- Page 1 BR10 User's Manual Wireless Audio Receiver aptX HD Audio RX USB Disk...
-
Page 3: Table Of Contents
Table of Contents 1. Introduction .................................. 2 2. What's in the box ................................2 3. Interface ..................................3 4. Remote Controller ................................ 5 5. Connection ................................... 6 5.1 Line in..................................6 5.2 Optical Out ................................6 5.3 Line out ................................... 6 5.4 USB Disk Drive ................................ -
Page 4: Introduction
Bluetooth headphones or speakers. You can control the BR10 with a remote control or with our free Android and iOS mobile app, which gives you full control of the device with its user-friendly EQ system. -
Page 5: Interface
3.Interface - 3 -... - Page 6 Mode Button: Short press: Switch mode Long press: Standby mode on/off Quickly press twice: System update (with firmware file in USB disk drive) Vol – Button: Short press: Decrease volume Long press: Play prev track Play/Pause Button: Short press: Play or Pause music Long Press: Enter Bluetooth paring mode Vol + Button: Short press: Increase volume Long press: Play next track...
-
Page 7: Remote Controller
4.Remote Controller - 5 -... -
Page 8: Connection
5.Connection 5.1 Line in Use the 2-1 RCA cable or Aux 3.5mm cable to connect an audio source device that has RCA or AUX output. 5.2 Optical Out Use an optical cable to connect to an amplifier or audio device that has optical input. 5.3 Line out Use the 2-1 RCA cable or Aux 3.5mm cable to connect an amplifier or active speaker. -
Page 9: Usage
Once connected, the Bluetooth light will stay on indicates connection successful. You than can play music and hear the audio from the connected audio device. BR10 will remember the connected device and auto connect to it when it is available. - 7 -... -
Page 10: Line In Mode
6.2 Line In Mode You can connect any device with line/AUX output to BR10. Press the Mode button on the device or use the remote controller or Go Control APP to switch to AUX mode. The AUX LED will turn on when in AUX mode. -
Page 11: Usb Disk Drive Mode
6.4 USB DAC Mode You can connect BR10 to your PC to work as an external USB DAC (like a sound card). Please make sure the cable you use has data link and not just a charging cable. Some charging cable is only for charging and does not contain data link for data transfer. -
Page 12: Firmware Update
6.5 Firmware Update You can go to our web site or forum to look for new firmware update. If there is a firmware update you want to install, download the MVA file and copy it to the root directory of a USB disk drive. Power up the device and plug in the USB disk drive with firmware file, once the USB indicator light is on, quickly press the Mode button twice to start the update. -
Page 13: Acpworkbench (Sell Separately)
7.Mobile Application Go Control is a user-friendly control application for BR10. You can easily take control of the device without complicate configuration; Go Control lets you do playback control, input source selection, enable Bluetooth pairing, enable Bluetooth transmission and in-depth EQ settings for BR10. -
Page 14: Specification
9.Specification Bluetooth BT Standard Receive 2x Bluetooth RX, able to connect up to 2 Bluetooth transmitter devices Codec aptX, aptX HD, aptX AD, AAC, SBC Audio I/O Line in 3.5mm analog earphone jack, Max 2Vrms input Optical in Up to 192KHz/24bit PCM only USB disk drive playback, support resume playback Audio Input Sample rate: 48kHz... - Page 16 @Copyright 2024 by Arylic. All Rights Reserved. The information contained in this guide is believed to be accurate and reliable. Arylic assumes no responsibility for any errors contained in this guide. Arylic reserves the rights to make changes in the specifications and/or design of the above mentioned product without prior notice.
