- Page 1 USER MANUAL SETUP GUIDE RS-TOUCH SERIES EME1F1-005-R2 IN-SESSION ALERTWERKS COMMON WIRED AIRFLOW SENSOR WITH 5 FT SETTINGS CABLE 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Chapter 1: Introduction And Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL CHAPTER 1: INTRODUCTION AND SPECIFICATIONS SUPPORT 1.877.877.2269 1.1 INTRODUCTION The AlertWerks Wired Airflow Sensor is a device that registers airflow in areas where consistent flow is needed, such as in cabinets and racks where the consistent operation of a fan is critical to the safe operation of electronic equipment. - Page 3 Yes, you can extend the airflow sensor using a standard CAT5 LAN cable. The total run length of this sensor is roughly 98 feet (30 meters). On / Off Type Airflow Sensor Black Box is only shipping the On / Off type of Airflow sensor. 1.877.877.2269 BLACKBOX.COM...
- Page 4 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL CHAPTER 2: CONFIGURATION SUPPORT 1.877.877.2269 2.2 CONFIGURING THE AIRFLOW SENSOR ON YOUR ALERTWERKS WIRED HUB Plug the sensor into one of the RJ-45 ports on the rear panel of the unit. Point your browser to the unit’s IP address (default, 192.168.0.100) and then log in as the administrator using your administrator password (default is “public”).
- Page 5 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: CONFIGURATION TECHNICAL SUPPORT 1.877.877.2269 shown in Figure 2-2 below: FIGURE 2-2: ADDITIONAL TABS, INCLUDING SETTINGS In the settings tab shown in Figure 2-2, make sure that the sensor is online. Then you can re-name your Airflow sensor, adjust the rearm and sensitivity settings, and change the Normal State.
- Page 6 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL CHAPTER 2: CONFIGURATION SUPPORT 1.877.877.2269 To calibrate the sensor follow the instructions on the screen and then click on the calibrate button as shown in Figure 2-3 below: FIGURE 2-3: CALIBRATE NOW BUTTON After clicking on the Calibrate button, a reminder will be displayed as shown in Figure 2-4 below: FIGURE 2-4: CALIBRATION CONFIRMATION BUTTON Click on the OK button to begin the airflow sensor’s calibration.
- Page 7 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: CONFIGURATION TECHNICAL SUPPORT 1.877.877.2269 After clicking on the Status Filters tab, you can enable or disable the email alerts and traps, set the Continuous Time settings to eliminate false warnings, set the Minimum time between each Email or Trap, and set the Day and Time filter as shown in Figure 2-5 below: FIGURE 2-5: STATUS FILTERS TAB AlertWerks Wired Hubs...
- Page 8 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL CHAPTER 2: CONFIGURATION SUPPORT 1.877.877.2269 After clicking on the Airflow sensor, the Normal Settings tab will be displayed, as shown in Figure 2-7 below: FIGURE 2-7: NORMAL SETTINGS SCREEN On the Normal Settings tab, you can rename the sensor, rename the Status, and change the Normal State to the Presence or Absence of airflow.
- Page 9 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: CONFIGURATION TECHNICAL SUPPORT 1.877.877.2269 To calibrate the sensor, follow the instructions on the screen and then click on the calibrate button as shown in Figure 2-8 below: FIGURE 2-8: CALIBRATION INSTRUCTIONS SCREEN After clicking on the Calibrate button, a reminder will be displayed as shown in Figure 2-9 below: FIGURE 2-9: CALIBRATION CONFIRMATION MESSAGE 1.877.877.2269...
- Page 10 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL CHAPTER 2: CONFIGURATION SUPPORT 1.877.877.2269 Click on the OK button to begin the airflow sensor’s calibration. 1.877.877.2269 BLACKBOX.COM...
-
Page 11: Appendix A: Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: HEADLINE TECHNICAL APPENDIX A: REGULATORY INFORMATION SUPPORT 1.877.877.2269 A.1 FCC STATEMENT This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 12: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: HEADLINE TECHNICAL APPENDIX A: REGULATORY INFORMATION SUPPORT 1.877.877.2269 A.4 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. -
Page 13: Appendix B: Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 14 NEED HELP? LEAVE THE TECH TO US LEAVE THE TECH TO US LIVE 24/7 LIVE 24/7 TECHNICAL TECHNICAL SUPPORT SUPPORT 1.877.877.2269 1.877.877.2269 © COPYRIGHT 2016 BLACK BOX CORPORATION. ALL RIGHTS RESERVED. © COPYRIGHT 2022. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. EN_IOT_MANUAL_EME1F1-005-R2_REV1_2211.PDF...
