Summary of Contents for Bauhn AP5W-0624
- Page 1 User Guide 5-Way Surge Protector with Wi-Fi & Meter Reading tempo.org/support Model: AP5W-0624 1300 002 534 Product Code: 715900 06/2024...
- Page 2 Have you got everything? Note: only one power board (white/black) is supplied Unpack the box and make sure all of these items are there: A. 5-Way Surge Protector with Wi-Fi & Meter Reading B. User Guide C. Warranty Certificate...
-
Page 3: Product Overview
Product Overview Overload Circuit Breaker (Resettable) Protects against current overload at 10 amp Power On/Off Switch Press to supply/cut off power to the sockets. Note: Please turn off “Child Lock” in the Tuya app to unlock the power button. Please use app to control the 5 independent switches separately. -
Page 4: Getting Started
Tuya Smart App The smart Wi-Fi power board connects your home Wi-Fi network to your appliances for easy control of home automation, as well as saving energy and providing home security. The “Tuya Smart” or “Smart Life” application along with your smart power board controls any connected electrical appliances via your smart device. - Page 5 Connecting your Power Board to Wi-Fi 1. Ensure your smart phone has connected using 2.4G Wi-Fi before starting the connection process. Note: The smart power board supports 2.4G only. 2. Go to the app, tap “Home” and then tap “+” in the upper right corner and tape “Add Device”.
- Page 6 Easy Mode 6. Plug the power board into a power outlet, press and hold the On / Off button for 5 seconds or until the blue LED blinks quickly (twice per second), the power board is reset and it is ready to connect in Easy Mode.
- Page 7 10. In AP mode your smart phone can connect directly to the power board through the temporary Wi-Fi hotspot named “SmartLife-xxxx”. Once connected, return to the app screen and the app will automatically transfer your home 2.4G Wi-Fi SSID and password to the power board.
- Page 8 Controlling the Outlet with the App BAUHN APSW-0624 Controlling the Outlet with the App: 1. In the Apps main Switch 2 screen: Select the connected smart power Switch 3 board. On the following Switch 4 screens, you can control the power boards on/...
-
Page 9: Troubleshooting
Troubleshooting • Power Board should be put into connection mode. (AP Mode) LED status • Follow the procedure above on connecting your Indicator Power Board to Wi-Fi. flashes slowly • When the connection is successful, the LED will stay ON. •... - Page 10 No power • Try other sockets. If the other sockets have power output from output, it’s probably the contact of one faulty one of the socket that is loose or not connected; avoid using sockets that socket. • Check that the power switch is turned on (you can try to turn it on and off a few times to make sure No power it’s switched on)
-
Page 11: Specifications
Specifications Input 230-240Vac, 50Hz 10A Total Loading Max. 2400W Surge Protection 175J Maximum Energy USB-C Output: 5V/3A MAX USB Output USB-A Output: 5V/2.4A MAX USB Output: total 5V/4.5A MAX Power Cable 1.5m Mass 620g Dimensions (W x H x D) 390 x 70 x 34mm... - Page 12 General Safety Warnings For the safety of yourself and others, follow all instructions and take notice of all the warnings. When adhered to, these safety precautions can reduce the risk of fire, electric shock and injury. This product complies with Australian Safety standard AS/NZS 3105, AS/NZS 61558.2.16 to ensure the safety of the product.
- Page 13 • The power board is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction by a person responsible for their safety. •...
- Page 14 General Safety Warnings • Unpack the power board and keep the original packaging carton and materials in a safe place. It will help prevent any damage if the power board needs to be transported in the future, and you can use it to store the power board when it is not in use.
- Page 15 Responsible disposal of the packaging The packaging of the product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a suffocation hazard for babies and young children, please ensure all packaging materials are out of reach and are safely disposed of.
- Page 16 Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 17 Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user- generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair,...
- Page 18 NOTES...
- Page 19 NOTES...
- Page 20 Give us a call What? You mean this User Guide didn’t have ALL the answers? Speak to us! We’d love to help you get up and running as quickly as possible. Call our After Sales Support on 1300 002 534. Operating hours: Monday-Friday, 8:30am-6pm;...
