OWNER'S MANUAL
R125
MOTORCYCLE
Read this manual carefully before oper-
ating this vehicle.
YZF-R125
YZF-R125A
5D7-F8199-E6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R125 2015 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha R125 2015

Summary of Contents for Yamaha R125 2015

  • Page 1 OWNER’S MANUAL R125 MOTORCYCLE Read this manual carefully before oper- ating this vehicle. YZF-R125 YZF-R125A 5D7-F8199-E6...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
  • Page 3 If you have any further questions, do not hesitate to contact your Yamaha dealer. The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first! Yamaha continually seeks advancements in product design and quality. There-...
  • Page 4 Important manual information EAU63350 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury haz- ards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 5: Table Of Contents

    Table of contents Safety information ......1-1 Checking the spark plug....6-9 Engine oil and oil filter element ..6-11 Description ........2-1 Coolant ......... 6-14 Left view ..........2-1 Replacing the air filter element Right view........2-2 and cleaning the check hose..6-15 Controls and instruments....2-3 Checking the engine idling speed.........
  • Page 6 Table of contents Replacing a turn signal light bulb ........... 6-37 Replacing the license plate light bulb ........... 6-37 Supporting the motorcycle... 6-38 Front wheel (for non-ABS models)....6-38 Rear wheel (for non-ABS models)....6-40 Troubleshooting......6-41 Troubleshooting charts....6-42 Motorcycle care and storage..

  • Page 7: Safety Information

    Safety information EAU1028B an accident or equipment damage. See page 4-1 for a list of pre-operation checks. Be a Responsible Owner  This motorcycle is designed to As the vehicle’s owner, you are re- carry the operator and a passen- sponsible for the safe and proper oper- ger.
  • Page 8 Safety information  Many accidents involve inexperi- • The passenger should always enced operators. In fact, many op- hold onto the operator, the seat erators who have been involved in strap or grab bar, if equipped, accidents do not even have a cur- with both hands and keep both rent motorcycle license.
  • Page 9 Safety information extra care when riding a motorcycle Avoid Carbon Monoxide Poisoning All engine exhaust contains carbon that has added cargo or accessories. monoxide, a deadly gas. Breathing Here, along with the information about carbon monoxide can cause head- accessories below, are some general aches, dizziness, drowsiness, nausea, guidelines to follow if loading cargo to confusion, and eventually death.
  • Page 10 Genuine before using it to make sure that it Yamaha accessories, which are avail- does not in any way reduce able only from a Yamaha dealer, have ground clearance or cornering been designed, tested, and approved clearance, limit suspension travel, by Yamaha for use on your vehicle.
  • Page 11 Safety information operator and may limit control torcycle, such as the frame or up- ability, therefore, such accesso- per front fork triple clamp (and not, ries are not recommended. for example, to rubber-mounted  Use caution when adding electri- handlebars or turn signals, or cal accessories.

  • Page 12: Description

    Description EAU63371 Left view 2 3 4 1. Battery (page 6-32) 2. Owner’s tool kit (for ABS models) (page 6-2) 3. Owner’s tool kit (page 6-2) 4. Fuse box (page 6-34) 5. Shift pedal (page 3-13) 6. Engine oil drain bolt (page 6-11) 7.

  • Page 13: Right View

    Description EAU63391 Right view 1. Front brake fluid reservoir (page 6-24) 2. Spark plug (page 6-9) 3. Engine oil filter element (page 6-11) 4. Dipstick (page 6-11) 5. Rear brake fluid reservoir (page 6-24) 6. Brake pedal (page 3-14)

  • Page 14: Controls And Instruments

    Description EAU63401 Controls and instruments 1. Clutch lever (page 3-13) 2. Left handlebar switches (page 3-11) 3. Multi-function meter unit (page 3-4) 4. Main switch/steering lock (page 3-1) 5. Right handlebar switches (page 3-11) 6. Throttle grip (page 6-16) 7. Brake lever (page 3-14)

  • Page 15: Instrument And Control Functions

    Instrument and control functions EAU10462 EAU10693 Main switch/steering lock LOCK The steering is locked, and all electrical systems are off. The key can be re- moved. To lock the steering The main switch/steering lock controls the ignition and lighting systems, and is used to lock the steering.

