REVOV R200 Manual

8. Do not strike, throw, or subject the battery to sever physical shock.
9. Do not directly solder the battery terminals.
10. Do not attempt to disassemble or modify the battery in any way.
11. Do not place the battery in a microwave oven or pressurized container.
12. Do not use the battery in combination with primary batteries (such as dry cell batteries) or batteries
of different cell count, cell-capacity, type, or brand.
13. Do not use the battery if it gives off an odour, generates heat, becomes discoloured or deformed,
or appears abnormal in any way. If the battery is in use or being recharged, remove it from the
device or charger immediately and discontinue use.
14. Do not dispose the battery before completely discharge.
15 Do not charge the battery by charging voltage over 57.0V.
16. Do not charge the battery by a charger with an automatic desulfation mode function
(equalization).
17. Please fix the battery terminal with original screws and nuts securely. Battery may be damaged by
the sparks because of the loose connections.
18. Keep out of reach of Children and Pets.
Transport Concerns
1. The battery should be transported with 70% charge state (approx.).
2. The battery should be packed with insulation and shockproof material to avoid damage from
sudden jolts and collision.
3. The battery should be handled with care when loading and unloading during transport.
Do not throw the batteries and avoid collision.
4. Do not transport the batteries together with flammable, explosive objects, or sharp metal goods.
Storage
5. The battery should be stored with 50% charge state (approx.).
6. The battery should be stored in a clean, dry,and ventilated environment (20-30°C), not in contact
with any corrosive substance and away from heat and fire.
7. The battery should be charged completely once every 180 days when in storage.
The battery pack comprises multiple systems that are designed to prevent hazards resulting from
failures. However, due the nature of electrical systems, REVOV cannot guarantee their absolute safety.
Leaking Batteries
If the battery pack leaks electrolyte, avoid contact with the leaking liquid or gas. If one is exposed to the
leaked substance, immediately perform the actions described below.
8. Inhalation: Evacuate the contaminated area and seek medical attention.
9. Contact with eyes: Rinse eyes with flowing water for 15 minutes and seek medical attention.
10. Contact with skin: Wash the affected area thoroughly with soap and water, and seek
medical attention
11. Ingestion: Induce vomiting, and seek medical attention.
Fire
In case of fires, make sure that the extinguisher is available near the battery pack. If possible, move the
battery pack to a safe area before it catches fire. Note: Fire Extinguisher Water, carbon dioxide, dry
chemical powder and foam are the most effective means to extinguish a Lithium Ferrous Phosphate (LFP)
battery fire.
WARRANTY
REVOV Batteries (PTY) LTD:
10 years or 3 500 cycles at 1 cycle per day.
DOD When used properly every day the R200 can be safely discharged to 100% of its rated 200Ah capacity.
Battery life is shortened if it is discharged beyond its rated Ah capacity.
R200
51.2V 200Ah 10.24kWh 2
The REVOV R200 is a 2 LiFe 16cell, 51.2V, 200Ah, 10.24kWh, Battery Module with built-in BMS with CANBus
nd
communications. Where inverter communications are required the unit's CAN bus communications provides
State of Charge and other information to supported inverters. In installations where no communications to
the inverter are required the REVOV 2 LiFe R200 can act as a lead-battery replacement. Automotive grade
nd
2 LiFe cells and REVOV 16 cell technology deliver superior performance under all loads assembled to meet
nd
the highest standards of SAFETY, RELIABILITY and LONGEVITY.
It is the perfect choice to provide backup power and integrate into Solar systems where daily cycling of the
system is desired. It is common to install just one battery to deal with blackouts but grow the system later.
More batteries can be added easily onto a shared busbar for those reducing their grid power usage in a
phased approach. The REVOV 2 LiFe R200 can be orientated with the "face"to the front, top or side for
nd
convenient wall and 19"rack mounting.
Model 9 (External label) Type
R200 51.2V LiFePO
4
REVOV Product Code: Type
2LIFE-R9-UBMS-R200-10.2 51.2 battery
Technical Specifications
General Settings
Float Charge
Bulk/Boost/
Inverter Voltage (V) Settings
Absorption Charge
Low Voltage
Disconnect
Maximum Charge current (A) @25°C ambient
Recommended Charge current (A)
Max. DIscharge Current Continuous
(A)
Recommended Recharge time (h)
Charging Temperature (°C)
Max output power (W)
Total Energy (kWh)
Nominal voltage (V)
Capacity (Ah)
Scalability
LiFe PO
nd
4
Package Domensions (mm)
L H W Weight
200Ah 620 520 300 86kg
Equipment Excl. Packaging (mm)
L H W Weight
520 442 221 83.6kg
Dependent on inverter type Notes
54.5V
Absorption 55-55.6V
55.5V
Load and temperature
dependent
46.5V
100A
60A Recommended
125A In-line fuse
160A
recommended
Even 60A is sufficient
3h
recommended
10-35°C
7500W
10.2kWh
51.2V
200Ah
Up to 15 Batteries in parallel
