- Page 1 User Manual Product：Aluminum Rollator Model：OS-28HFK-RW-9213-B...
- Page 2 First of all, thank you very much for choosing OasisSpace products, please read the instructions ca refully before assembling. The product structure diagram is as follows:...
- Page 3 1. Cup holder 2.Handgrip 3.Right rear leg tube 4.Left rear leg tube 5.Triangle Knob 6.Cane holder 7.Knob 8.Left front wheel 9.Left footrest 10.Right footrest 11.Right front wheel 12.Shopping bag 13.Main Frame Firstly, Preparation before assembly: After unpacking the packing box, first use scissors to remove the plastic ties and the packed bubble bag.
- Page 4 Secondly, Assembly instructions: (please refer to the part number and name in Figure 1 for asse mbly): Step one：（As pic2 showed） Put the 2 armrest tube on the 13 main frame; put 3 the right rear wheel tube and 4 the left rear wheel tube on the 13 main frame and fix it with 5 triangle knob. Put 8 The left front wheel and 11 The right front wheel respectively on the 13 Main frame and fix them.
- Page 5 Pic2 Step 2: （As pic3 showed） Put 9 left pedal and 10 pedal right on 13 main frame, fix with 7 plum knob; fix 6 umbrella frame on 13 main frame; then fix 1 cup holder On the 2 armrest tube; finally fix the 12 hanging bag on the 13 main frame.
- Page 6 After packaging, the four-wheeler should be stored at a temperature not exceeding -10 ℃ to 40 ℃, and a relative humidity not exceeding 80%. No corrosive gas and well ventilated, clean room. Keep away from moisture, light and heat during transportation. Brand Products: OasisSpace Shower Bench Shower Chair Bamboo Shower Chair...
- Page 7 Rollator Walker Walker Knee Scooter Toilet Rail...
