EDER ELLFS6FW-11 Service Manual

Drum washing machine
Hide thumbs Also See for ELLFS6FW-11:
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
Drum washing machine

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELLFS6FW-11 and is the answer not in the manual?

Questions and answers

Related Manuals for EDER ELLFS6FW-11

Summary of Contents for EDER ELLFS6FW-11

  • Page 1 Service Manual Drum washing machine...

  • Page 2: Table Of Contents

    Contents Contents I. Precautions.....................2 II. Appearance and technical parameters of the washing machine....6 III. Factory detection..................7 IV. Wiring diagram, electric circuit schematic diagram and water circuit diagram......................8 V. Programming steps..................12 VI. Disassembly method for the main components........15 VII.

  • Page 3: Precautions

    After-market Service Manual for Drum Precautions Washing Machine I. Precautions Please note the following safety precautions when performing troubleshooting and parts replacement during maintenance: 1.1 Safety precautions 1.1.1 The use of original parts for the washing machine has safety features such as non-flammability and pressure resistance.
  • Page 4 After-market Service Manual for Drum Washing Machine Symbol Meaning indicates that the maintenance technician and nearby persons may die or be seriously injured due to improper work, or that the user may die or be seriously injured due to a product defect caused by Warning the execution process of the work of the technician.
  • Page 5 After-market Service Manual for Drum Use the specified service parts when repairing the product. Washing Machine Otherwise, a malfunction or defect may occur. In addition, a short circuit, fire or other danger to the customer Use service parts may occur. Warning After repairing, measure the insulation resistance between the charging part (power cord plug) and the non-charging metal...
  • Page 6 After-market Service Manual for Drum Do not pour or immerse electrical parts into water or liquid Washing Machine solutions. Otherwise, an electric shock or fire may occur. Do not splash water Wipe off the dust that is attached to the power cord plug. Dust may cause a fire.

  • Page 7: Appearance And Technical Parameters Of The Washing Machine

    Top cover Detergent box Control panel Adjustable bottom foot Front door Filter cover Package size (wide x depth x height): 650mmx520mmx870mm Technical parameter Model ELLFS6FW-11 Rated voltage AC220V~AC240V/50Hz 0.1-1MPa Water pressure Clean ratio Rated power 1950W Rated washing capacity (kg)

  • Page 8: Factory Detection

    After-market Service Manual for Drum Factory detection Washing Machine III. Factory detection After connecting the power plug, do not press the 【Power】 key (or press the 【Power】 key to turn on the machine and then turn off the machine), and press the【Start/Stop】 ,【Reservation】 ,【Speed】 , 【Speed】...

  • Page 9: Wiring Diagram, Electric Circuit Schematic Diagram And Water Circuit Diagram

    After-market Service Manual for Drum Wiring diagram, electric circuit schematic diagram and water circuit diagram Washing Machine IV. Wiring diagram, electric circuit schematic diagram and water circuit diagram 1. Wiring diagram Control panel Inlet valve Sensor Heater Filter Drainage pump Water level switch Door switch Motor...
  • Page 10 After-market Service Manual for Drum Wiring diagram, electric circuit schematic diagram and water circuit diagram Washing Machine 2、Electric circuit schematic diagram Page 9...
  • Page 11 After-market Service Manual for Drum Wiring diagram, electric circuit schematic diagram and water circuit diagram Washing Machine Page 10...
  • Page 12 After-market Service Manual for Drum Wiring diagram, electric circuit schematic diagram and water circuit diagram 3. Water circuit diagram Washing Machine Drum inlet pipe Drainage Inlet pipe pipe Water level sensor Drum drainage Washing box pipe Drainage pump Inlet valve Page 11...

  • Page 13: Programming Steps

    After-market Service Manual for Drum Programming steps Washing Machine V. Programming steps 1. Click the icon shown below to display the following interface, and the programming of the computer board is enabled 2. Select this programmer, the red mark in the figure corresponds to the computer board 5V Page 12...
  • Page 14 After-market Service Manual for Drum 3. Click “File”, select “open project”, and select “R5F100FE” Washing Machine 4. Click “Browse”, select the program to be programmed and display the selected program Page 13...
  • Page 15 After-market Service Manual for Drum Washing Machine 5. Click “Start” to start programming, if the following green font is shown as the last line, it indicates that the programming is successful Page 14...

