Summary of Contents for BN-Link BND-70/U97S
- Page 2 Operating Temperature:32℉-140℉ Storage Temperature: -4℉-140℉ Cycle Setting Range: 1 second to 23:59 minutes (ON duration and OFF duration) Photocell Sensor HH:Hours MM:Minutes Power Indicator LCD Display MM:Minutes SS:Seconds Add HH/MM Minus HH/MM Keeps the timer Set the time for the ‘ON’/ ‘OFF’ section running based on set ON/OFF times Opposite of day-only mode...
- Page 3 1. Set Cycle Time ‘ON’ Duration Time 1.1 When the programmed time exceeds 1 hour To set the hour, press to enter ‘ON’ time setting, the timer displays in HH:MM format. Press to set the ‘ON’ duration hours. (00~23) Press again to lock in the setting.
- Page 4 2. Set Cycle Time ‘OFF’ Time 2.1 When the programmed time exceeds 1 hour Complete the ‘OFF’ time setting using step 1.1 as a template. 2.2 When the programmed time is less than 1 hour Complete the ‘OFF’ time setting using step 2.1 as a template. After completing the setup, the device will display a countdown according to the set "ON"...
- Page 5 THREE CYCLE MODES...
- Page 6 1. Modify ON duration time or OFF duration time: 2. Toggle loop mode: 3. Reset:...
