VEVOR VV-LLT-150 Instructions

INSTRUCTIONS
Thank you for buying our low voltage transformers. The installation or instruction
covers the specifications as following.
Type-No. Rating Power
VV-LLT-150 150VA
VV-LLT-200 200VA
VV-LLT-300 300VA
VV-LLT-600 600VA
Read this instructions carefully before install or use it. Please keep the safety
warnings or instructions for future use.
!!! WARNING
!!! This device is only accepted for use as a component of a landscape lighting
system,Don not use it as power supply for swimming pool or Spa lighting system.
!!! Risk of Electric shock. The transformer is an electric device with 110V/120V
operation voltage. There exists the potential risk of ELECTRICAL
SHOCK ,EXPLOSION and FIRE HAZARDS.
!!! IF installation involves special wiring or repair it with case opened, please consult
a qualified electrician.
!!! Suitable for indoor and outdoor use. It can be used` in drizzling rain, but can not be
used in heavy rain. Protect it from possible heavy rain .
!!! Do not submerge the transformer.
!!! Avoid the Electrical Shock, install or operate it at least 3m far away from wet
environment. Connecting with GFCI Protected receptacle is highly recommended
when use outdoors.
!! Caution
!! Please note the rating power, Use with only below allowance DO NOT beyond it.
Please refer in Calculation Power Consumption.
!! Getting hot when use, keep it well ventilated and Do not touch it.
!! Please shut off the power supply if not use it for a long time.
Calculation Power Consumption.
1 Low voltage systems are supposed to reduce standard 120-VOLT power from your
home to 12-VOLTS. Calculation the power consumption as following procedure.
A： Total wattage of Incandescent bulbs (Resistive) multiply by 1.1(*1.1)；
B： Total Wattage of LED bulbs/fixture (Electromagnetic/Inductive) multiply by 1.6
(*1.1/0.7)；
C: Add A and B （）as the power consumption allowance, aka minimum transformer
VA requirement；
D: The C must be less than the Rating power of the transformers. If special
Input Volt./ Output
Amp. Voltage
120V/60Hz/ 12V/13V/14V/
1.25A 15V
120V/60Hz/ 12V/13V/14V/
1.66A 15V
120V/60Hz/ 12V/13V/14V/
2.5A 15V
120V/60Hz/ 12V/13V/14V/
5A 15V
Max output
Amp.
12.5A
16.6A
25A
50A