  • Page 16: Disassembly Method For The Main Components

    After-market Service Manual for Drum Disassembly method for the main components Washing Machine VI. Disassembly method for the main components 1. Tools required Tool Model Notes Heater (1), outer cylinder (12), transport 8 mm, 10mm 13mm, bolts (5), motor (2), balance block (9) Sleeve 17mm tools...
  • Page 17 After-market Service Manual for Drum Disassembly method for the main components Washing Machine 2. Disassembly diagram This is a standard disassembly diagram, which may slightly differ from the actual product. Disassembly and assembly may be used for reference. Note: Unplug the power cord of the product before disassembling and assembling the product. Diagram Description Tool...
  • Page 18 After-market Service Manual for Drum Washing Machine Description Tool Component Diagram Open the door to find the location of the door A flat seal clamp spring and pick up the spring with screwdriver a flat screwdriver. Pull the door seal clamp from the bottom to the top by hand and remove the door seal clamp.
  • Page 19 After-market Service Manual for Drum Washing Machine Press down with one hand and pinch the buckle with another hand to separate it from the box; Hand Take out the door lock Description Tool Component Diagram Remove Remove the 4 transport bolts from the rear sealing the rear Sleeve and a door.
  • Page 20 After-market Service Manual for Drum Component Diagram Description Tool Washing Machine Remove Sleeve the front Remove the three bolts from the front balance balance block with the sleeve block 1. Use a Phillips screwdriver to loosen the screws Remove Use a screwdriver to insert it in and A Phillips on the door seal clamp in the counterclockwise the door...
  • Page 21 After-market Service Manual for Drum Washing Machine Component Diagram Description Tool A Phillips Remove the screwdriver, drainage pump Remove the parts simply by removing the 4 needle-nose screws on the drainage pump. pliers and hand Remove the Sleeve and door seal Remove the belt pulley simply by removing the hand bolts with the sleeve.

  • Page 22: Inspection Of Electronic Components

    After-market Service Manual for Drum Inspection of electronic components Washing Machine VII. Inspection of electronic components Inspection of electronic components Picture (The pictures shown Serial Test Part here is indicative Range Reference number description only, the actual product may differ) Frequency Water level test for the...

  • Page 23: Fault Diagnosis And Treatment Methods

    After-market Service Manual for Drum Fault diagnosis and treatment Washing Machine VIII. Fault diagnosis and treatment methods Note: Please confirm the above items before maintenance Phenomenon Items to be confirmed Does the power plug come off ◆ The washing Is the regional line out of power ◆...
  • Page 24 After-market Service Manual for Drum Fault diagnosis and treatment Washing Machine Common fault diagnosis and analysis Error code Fault description Treatment methods 1. Check if the faucet is open and the water flow size 2. Hang up the drainage pipe 3.
  • Page 25 After-market Service Fault diagnosis and treatment Manual for Drum Washing Machine 1. Check if the wire harness terminal is firmly plugged or replace the wire harness Water heating pipe fault 2. Replace the heating pipe 3. Replace the computer board (or dry the computer board) 1.

  • Page 26: Troubleshooting

    After-market Service Manual for Drum Troubleshooting Washing Machine IX. Troubleshooting E1. Water feeding timeout fault Water feeding time-out Is the faucet open Open the faucet Is the water pressure in the range of Wait until the water pressure 0.1~1MPa meets the standard Is the height of the hung drainage pipe Hang up the drainage pipe...
  • Page 27 After-market Service Manual for Drum Washing Machine E2. Door lock fault Door is not locked Is the door closed Close the door again properly Is the wiring Correctly connect PCB with between PCB and the door lock door lock correct Check if the door Replace the door lock lock is intact...
  • Page 28 After-market Service Manual for Drum Washing Machine E3. Motor fault Motor does not work Reduce the amount of laundry, If the laundry is too and restart power-on operation much or stuck after power-off and a period of cooling Is the wiring Reliable and correct wiring between PCB and motor correct...
  • Page 29 After-market Service Manual for Drum Washing Machine E4. Drainage timeout fault Drainage timeout The suspension height of the drainage pipe Hang up the drainage pipe exceeds 100cm Is the water pump Clean the filter clogged Is the water pump in Replace the water pump good condition Replace the PCB...
  • Page 30 After-market Service Manual for Drum Washing Machine E5. Water overflow/water level sensor fault E5. Water overflow/water level sensor fault Is the inlet valve Replace the inlet valve intact Is the water level Replace the water level sensor intact sensor Replace the PCB board Page 29...
  • Page 31 After-market Service Manual for Drum E6. Water heating pipe fault Washing Machine Water heating pipe fault Is the wire harness Plug in the wiring harness of the heating pipe properly properly plugged Is the water heater Replace the water heater intact Replace the PCB board...
  • Page 32 After-market Service Manual for Drum Washing Machine E7. Water heating temperature sensor fault E7. Water heating temperature sensor fault Is the wire harness Plug in the wiring loose harness properly Is the sensor intact Replace the water heater Replace the PCB board Page 31...

  • Page 33: Exploded Diagram And Details

    After-market Service Manual for Drum Exploded diagram and details Washing Machine X. Exploded diagram and details Page 32...
  • Page 34 After-market Service Manual for Drum Washing Machine Page 33...
  • Page 35 After-market Service Manual for Drum Washing Machine Page 34...
  • Page 36 After-market Service Manual for Drum Washing Machine Page 35...
  • Page 37 After-market Service Manual for Drum Washing Machine Page 36...
  • Page 38 After-market Service Manual for Drum Washing Machine Page 37...
  • Page 39 After-market Service Manual for Drum Washing Machine Page 38...
  • Page 40 After-market Service Manual for Drum Washing Machine Page 39...