  • Page 16: Indicator Lights And Warning Lights

    RESET SELECT gine is not working correctly. If this oc- ZAUM1316 1. Turn signal indicator light “ ” curs, have a Yamaha dealer check the 2. Neutral indicator light “ ” self-diagnosis system. 3. High beam indicator light “ ”...
  • Page 17 Instrument and control functions The ABS may not work correctly. If any come on to indicate that the function is of the above occurs, have a Yamaha activated or the light will go off to indi- dealer check the system as soon as cate that the function is deactivated.

  • Page 18: Multi-Function Meter Unit

    Instrument and control functions  a speedometer EAUM3422 Multi-function meter unit  a tachometer  a clock FTRIP x1000r/min  a fuel meter km/h km/L/100km  a coolant temperature meter  an odometer and tripmeter display RESET SELECT  a multi-function display ...
  • Page 19 Instrument and control functions To set the clock Tachometer 1. Turn the key to “ON”. 2. Push the “SELECT” button for at least two seconds. x1000r/min 3. When the hour digits start flash- ing, use the “RESET” button to set the hours.
  • Page 20 3 seconds repeatedly. If this diator. occurs, have a Yamaha dealer check  If the engine overheats, see page the electrical circuit. 6-43 for further instruction.
  • Page 21 Instrument and control functions ODO (odometer) → TRIP 1 (tripmeter) Multi-function display → TRIP 2 (tripmeter) → ODO (odome- ter) F TRIP km/L ZAUM1307 1. Multi-function display ZAUM1306 The multi-function display is equipped 1. Odometer/tripmeter/fuel reserve tripmeter with the following: ...
  • Page 22 Instrument and control functions  “km/L”: The distance that can be SPEED/__km/h”, the oil service re- minder “DIST SERV/__km” in the fol- traveled on 1.0 L of fuel under the lowing order: current riding conditions is shown.  “L/100 km”: The amount of fuel C Ave__._km/L →...
  • Page 23 Instrument and control functions  “AVE_ _._ MPG” (for the UK only): two seconds. The average speed dis- The average distance that can be play will also reset automatically 4 traveled on 1.0 Imp.gal of fuel is hours after the key was last turned to shown.
  • Page 24 If the low battery indicator comes on If the engine oil is changed before the have a Yamaha dealer check the bat- oil change indicator comes on (i.e. be- tery. fore the set oil service interval has been...

  • Page 25: Handlebar Switches

    If the display indicates any error codes, note the code number, and then have a ZAUM1163 Yamaha dealer check the vehicle. 1. Engine stop switch “ ” 2. Start switch “ ”...
  • Page 26 Instrument and control functions the multi-function meter unit and page EAU12461 Turn signal switch “ ” 3-3 for information on the tachometer To signal a right-hand turn, push this high-rpm warning light.) switch to “ ”. To signal a left-hand turn, push this switch to “...

  • Page 27: Clutch Lever

    Instrument and control functions EAU12822 EAU12872 Clutch lever Shift pedal ZAUM1164 ZAUM1165 1. Clutch lever 1. Shift pedal The clutch lever is located on the left The shift pedal is located on the left side of the handlebar. To disengage side of the motorcycle and is used in the clutch, pull the lever toward the combination with the clutch lever when...

  • Page 28: Brake Lever

    Instrument and control functions EAU12892 EAU12944 Brake lever Brake pedal ZAUM1166 1. Brake lever 1. Brake pedal The brake lever is located on the right The brake pedal is located on the right side of the handlebar. To apply the side of the motorcycle.

  • Page 29: Abs (For Abs Models)

     This ABS has a test mode which EAU60021 ABS (for ABS models) allows the owner to experience The Yamaha ABS (Anti-lock Brake the pulsation at the brake lever or System) features a dual electronic con- brake pedal when the ABS is op- trol system, which acts on the front and erating.

  • Page 30: Fuel Tank Cap

    Instrument and control functions EAUM2082 EAU13213 Fuel tank cap Fuel Make sure there is sufficient gasoline in the tank. EWA10882 WARNING Gasoline and gasoline vapors are extremely flammable. To avoid fires and explosions and to reduce the risk of injury when refueling, follow these instructions.
  • Page 31 Your Yamaha engine has been de- signed to use premium unleaded gas- oline with a research octane number of 95 or higher. If knocking (or pinging)

  • Page 32: Catalytic Converter

    Instrument and control functions EAU13434 EAUM2461 Catalytic converter Rider seat This model is equipped with a catalytic converter in the exhaust system. To remove the rider seat 1. Insert the key into the seat lock, EWA10863 WARNING and then turn it clockwise. The exhaust system is hot after op- eration.

