- Page 1 GAS COOKTOP INSTRUCTION MANUAL Model No.: 30＂: CAHQ5B70/JZT-HQ5B70IAZXA 36＂: CAHQ5B90/JZT-HQ5B90XAZXA Website: www.casainc.com Contact Phone Number: 888-257-3857 Service Contact : service@casainc.com...
- Page 2 The instructions shall be marked with directions to the installer to leave them with the appliance and to the consumer to retain them for future reference. WARNING This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 3: Table Of Contents
Contents Cooktop Description Important Information Installation Installation Instructions Operating Instructions Care and Maintenance Trouble Shooting Safety Information This appliance shall be installed in accordance with the regulations in force and only used in a well- ventilated space. Read the manual before installing or using this appliance. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or, in Canada, the Natural Gas and Propane Installation Code, CSA B149.1. -
Page 4: Cooktop Description
Cooktop Description 30＂ : CAHQ5B70/JZT-HQ5B70IAZXA 36＂ : CAHQ5B90/JZT-HQ5B90XAZXA Operating Instructions Knob 1 is for semi-rapid burner D Knob 2 is for rapid burner B Knob 3 is for triple ring burner A Knob 4 is for rapid burner C Knob 5 is for auxiliary burner E Total heat input: 41800Btu/ hr 1. -
Page 5: Installation
Installation Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. The adjustment conditions for this appliance are stated on the label (or data plate). ... - Page 6 When using the gas cooktop for a long period of time, the ventilation should be improved, by opening a window or increasing the extractor speed. Do not use gas cooktop if it is in contact with water. Do not operate the gas cooktop with wet hands.
- Page 7 wooden strips; in the case of a joining cabinet surface, remember to leave a space of at least 1.77” x 22.05” at the back. When installing on a built-in oven without forced ventilation, ensure that there are air inlets and outlets for ventilating the interior of the cabinet adequately. Pressure Regulator Installation A: Cooktop air pipe joint B: Pressure Regulator...
- Page 8 Cut Out dimensions The dimensions of the cut-out are given in the diagram. (Dimensions are given in inch.) CAHQ5B70/JZT-HQ5B70IAZXA CAHQ5B90/ JZT-HQ5B90XAZXA Figure 4 WARNING Electrical Grounding Instructions This appliance is equipped with a three-prong grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle.
-
Page 9: Installation Instructions
Installation Instructions Overall dimensions For Model Width Depth CAHQ5B70/JZT-HQ5B70IAZXA 30 in 20.0 in CAHQ5B90/JZT-HQ5B90XAZXA 36 in 20.7 in Cut out dimensions For Model Width Depth CAHQ5B70/JZT-HQ5B70IAZXA 28.6 in 18.9 in CAHQ5B90/JZT-HQ5B90XAZXA 33.0 in 18.9 in Fixing fittings(hooks, screws) are provided to place the cooktop on worktop, the worktop measure 0.8”... -
Page 10: Operating Instructions
Operating Instructions Lighting Simply press the knob in, turn anticlockwise to ignition position (lightning icon). Press the ignition device and hold the knob till the burner is ignited Before releasing knob, ensure a flame is established. If the burner fails to ignite, put into off position and try again. ... -
Page 11: Care And Maintenance
Triple ring Semi rapid Auxiliary Pan dimensions Rapid burner burner burner burner inches (mm) 10200Btu/hr 12000Btu/hr 6000Btu/hr 3400Btu/hr Outside diameter - top ≤9 (229) ≤9 (229) ≤7 (178) ≤7 (178) Projected outside ≤8½(216) ≤8½(216) ≤6½(165) ≤6½(165) diameter - bottom WARNING As soon as a liquid starts boiling, turn down the flame so that it will barely keep the liquid simmering. - Page 12 Control Panel Sign OFF = gas valve is shut off Sign HI =largest flame Sign LO=smallest flame Sign = electric discharge for ignition The Burners The burner caps and crowns can be removed for cleaning. Wash the burner caps and crowns using hot soapy water, and remove marks with a mild paste cleaner.
-
Page 13: Trouble Shooting
Trouble Shooting Problem Corrective action • The gas ring burns • Check the main jet is not blocked and the burner crown is clear of unevenly food particles. • Check the burner cap and crown have been replaced correctly, e.g. after cleaning. -
Page 14: Safety Information
• Burner crown only emits • Check the burner crown holes are not blocked part of the fire • Check nozzle jet angle is not deviation. • Burning black smoke • Check if the gas type used is correct. • The knob LED does not •... - Page 15 WARNING The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed. Ensure that the kitchen is well ventilated especially when the appliance is in use. Keep natural ventilation holes open or install a mechanical ventilation device.
- Page 16 receptacle and a warning to the user to disconnect the electrical supply before servicing the appliance. Socket needs to be installed below the cooktop surface, and away from the fire source Gas Conversion Operating Instructions Figure 10 Gas type Nozzles Dia. Power Nozzles Dia.
- Page 17 8) Similarly, when use in NG status, turn the marked NG arrow upwards and tighten it to the screw cap (see Figure 10). Repeat the above operation. The outlet pressure requires to be 4 ± 1in w.c.. 9) After the conversion is completed, the conversion label in the accessory bag needs to be attached next to the original label.
