WFCT8530 Circuit Diagram burner valve Right Front Right Rear Left Front Left Rear Ignition pin Pulse ignitor INPUT: 120V/AC 60Hz HV-4pin L (Black wire) Power Plug N (White wire) PE(Green wire) WFCT8530&WFCT8536 Gas Cooktop Clearance Circuit Diagram...
Page 14
WFCT8536 Circuit Diagram burner valve Right Front Right Rear Middle Front Middle Rear Left Front Left Rear Ignition pin Pulse ignitor INPUT: 120V/AC 60Hz HV-6pin L (Black wire) Power Plug N (White wire) PE(Green wire) WFCT8530&WFCT8536 Side &Back Panel Layout...
INSTALLING THE COOKTOP 1. Place the product on the desktop, and use 2. The countertop pan-head screw passes two cross-shaped flat-head screws to fix the desktop through the countertop fixing piece, and twist Adjust the horizontal direction of The vertical direction of the fixing device on the product base.