  • Page 33: Sidestand

    Therefore, check this system regularly and have a Yamaha dealer repair it if it does not function properly. 3-19...

  • Page 34: Ignition Circuit Cut-Off System

    Instrument and control functions EAU66730 Ignition circuit cut-off system The ignition circuit cut-off system (comprising the sidestand switch, clutch switch and neutral switch) has the following functions.  It prevents starting when the transmission is in gear and the sidestand is up, but the clutch le- ver is not pulled.
  • Page 35 Does the engine start? The neutral switch may not be working correctly. The motorcycle should not be ridden until checked by a Yamaha dealer. With the engine still running: 6. Move the sidestand up. 7. Keep the clutch lever pulled.

  • Page 36: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 37 • Check operation. — signals and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch • If system is not working correctly, have Yamaha dealer 3-19 check vehicle. • Check fluid level. Battery 6-32...

  • Page 38: Operation And Important Riding Points

    This model is equipped with a lean an- there is a control or function you do not gle sensor to stop the engine in case of understand, ask your Yamaha dealer. a turnover. In this case, the multi-func- EWA10272 tion display indicates error code 30, WARNING but this is not a malfunction.

  • Page 39: Starting The Engine

    The neutral indi- the clutch lever pulled and the cator light should come on. If not, sidestand up. ask a Yamaha dealer to check the See page 3-20 for more informa- electrical circuit. tion. 3. Start the engine by pushing the 1.

  • Page 40: Shifting

    Operation and important riding points EAU16673 and drive train, which are not Shifting designed withstand shock of forced shifting. ZAUM1167 1. Shift pedal 2. Neutral position Shifting gears lets you control the amount of engine power available for starting off, accelerating, climbing hills, etc.

  • Page 41: Tips For Reducing Fuel Consumption

    Operation and important riding points EAU16811 EAU16831 Tips for reducing fuel con- Engine break-in sumption There is never a more important period in the life of your engine than the period Fuel consumption depends largely on between 0 and 1000 km (600 mi). For your riding style.

  • Page 42: Parking

    Yamaha dealer check the vehi- touch them and be burned. cle.  Do not park on a slope or on soft...

  • Page 43: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service. EWA15123 WARNING Turn off the engine when performing...

  • Page 44: Owner's Tool Kit

    If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.

  • Page 45: Periodic Maintenance Chart For The Emission Control System

     From 30000 km (17500 mi), repeat the maintenance intervals starting from 6000 km (3500 mi).  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. EAU69210...

  • Page 46: General Maintenance And Lubrication Chart

    Periodic maintenance and adjustment EAU69250 General maintenance and lubrication chart ODOMETER CHECK OR READING MAINTENANCE JOB ITEM X 1000 km X 1000 mi 10.5 14 √ √ • Clean. 1 * Air filter element √ √ • Replace. Air filter check √...
  • Page 47 Periodic maintenance and adjustment ODOMETER CHECK OR READING MAINTENANCE JOB ITEM X 1000 km X 1000 mi 10.5 14 • Check chain slack, alignment Every 1000 km (600 mi) and af- and condition. ter washing the motorcycle, rid- Drive chain •...
  • Page 48 Periodic maintenance and adjustment ODOMETER CHECK OR READING MAINTENANCE JOB ITEM X 1000 km X 1000 mi 10.5 14 Engine oil filter el- √ √ √ √ √ • Replace. ement • Check coolant level and vehicle √ √ √ √...

  • Page 49: Removing And Installing The Cowlings And Panel

    Periodic maintenance and adjustment EAU18732 Removing and installing the cowlings and panel ZAUM1170 1. Screw 2. Cowling A ZAUM1169 1. Cowling A To install the cowling 2. Cowling B Place the cowling in the original posi- 3. Cowling C tion, and then install the screws. 4.
  • Page 50 Periodic maintenance and adjustment 2. Fit the projection on the cowling into the slot, and then slide the cowling backward. 3. Install the screws. 4. Install cowling A and panel A. Cowling C To remove the cowling ZAUM1173 Remove the screws, and then pull the 1.

