- Page 1 Meeting 360 Ultra Enhanced All-in-One Conference Camera User Manual Scan the QR code or visit our link to download the latest manual here: nexigo.com/manuals...
-
Page 2: Contact Information
If you have any problems, please contact us any time at cs@nexigo.com for further assistance. From all of us here at NexiGo, we want to thank you for your trust in us. We look forward to serving you again in the near future. Sincerely,... -
Page 3: What's In The Box
WHAT'S IN THE BOX? Lens Cover x 1 All-in-One Remote Control x 1 Conference (Requires 2 AAA batteries, not included) Power Adapter x 1 Camera x 1 9.8ft USB-C to 4.9ft USB-A to Storage bag x 1 USB-C Cable x 1 USB-C Cable x 1 User Manual x 1 Quick Start Guide x 1... -
Page 4: Camera Diagram
CAMERA DIAGRAM... - Page 5 1. Power Button Press and hold to power on Press to wake up or enter sleep mode in HDMI input mode 2. Volume + / - Buttons Press to adjust the speaker volume Press and hold both buttons for 3 seconds to switch between 1080p and 720p resolution 3.
- Page 6 BLUETOOTH REMOTE INTRODUCTION BLUETOOTH REMOTE DIAGRAM Power: Press to wake up or enter sleep mode. Left / Right / Up / Down: Navigate through system page. Return: Return to the previous page. Volume Down: Decrease the volume. Mode: Change the orientation that the camera uses to display meeting attendees.
- Page 7 In USB Input Mode, only buttons labeled 2, 5, 6, 4, 11, and 12 are functional. The Remote Control cannot power on the NexiGo Meeting 360 Ultra. Please power on the device manually, then press and hold the Power Button for at least 5 seconds to activate the camera.
-
Page 8: Setup Instructions
To power off the camera or enter standby mode, you must exit motion control mode. SETUP INSTRUCTIONS Before you plug in the NexiGo Meeting 360 Ultra, choose an Input Mode: USB, HDMI, or LAN Mode. This will determine how you set up the camera and how you will be able to use it. - Page 9 System Preferences > Security & Privacy > Privacy. 2. Select the NexiGo Meeting 360 Ultra Camera from the list of devices. 3. Grant permission to each app that needs camera access. 4. Open your video calling app and select the NexiGo Meeting 360 Ultra Camera as the active camera, microphone, and speaker.
-
Page 10: Lan Mode
In this mode, it’s unnecessary to use an external computer. Simply connect the NexiGo Meeting 360 Ultra to a TV or other display screen and start video conferencing directly through the camera. Setup 1. Use the provided USB-C to USB-C Cable to connect the camera to power. -
Page 11: Hdmi Mode
Download HDMI MODE CONNECTING TO NETWORK Wired network connection Plug an ethernet cable into the NexiGo Meeting 360 Ultra. To ensure that your camera is properly connected, check in Settings > My Device for network details. Wireless network connection Go to Settings >... - Page 12 USING THE APP STORE Use the built-in App Store to install common video conferencing apps. The apps you install will be available on the Home page. Before you can access the App Store, you must register your device with Google Service Framework (GSF). GSF ID Registration 1.
-
Page 13: Recording Meetings
4. Repeat the previous step to stop recording. SCREEN MIRRORING Miracast (Windows and Android) 1. Make sure that the NexiGo Meeting 360 Ultra is on the same network as your casting device. 2. On the NexiGo Meeting 360 Ultra, go to the... - Page 14 Swipe down to open your panel and select Cast. Airplay (Apple) 1. Make sure that the NexiGo Meeting 360 Ultra is on the same network as your Apple device. 2. Open Screen Mirroring on your Apple device and select NexiGo Meeting 360 Ultra XXXX from the list of devices.
- Page 15 Timezone: Set system time zone. Firmware Upgrade: Check for system updates. When the NexiGo Meeting 360 Ultra is in HDM Mode and connected to a network, it will automatically notify you if there is new firmware available. My Device: View device information, such as Device name, Legal information, Model &...
- Page 16 MEETING MODES When you're in a meeting, you can switch modes by pressing Mode Button on top of the camera. This will change the orientation your camera uses to display meeting attendees. Your Meeting Mode options are Discussion Mode, Presentation Mode, Lecture Mode,...
- Page 17 3. Lecture Mode 4. Global Mode Display the active speaker Display two 195° panoramic only. videos. Lecture Mode Global Mode 5. Patrol Mode Display the active speaker on the right. On the left, pan to display each attendee in turn. Patrol Mode...
- Page 18 Locking a Frame Easily adjust the image content of the frame and lock it. Use Left / Right / Up / Down Buttons to move the image content of the frame and use the Volume + / - Buttons zoom in or out. Press to confirm the locked image.
- Page 19 Unlocked frame Locked frame MULTI-CAMERA SETUP (LAN MODE) NexiGo Meeting Studio can integrate up to four video conferencing cameras at once, enabling image and audio capture throughout a wider area. The NexiGo Meeting Studio app enables new Meeting Modes and AI tracking to meet the unique requirements of larger...
- Page 20 HOW TO SETUP 1. Connect up to four NexiGo Meeting 360 Ultra cameras to the same network as the meeting host computer. Router Computer Cameras 2. Open the NexiGo Meeting Studio app on your computer. If you don’t have the app, you can download it from nexigo.com/pages/n2000-ultra-support...
- Page 21 Panoramic View Display a 360° view on top, the active speaker in the lower left corner, and individual attendees in the lower right.
- Page 22 Switch the Panoramic View You can switch the panoramic view from the different cameras when numerous cameras are connected. SN 000000001 SN 000000002 SN 000000003 SN 000000004 SN 000000001 SN 000000002 SN 000000003 SN 000000004 Speaker View Display the active speaker on the left and individual attendees on the right.
- Page 23 Gallery View Displays active speakers in equally-sized frames. Record Click Record to save the meeting as a video on your computer.
- Page 24 AI Tracking Tracks the active speaker using low-latency voice tracking and facial recognition. The camera pans smoothly to follow the speaker, even if they move out of frame. Zoom and Lock Adjust the zoom and position of any active speaker frame, then lock it into place.
-
Page 25: Specifications
SPECIFICATIONS Resolution 1920 x 1080, 1280 x 720 Software Zoom, Skype, Slack, GoToMeeting, Compatibility Microsoft Teams, Cisco Webex, BlueJeans, and other apps that support USB cameras. Video Format MJPEG Pickup range: 5.5M / 18ft Sensitivity: -38 dB Eight omnidirectional microphones Microphone AEC (acoustic echo cancellation) VAD (voice activation detection) -
Page 26: Safety Notes
Using other parts, accessories, or chargers not recommended by NexiGo may result in fire, electric shock, damage to the item, or personal injury. 4. The lenses on this camera are made of glass. If the lens is damaged, be sure to handle it carefully and keep it out of the reach of children. -
Page 27: Fcc Requirements
FCC REQUIREMENTS Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 28 Get in touch with FREE online services. facebook.com/letsnexigo...
