- Page 1 Exquisite products, wonderful life Projector User Manual Mini projector Version:H11_A230630...
-
Page 3: High-Temperature
Precautions ● Before using the product, please read the instruction manual ca- refully and keep it in a safe place for emergency use. ● Please use the machine carefully, and do not drop or hit it at a high altitude during transportation to avoid damage to the original machine. -
Page 4: Packing List
Packing List Projector*1 Remote Control * 1 HDMI Cable*1 Power Supply * 1 User Manual * 1... - Page 5 Appearance and function 1. Front view Remote control Focus Power Source Navigation + OK Menu Home Return Vol- Vol+ Mute...
- Page 6 2. Back view DC input port Earphone output port USB port HDMI input port...
- Page 7 Device connection instructions DVD,computer, games console Speakers or HDMI cable headphones When the projector is connected to input devices such as game consoles, DVDs, computers, or TV sticks through an HDMI cable, you must choose the HDMI channel.
- Page 8 Signal source equipment 1. Connect to power supply 2. On/Off Power on step 1. Projector connect to power supply; 2. Turn on the Porjector power button or button of the remote control.
- Page 9 Launcher debugging When the display is abnormal, please adjust according to the following diagram. Correct showing Focus knob Picture blurred Horizontal placement Picture tilted Facing the screen Picture crooked...
-
Page 10: Installation
Installation 1.Click“ ”key ,select the “Projection Mode” in the“Option”. 2. Select the corresponding projection mode based on the projector installation. Four projection mode Front Desktop Rear Ceiling Rear Desktop Front Ceiling... -
Page 11: Bluetooth Settings
Bluetooth settings 1. Click“ ”key , select“BT Setting”，and turn on Bluetooth. Turn on Bluetooth 2. Click“Search bluetooth”，Search for Bluetooth devices name. 3. Select Bluetooth device and connect. - Page 12 Projector is connected to USB Projector connected to USB flash drive, Select MOVIE, MUSIC, and PHOTO to play the corresponding files separately. Image files JPEG,PNG,BMP Supporting Audio files MP3,WMA,AAC,WAV documents Video files MP4,MKV,AVI,MEP,VOB,3PG ※: This projector does not support movies with Dolby sound and DTS. When directly playing a video with Dolby or DTS on a USB drive, there may be no sound or images, but it can be decoded by a computer or other playback device and connected to an HDMI channel for playback.
-
Page 13: Product Features
Product Features 117*93*136mm Dimension 0.65KG Projector Weight Power Supply DC IN: 12V Power Consumption 48W FAT ,FAT32,NTFS USB Format HDMI Input(480P/720P/1080P) Signal Ports Projection distance and size 200” 100” 60” 30” 5.56m 2.78m 1.67m 0.83m The projection ratio is 1.25:1 and the optional distance is 2.7 ft to 20ft. If it exceeds this range, the projected picture will be unclear or the brightness will be too low, which will affect the viewing experience.
