imarflex CVO-230FT Quick Start Manual

SPECIFICATION:
MODEL NO. : CVO-230FT
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 1500 watts
BOX DIMENSION : 440*405*380mm
UNIT DIMENSION : 405*385*350mm
GROSS WEIGHT : 8.9Kg
UNIT WEIGHT : 7.7Kg
IMPORTANT SAFEGUARDS:
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. Read all instructions carefully.
2. Before using the oven toaster, check if the voltage indicated corresponds with the convenience
outlet (230Va.c.).
3. Do not use a two-way socket with another appliance.
4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be
replaced with the same type and size or bring the unit to the nearest authorized service center.
5. Put the unit on stable surface; keep it away from the edge of counter to avoid accident.
6. Keep curtains, furniture, flammable materials, etc. away from the unit and from the convenience
outlet where the unit is plugged in.
7. To protect against electric shock, do not immerse the unit in water or any other liquid.
8. Do not place the appliance near gas stove or electric stove.
9. The unit needs at least 10 cm clearance space on all sides and at least 30 cm above. This
is to allow adequate air circulation.
10. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances by a person responsible for
their safety.
11. Children should be supervised to ensure that they do not play with the appliance.
12. Do not immerse the unit in water.
13. Do not use this unit other than its intended use.
14. Avoid touching the appliance surface while cooking is in progress or even after use. While the
appliance is in use avoid the glass from getting wet to avoid breakage.
15. Use of accessories or equipment not supplied by the manufacturer may cause damage or
malfunctioning of your appliance or result in injuries.
16. Switch off the appliance before removing or replacing its accessories.
17. Minor metal contraction sound may occur during operation but this is normal.
18. For household use only; not intended for any business purposes.
19. In case of malfunctions, please bring the unit to the nearest Authorized Imarflex Service Center.
20. This appliance is not intended for outdoor use.
21. Save this instruction for future reference.
22. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this
appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
DESCRIPTION OF PARTS:
CONTROL PANEL
Time Setting Temperature Setting Function Setting Toast Timer Setting
1. Timer Setting - Set the desired time for all function except for the Toast function.
2. Toast Timer Setting - Set the desired time for Toast function only (Light, Medium, Dark) bread
outcome.
3. Temperature Setting - Select the desired temperature from 0°C to 230°C.
Note: For Toast function: Set the temperature to 140°C.
4. Function
a. Air-Fry – Use for chicken, french fries, pata, fish, etc. It makes the outcome crispy.
Toast
b. – Use for toasting breads.
c. Upper Heater - It is normally use for cooking top part of the foods, reheating, pizza, broil,
etc.
d. Lower Heater - Use for baking breads.
e. Upper & Lower Heater - Use for grilling meats, seafood, etc.
f. Convection & Upper Heater
reheating, pizza, broil, etc.; the fan is working together with the upper heater only.
Convection & Both Heater
g.
together with the upper and lower heater.
HOW TO USE:
NOTE: For the first use, preheat the oven for at least 3 to 5 minutes until burnt smell and light smoke
is gone. This is to prevent this smell and smoke mix to the food.
1. Place the unit on flat surface.
2. Check if the timer and function selector switch is at OFF position before plugging the oven into the
convenience outlet. Plug the unit.
3. Set the Upper & Lower Heater to your desired temperature.
Note: If you will only use one heater, make sure to turn OFF the other heater.
4. Set the function switch to desired setting.
5. For baking, use edible oil or butter to keep the food from sticking into the pan.
6. Turn the timer to pre-heat the unit for at least 5 minutes or as required by the cooking recipe.
Note: If you need to set the time below 10 minutes, set the timer switch more than 10
minutes first then set to desired time setting.
7. Place the food on the grill rack or tray and close the door. Be careful when putting food, the unit is
hot.
8. Turn the timer switch to desired cooking time.
NOTE: The cooking time and result of the food to be cooked may depend on the amount
and size, trial is advisable to get the desired setting and doneness of the food.
9. A beep sound will be heard and the unit will stop cooking once the set time is finished.
CAUTION: Do not touch the unit when it's hot.
Tips: For better performance, let the unit cool down for 15 minutes after every hour of use.
Air-Fry Function
1. Plug the unit into the convenience outlet.
2. Place the grill rack inside the oven.
3. Preheat the unit for at least 5 minutes at 230°C.
4. After preheat, place the food inside the air fryer basket.
5. Put the air fryer basket on the top of the grill rack inside the unit and close the door.
Note: Be careful when putting bread, the unit is hot.
6. Set function.
7. Select the desired time and temperature.
8. Once the cooking cycle ends, a beep sound will be heard and the unit will stop cooking once the
set time is finished.
9. Remove the air-fryer basket from the unit.
10. Unplug the unit after every use.
Toast Function
1. Plug the unit into the convenience outlet.
2. Place the grill rack inside the unit.
3. Preheat the unit for at least 5 minutes at 230°C.
4. After preheat, place the sliced bread inside the unit and close the door.
Note: Be careful when putting bread, the unit is hot.
5. Set the temperature to 140°C.
6. Set the function.
7. Select the desired time in
8. Once the cooking cycle ends, a beep sound will be heard and the unit will stop cooking once the
set time is finished.
9. Remove the toasted bread from the unit.
10. Unplug the unit after every use.
- It is normally use for cooking top part of the foods,
- This setting is use for baking cakes; the fan is working
. Select light, medium or dark.