  • Page 51: Checking The Spark Plug

    Periodic maintenance and adjustment EAU19633 Checking the spark plug The spark plug is an important engine component, which is easy to check. Since heat and deposits will cause any spark plug to slowly erode, the spark plug should be removed and checked in accordance with the periodic main- tenance and lubrication chart.
  • Page 52 Spark plug: ating improperly. Do not attempt to 12.5 Nm (1.25 m·kgf, 9.04 ft·lbf) diagnose such problems yourself. In- stead, have a Yamaha dealer check the vehicle. If a torque wrench is not available when installing a spark plug, a good 2.

  • Page 53: Engine Oil And Oil Filter Element

    Periodic maintenance and adjustment EAUM3491 Engine oil and oil filter ele- ment The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter ele- ment replaced at the intervals specified in the periodic maintenance and lubri- cation chart.
  • Page 54 Periodic maintenance and adjustment 4. Place an oil pan under the engine to collect the used oil. 5. Remove the engine oil filler cap and the drain bolt along with the O-ring, compression spring, and engine oil strainer, to drain the oil from the crankcase.
  • Page 55 Periodic maintenance and adjustment NOTICE: Before installing the 13. Turn the engine off, and then engine oil drain bolt, do not for- check the oil level and correct it if get to install the O-ring, com- necessary. pression spring, and oil strainer 14.

  • Page 56: Coolant

    If water has been added to the coolant, have a Yamaha dealer check the anti- freeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.

  • Page 57: Replacing The Air Filter Element And Cleaning The Check Hose

    WARNING! Never attempt to remove periodic maintenance and lubrication the radiator cap when the engine is chart. Have a Yamaha dealer replace hot. [EWA10382] the air filter element more frequently if you are riding in unusually wet or dusty areas.

  • Page 58: Checking The Engine Idling Speed

    Adjusting the throttle grip free speed play Check the engine idling speed and, if necessary, have it corrected by a Yamaha dealer. Engine idling speed: 1350–1550 r/min ZAUM1177 1. Throttle grip free play The throttle grip free play should mea- sure 3.0–5.0 mm (0.12–0.20 in) at the...

  • Page 59: Valve Clearance

    The valve clearance changes with use, sition. resulting in improper air-fuel mixture and/or engine noise. To prevent this from occurring, the valve clearance must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. 6-17...

  • Page 60: Tires

    The tires must be checked before each ride. If the center tread depth reaches the specified limit, if the tire has a nail or glass fragments in it, or if the side- wall is cracked, have a Yamaha dealer replace the tire immediately. 6-18...
  • Page 61 EWA10472 their suitability for further use. WARNING EWA10902  Have a Yamaha dealer replace WARNING excessively worn tires. Besides  The front and rear tires should being illegal, operating the vehi- be of the same make and de-...

  • Page 62: Cast Wheels

    130/70-17 M/C 62H(PIRELLI)- ride. If any damage is found, have 62S(MICHELIN) Manufacturer/model: a Yamaha dealer replace the PIRELLI/SPORT DEMON wheel. Do not attempt even the MICHELIN/PILOT STREET smallest repair to the wheel. A de-...

  • Page 63: Adjusting The Clutch Lever Free Play

    Periodic maintenance and adjustment EAU22046 Adjusting the clutch lever free play Measure the brake lever free play as shown. 1. Locknut 2. Clutch lever free play adjusting nut (crank- case) 6. To increase the clutch lever free play, turn the clutch lever free play 1.

  • Page 64: Checking The Front Brake Lever Free Play

    2.0–5.0 mm (0.08–0.20 in) 3.5–4.5 mm (0.14–0.18 in) Periodically check the brake lever free Periodically check the brake pedal free play and, if necessary, have a Yamaha play and, if necessary, have a Yamaha dealer check the brake system. dealer adjust it.

  • Page 65: Brake Light Switches

    (a). To make the indicator groove has almost disap- brake light come on later, turn the ad- peared, have a Yamaha dealer replace justing nut in direction (b). the brake pads as a set. For non-ABS models...

  • Page 66: Checking The Brake Fluid Level

    Check each rear brake pad for damage and measure the lining thickness. If a brake pad is damaged or if the lining thickness is less than 1.5 mm (0.06 in), have a Yamaha dealer replace the ZAUM1181 1. Minimum level mark brake pads as a set.

