Summary of Contents for Epic UMC V5.3
- Page 1 UMC for WhatsMiners Complete User Guide...
-
Page 2: Table Of Contents
Mining Config How to connect ePIC UMC Performance Perpetual Tune How to reassemble the miner Network List of models with ePIC UMC Support System VEx & 0x1950 chip type Find Miner VGx & 0x1960 chip type Logs VHx & 0x1968 chip type... -
Page 3: Installing Epic Umc Control Board
Installing ePIC UMC Control Board... -
Page 4: Epic Umc For Whasminer Overview
1. ePIC UMC for Whatsminer Overview Our ePIC UMC V5.3 is compatible with Whatsminer products Features & Specifications Hashboard Communication Connector PSU Connector Ethernet Connector Fan Connector microSD Card Connector... -
Page 5: Components
Components Included Not Included MicroSD Card SD card to USB adapter ePIC UMC v5.3 Power Cords Ethernet Cable Required Tool : Screwdriver... -
Page 6: Installation Instructions
2. Installation Instructions How to disassemble the miner Unscrew the 4 screws in the direction as shown Whatsminer M30S+... - Page 7 b. Lift the metal cage...
-
Page 8: How To Disconnect Whatsminer Control Board
How to Disconnect Whatsminer Control Board c. Disconnect the fan, PSU, and hashboard connectors Hasboard... - Page 9 d. Unscrew the 4 screws in the direction as shown...
-
Page 10: How To Connect Epic Umc
How to Connect ePIC UMC Control Board e. Secure the ePIC UMC using the 4 screws in the direction as shown... - Page 11 f. Connect the hashboard, PSU, and the fan connector Hashboard...
-
Page 12: How To Reassemble The Miner
How to Reassemble the Miner e. Secure the metal plate using the 4 screws below. -
Page 13: List Of Models With Epic Umc Support
List of models with ePIC UMC Support... - Page 14 P/N indicates model of your WhatsMiner and the part number Model Name M30S+_VH2.0 Supported Part Number Check the table for VHx & 0x1968 Chip Type and find out if this model is supported. In this case, M30S+_VH2.0 is supported by ePIC UMC.
-
Page 15: Vex & 0X1950 Chip Type
VEx & 0x1950 Chip Type Models M30S M30S+ M30S++ M31S M31S+ M34S+ M36S Supported Part Number ✔ ✔ ✔ ✔ ✔ VE1x ✔ ✔ ✔ VE2x ✔ ✔ ✔ ✔ ✔ VE3x ✔ ✔ ✔ ✔ VE4x ✔ ✔ ✔ ✔... -
Page 16: Vgx & 0X1960 Chip Type
VGx & 0x1960 Chip Type Models M30S M30S+ M30S++ M31S+ M33S M33S+ M33S++ M36S+ Supported Part Number ✔ VG1x ✔ ✔ ✔ ✔ VG2x ✔ ✔ ✔ ✔ ✔ ✔ ✔ VG3x ✔ ✔ ✔ ✔ VG4x ✔ VG5x ✔ VG6x... -
Page 17: Vhx & 0X1968 Chip Type
VHx & 0x1968 Chip Type Models M30S M30S+ M30S++ M33S+ M33S++ M36S++ M50s Supported Part Number ✔ ✔ ✔ ✔ VH1x ✔ ✔ ✔ ✔ ✔ ✔ ✔ VH2x ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ VH3x ✔ ✔ ✔... -
Page 18: Using Epic Dashboard
Using the ePIC Dashboard... -
Page 19: Download The Epic Dashboard Installation Package
4. Download the ePIC Dashboard Installation Package Click here to directly access to epic-dashboard Go on ePIC GitHub and click epic-dashboard Click the latest release as shown Choose your OS accordingly Open the downloaded zip file Run the epic-dashboard application... -
Page 20: Find Ip Of The Miner
5. Find IP of the Miner By default all of the miners have a password of letmein Scanning for Miners You can first try using the “Quick Miner Scan” in the sidebar. This will scan the network the computer is currently connected to Click “Advanced Scan”... - Page 21 6. ePIC Dashboard - Control your miner Password is required to apply the setting HOME MINER CONTROL MINER CONFIG PERFORMANCE To add, save, load, remove and To execute the desired command To copy a miner’s config into the To select the desired Preset blacklist miners fields, select the miner and then...
-
Page 22: Epic Dashboard
Dashboard Password is required to apply the setting SYSTEM COOLING TUNE PERPETUAL TUNE To update Firmware with the To set the desired fan speed and To set the desired clock To turn on Perpetual Tuning, latest release, click here shutdown temperature. -
Page 23: Using Epic Webdash
Using the ePIC Webdash... -
Page 24: Control Panel
7. Control Panel To execute the desired command Turns miner off and back on. Stops the miner from Mining will restart once mining miner is turned back on Restarts mining software Sets the machine back to its Locks or unlocks without rebooting the original state with the Webdash for... -
Page 25: Unlocking Miner
Unlocking Miner To get an access to the Webdash Enter your miner IP on a desired web browser. Click the button in the top right corner and enter the password. Password by default : letmein... -
Page 26: Toggle Theme
8. Toggle Theme To change the colour of the Webdash environment Dark Mode Light Mode... -
Page 27: Dashboard
9. Dashboard To view status of a miner Real-time Configuration mining status options xxxxxxxxxx Pool status Fan speed PSU status Hasboard chips information... - Page 28 10. Settings - Mining Config To modify and configure a miner Our firmware supports 3 mining pools in case a connection cannot be made, which takes precedence from top to bottom. “Unique ID” will append the unique miner id at the end of the worker name if enabled.
-
Page 29: Performance
Performance Tune Shutdown Temperature Choose the desired preset, or Set the desired fan speed Set the desired shutdown input your own voltage and temperature to prevent Note: it is generally recommended to turn on frequency overheating AutoFan. There is a minimum Fan speed tied to the miner’s current preset. -
Page 30: Perpetual Tune
Perpetual Tune To maintain the target hashrate at best performance Whatsminer Turn on the “VoltageOptimizer” toggle, and enter your target hashrate Note: Perpetual Tuning is only available in firmware version 0.23.4 or later. Chiptune is not available in Whatsminers. -
Page 31: Network
Network Turn off the DHCP toggle if you want to set static IPs for your operation. Enter the fields and hit “APPLY”... -
Page 32: System
System Update Enter your new password, confirm, then hit Download the latest release of the firmware “APPLY” from ePIC Github Download the zip file powerplay-xxxx-update-vxxxxxxx.zip Upload, then hit “APPLY” *DO NOT UNZIP! Note: The “Maintain config over update” will save your settings across the update. -
Page 33: Find Miner
11. Find Miner Turn on the “Find Miner” toggle. Your miner will be flashing red light Indicates that your miner will be flashing red light... - Page 34 12. Logs Turn “Logs” toggle on Real-time log Download the logs Scroll to bottom Close the logs...
-
Page 35: Api
13. API To manually enable application Click API and click the desired command to run Click “Try it out” Enter the desired value and click “Execute”... - Page 36 Have a question? Website https://epicblockchain.io/support/ Email Support@epicblockchain.io Github https://github.com/epicblockchain Twitter https://twitter.com/ePICBlockchain Telegram https://t.me/epic_umc...
