MW MOUNTS MWMFM7044 Instruction Manual

Medium - large full motion mount

Advertisement

Quick Links

Medium - Large Full Motion Mount
Soporte de pared mediano - grande con
movimiento completo
Grand support à mouvement complet moyen
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
!
CAUTION:
THE MAXIMUM LOADING WEIGHT IS 70
LBS. USE WITH PRODUCTS HEAVIER THAN THE
MAXIMUM WEIGHT INDICATED MAY RESULT IN
INSTABILITY AND POSSIBLE PERSONAL INJURY.
!
PRECAUCIÓN:
EL PESO MÁXIMO DE CARGA ES
70 LBS. EL USO CON PRODUCTOS MÁS PESADOS QUE
EL PESO MÁXIMO INDICADO PUEDE PROVOCAR
INESTABILIDAD Y POSIBLES LESIONES PERSONALES.
ATTENTION :
!
LE POIDS DE CHARGEMENT
MAXIMAL EST DE 70 LB. L'UTILISATION AVEC DES
PRODUITS PLUS LOURDS QUE LE POIDS MAXIMAL
INDIQUÉ PEUT ENTRAÎNER UNE INSTABILITÉ ET DES
BLESSURES CORPORELLES.
Max Screen Size: 63"
Tamaño máximo de la pantalla: 63"
Taille maximale de l'écran : 63 po
V9
Reduce
Reducir
Réduire
Reuse
Reutilizar
Réutiliser
Recycle
Reciclar
Recycler
P1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MWMFM7044 and is the answer not in the manual?

Questions and answers

Summary of Contents for MW MOUNTS MWMFM7044

  • Page 1 Medium - Large Full Motion Mount Reduce  Reducir Soporte de pared mediano - grande con Réduire Reuse  movimiento completo Reutilizar Grand support à mouvement complet moyen Réutiliser Recycle  INSTRUCTION MANUAL Reciclar Recycler MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: THE MAXIMUM LOADING WEIGHT IS 70 LBS.
  • Page 2 QUESTIONS? ¿PREGUNTAS? DES QUESTIONS ? NEED HELP? PLEASE CALL ¿NECESITA AYUDA? LLAME BESOIN D’AIDE ? VEUILLEZ APPELER 1-602-674-1000 DISCLAIMER - WARNING INFORMATION DESCARGO DE RESPONSABILIDAD - INFORMACIÓN DE ADVERTENCIA AVIS DE NON-RESPONSABILITÉ - INFORMATIONS D’AVERTISSEMENT Disclaimer -. MW PRODUCTS has extended every effort to ensure to accuracy and completeness of this manual. However, MW PRODUCTS does not claim that the information covers all installation and or operational variables.
  • Page 3 MONITOR PLATE AND ADAPTERS PLACA DEL MONITOR Y ADAPTADORES PLAQUE DU MONITEUR ET ADAPTATEURS Use diagrams to determine which mounting configuration is needed to attach monitor plate (with or without adapters) to the back of TV. Please check TV wall mounting compatibility before proceeding with installation.
  • Page 4 HARDWARE PART NUMBERS NÚMEROS DE PIEZA DE LOS ACCESORIOS DE MONTAJE NUMÉROS DE PIÈCE DE MATÉRIEL M4 x 12 M6 x 15 M8 x 15 M4 x 30 M6 x 30 M8 x 30 M8 x 50 STEEL WASHER SPACER ARANDELA DE ACERO ESPACIADOR RONDELLE EN ACIER...
  • Page 5 STEP 1- REMOVE MONITOR PLATE FROM MOUNT AND REMOVE COVERS FROM WALL PLATE PASO 1- RETIRE LA PLACA DEL MONITOR DEL SOPORTE Y RETIRE LAS CUBIERTAS DE LA PLACA DE PARED ÉTAPE 1 - RETIREZ LA PLAQUE DU MONITEUR DU MONTAGE ET RETIREZ LES PROTECTIONS DE LA PLAQUE MURALE Remove monitor plate from wall plate Retire la placa del monitor de la placa de la pared Retirez la plaque du moniteur de la plaque murale...
  • Page 6 STEP 2B- IF NEEDED, ATTACH MONITOR ADAPTERS TO MONITOR PLATE (See page 3 for options) PASO 2B: SI ES NECESARIO, FIJE LOS ADAPTADORES DEL MONITOR A LA PLACA DEL MONITOR (consulte las opciones en la página 3) ÉTAPE 2B - SI NÉCESSAIRE, FIXEZ LES ADAPTATEURS DU MONITEUR À LA PLAQUE DU MONITEUR (Voir la page 3 pour consulter les options) Connect monitor plate with adapters to TV Conecte la placa del monitor con los adaptadores al televisor Fixez la plaque du moniteur avec des adaptateurs sur le téléviseur...
  • Page 7 STEP 2D- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE HARDWARE KIT ARE TOO LONG PASO 2D- USE LA ARANDELA DE ACERO M8 SI LOS TORNILLOS PHILLIPS DEL JUEGO DE ACCESORIOS DE MONTAJE SON DEMASIADO LARGOS ÉTAPE 2D - UTILISEZ LA RONDELLE EN ACIER M8 SI LES VIS CRUCIFORMES DU KIT DU MATÉRIEL SONT TROP LONGUES Diagrams show three possible options for using additional washers if hardware screws are too long to properly tighten into the back of the TV.
  • Page 8 STEP 3A- WOOD STUD (CONCRETE INSTALLATION SKIP TO 3B) PASO 3A- MONTANTE DE MADERA (INSTALACIÓN EN PARED DE CONCRETO SALTE AL PASO 3B) ÉTAPE 3A - MONTANT EN BOIS EN CAS D’INSTALLATION SUR UNE STRUCTURE EN BÉTON, PASSEZ À L’ÉTAPE 3B) Find stud and mark edge and center locations Encuentre el poste de madera y marque la ubicación de los bordes y el centro Trouvez les emplacements des montants et marquez les bords et les centres...
  • Page 9 STEP 3 B – SOLID CONCRETE PASO 3 B - CONCRETO SÓLIDO ÉTAPE 3B - BÉTON Level Solid Concrete Drill bit Nivel Concreto sólido Broca Mettre à niveau Béton Foret DRILL BIT NOT INCLUDED BROCA NO INCLUIDA FORET NON INCLUS 3/8”...
  • Page 10 STEP 4- ATTACH PANEL TO MOUNT PASO 4- FIJAR EL PANEL AL SOPORTE ÉTAPE 4 - FIXEZ L’ÉCRAN AU SUPPORT Hang with TV attached Heavy, Assistance Cuelgue con el televisor fijado Required Accrochez avec la télévision attachée ¡PESADO! Necesitará ayuda para realizar esta operación TRES LOURD ! Cette etape requiert deux personnes...
  • Page 12 Congratulations! Installation complete ¡Felicidades! Instalación completa Félicitations ! Installation terminée WARRANTY INFORMATION INFORMACIÓN SOBRE LA GARANTÍA INFORMATIONS DE GARANTIE ■ This warranty applies to US Residents who purchase from an authorized MW PRODUCTS Dealer. MW PRODUCTS products are covered against defects in materials and workmanship for 5 years.