  • Page 67: Changing The Brake Fluid

     Clean the filler cap before re- EAU22733 Changing the brake fluid moving. Use only DOT 4 brake Have a Yamaha dealer change the fluid from a sealed container. brake fluid at the intervals specified in  Use only the specified brake flu- the periodic maintenance and lubrica- id;...

  • Page 68: Drive Chain Slack

    3. Tighten the axle nut, then the lock- EAU34318 nuts to their specified torques. To adjust the drive chain slack Consult a Yamaha dealer before ad- justing the drive chain slack. 1. Loosen the axle nut and the lock- nut on each side of the swingarm.

  • Page 69: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment EAU23026 Tightening torques: Cleaning and lubricating the Axle nut: drive chain 85 Nm (8.5 m·kgf, 61 ft·lbf) The drive chain must be cleaned and Locknut: 16 Nm (1.6 m·kgf, 12 ft·lbf) lubricated at the intervals specified in the periodic maintenance and lubrica- 4.

  • Page 70: Checking And Lubricating The Cables

    Yamaha dealer at the intervals cated if necessary. If a cable is specified in the periodic maintenance damaged or does not move smoothly, chart.

  • Page 71: Checking And Lubricating The Brake And Clutch Levers

    Periodic maintenance and adjustment EAU23144 EAU23185 Checking and lubricating the Checking and lubricating the brake and clutch levers brake pedal The operation of the brake and clutch The operation of the brake pedal levers should be checked before each should be checked before each ride, ride, and the lever pivots should be lu- and the pedal pivot should be lubricat- bricated if necessary.

  • Page 72: Checking And Lubricating The Sidestand

    EAUM1653 Checking and lubricating the Lubricating the swingarm piv- sidestand The swingarm pivots must be lubricat- ed by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart. Recommended lubricant: Lithium-soap-based grease The operation of the sidestand should...

  • Page 73: Checking The Front Fork

    If any free over. play can be felt, have a Yamaha [EWA10752] 2. While applying the front brake, dealer check or repair the steer- push down hard on the handle- ing.

  • Page 74: Checking The Wheel Bearings

    If there is play in the wheel skin, eyes or clothing and al- hub or if the wheel does not turn ways shield your eyes when smoothly, have a Yamaha dealer working near batteries. In case check the wheel bearings. of contact, administer the fol- lowing FIRST AID.
  • Page 75 Periodic maintenance and adjustment then place it in a cool, dry place. To check the electrolyte level NOTICE: When removing the 1. Place the vehicle on a level sur- face and hold it in an upright posi- battery, be sure the key is tion.

  • Page 76: Replacing The Fuses

    Periodic maintenance and adjustment EAUM3461 YZF-R125 Replacing the fuses 1 2 3 4 5 The fuse boxes, which contains the fuses for the individual circuits, are lo- cated under the rider seat. (See page 3-18.) ZAUM1189 1. Headlight fuse 2. Signaling system fuse 3.

  • Page 77: Replacing A Headlight Bulb

    Main fuse: This model is equipped with halogen 20.0 A bulb headlights. If a headlight bulb Ignition fuse: burns out, have a Yamaha dealer re- 7.5 A Signaling system fuse: place it and, if necessary, adjust the 7.5 A headlight beam.

  • Page 78: Replacing An Auxiliary Light Bulb

    This model is equipped with two auxil- If the tail/brake light does not come on, iary lights. If an auxiliary light bulb have a Yamaha dealer check it. burns out, replace it as follows. 1. Remove the auxiliary light bulb socket (together with the bulb) by pulling it out.

  • Page 79: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU24205 EAUM3510 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the screw. ZAUM1190 1.

  • Page 80: Supporting The Motorcycle

    EWA14841 WARNING when removing the front and rear wheel or performing other mainte- For the ABS model, have a Yamaha nance requiring the motorcycle to dealer remove and install the wheel. stand upright. Check that the motorcy- cle is in a stable and level position be- EAU56531 fore starting any maintenance.
  • Page 81 Periodic maintenance and adjustment 6. Tighten the wheel axle pinch bolt A and pinch bolt B to the specified torques. 7. Retighten the wheel axle pinch bolt A to the specified torque. 8. Tighten the brake caliper bolts to the specified torques. Tightening torques: ZAUM1192 Wheel axle:...

