INSTALLATION GUIDELINES
CLOTHILDE 70" X 33" X 29" FREESTANDING OVAL COPPER BATHTUB
COBT01
IMPORTANT:
 Installation of this product in a wet environment such as outdoors,
steam rooms, or within showering stalls voids all Warranty.
 Immediately after receiving the BATHTUB and removal of packing,
you MUST inspect the unit for freight damage. Any claims for damage,
whether apparent or hidden, must be made to the carrier immediately
in order for them to assume all associated costs. Should inspection
reveal any defect in the finish, do not install the BATHTUB. Damage or
defect to the finish claimed after the BATHTUB is installed is excluded
from the warranty. The warranty DOES NOT cover labor or materials
to remove or re-install the BATHTUB.
 To ensure this product is installed properly, you must read and follow
these guidelines.
 The owner/user of this product must keep this information for future
reference.
CAUTION: This product is extremely heavy and adequate floor support

is required. Ensure the product is properly supported by the base.
 This product must be installed by a professional licensed contractor.
Be sure your installation conforms to all federal, state, and local codes.
 Inspect this product to assure it is the correct model and you have
all parts required for proper installation. Take all the necessary
precautions to ensure this product is protected during installation and
do NOT install this product if it has been damaged.
 All final connections are made below the finished floor. Accessibility
below the finished floor is required.
PRODUCT SUPPORT | 800.927.2120 | WATERWORKS.COM
STYLE
 It is strongly advised that a bead of caulk be applied to seal the tub to the floor post
installation. This will reduce the potential of water and humidity from being captured under
the unit, preventing lacquer and material decay (rust, corrosion, etc.)
 The use of certain plumber's putty may stain stone or tile surfaces.
WARNING: Use of harsh floor cleaners up to the exterior surface of the tub may strip the

exterior lacquer protecting the finish. This will expose the cast iron to elements likely to
produce rust.
 WARNING: The following basic safety precautions should always be followed when using
your BATHTUB.
● Caution should always be exercised when entering or leaving the BATHTUB.
DANGER: To reduce the risk of injury, do NOT permit children or persons with a
●
disability to use the BATHTUB without close supervision.
Keep all electrical appliances such as radios and hairdryers a safe distance from the
●
BATHTUB.
● Do NOT use the BATHTUB when sleepy or drowsy, under the influence of alcohol or
prescription medications or when overheated.
 If further assistance is required, please contact Product Support at 1-800-927-2120 Monday
through Friday, 8am – 6pm EST.
TECHNICAL DETAILS:
DETAIL
ADJUSTABLE LEVELERS/FEET
DRAIN HOLE DIAMETER
OVERFLOW HOLE DIAMETER
SINGLE OR DOUBLE ENDED
WATER CAPACTIY
DRY
WEIGHT
FILLED
REQUIRED PLUMBING DETAILS:
 Clothilde Stand Pipe Waste and Overflow
STYLE No. COWO75
SPECIFICATION
YES
2-1/16" [53mm]
2-1/16" [53mm]
DOUBLE ENDED
57 gal [215 liters]
437 lbs. [198 kg]
912 lbs. [414 kg]
PAGE 1 OF 4 | UPDATED ON 3.07.2023