  • Page 82: Rear Wheel (For Non-Abs Models)

    Periodic maintenance and adjustment EAU44802 Rear wheel (for non-ABS models) EWA14841 WARNING For the ABS model, have a Yamaha dealer remove and install the wheel. EAU56701 1. Drive chain slack adjusting bolt 2. Locknut To remove the rear wheel EWA10822 6.

  • Page 83: Troubleshooting

    However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 84: Troubleshooting Charts

    2. Compression There is compression. Check the ignition. Operate the electric starter. There is no Have a Yamaha dealer check the vehicle. compression. Wipe off with a dry cloth and correct the 3. Ignition Operate the electric spark plug gap, or starter.
  • Page 85 Start the engine. If the engine overheats again, The coolant level is have a Yamaha dealer check and repair the cooling system. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended coolant as soon as possible.

  • Page 86: Motorcycle Care And Storage

    Rust and corrosion can develop matte colored finished parts. Be even if high-quality components are sure to consult a Yamaha dealer for used. A rusty exhaust pipe may go un- advice on what products to use be- noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 87 Motorcycle care and storage fected area any longer than in- scratching. Some cleaning structed. Also, thoroughly rinse compounds for plastic may the area off with water, immedi- leave scratches on the wind- ately dry it, and then apply a cor- shield.
  • Page 88  Consult a Yamaha dealer for ad- 4. To prevent corrosion, it is recom- vice on what products to use. mended to apply a corrosion pro- ...

  • Page 89: Storage

    Motorcycle care and storage head so that the electrodes are EAU43204 Storage grounded. (This will limit spark- ing during the next step.) Short-term d. Turn the engine over several Always store your motorcycle in a cool, times with the starter. (This will dry place and, if necessary, protect it coat the cylinder wall with oil.) against dust with a porous cover.
  • Page 90 Motorcycle care and storage Make any necessary repairs before storing the motorcycle.

  • Page 91: Specifications

    Specifications Dimensions: 10 30 50 70 90 110 130 ˚F Overall length: 1950 mm (76.8 in) SAE 10W-30 Overall width: SAE 10W-40 695 mm (27.4 in) SAE 10W-50 Overall height: 1065 mm (41.9 in) SAE 15W-40 Seat height: SAE 20W-40 825 mm (32.5 in) SAE 20W-50 Wheelbase:...
  • Page 92 Specifications Transmission: Manufacturer/model: MICHELIN/PILOT STREET Primary reduction ratio: Loading: 73/24 (3.042) Final drive: Maximum load: Chain 180 kg (397 lb) Secondary reduction ratio: (Total weight of rider, passenger, cargo 48/14 (3.429) and accessories) Transmission type: Tire air pressure (measured on cold Constant mesh 6-speed tires): Operation:...
  • Page 93 Specifications Wheel travel: ABS warning light: 130 mm (5.1 in) LED (YZF-R125A) Rear suspension: Fuse: Type: Main fuse: Swingarm (link suspension) 20.0 A Spring/shock absorber type: Headlight fuse: Coil spring/oil damper 15.0 A Wheel travel: Signaling system fuse: 114 mm (4.5 in) 7.5 A Electrical system: Ignition fuse:...

  • Page 94: Consumer Information

    Yamaha dealer or for reference in case the vehicle is stolen. EAU26471 Model label VEHICLE IDENTIFICATION NUMBER:...

  • Page 95: Index

    Index Horn switch........... 3-12 ABS (for ABS models) ......3-15 ABS warning light (for ABS models)..3-2 Identification numbers ......9-1 Air filter element and check hose, Ignition circuit cut-off system ....3-20 replacing and cleaning....... 6-15 Indicator lights and warning lights ..3-2 Auxiliary light bulb, replacing ....
  • Page 96 Index Valve clearance........6-17 Vehicle identification number ....9-1 Wheel bearings, checking.....6-32 Wheel, front (for non-ABS models) ..6-38 Wheel, rear (for non-ABS models) ..6-40 Wheels ..........6-20 10-2...
  • Page 98 Original instructions MBK Industrie Z.I. de Rouvroy 02100 Saint Quentin PRINTED IN FRANCE 2015.09 (E)
