  • Page 1 MULTIFIT PALLET FORKS OPERATOR’S MANUAL PM-000135-F...
  • Page 2 MY.DIGGA.COM MY.DIGGA.COM DECAL IS APPLIED TO THE DECAL TO BE APPLIED TO ATTACHMENT WINDOW OF MACHINE ACCESS OPERATOR MANUALS RISK ASSESSMENTS AND MORE PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 To the Purchaser .
  • Page 4 PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...

  • Page 5: To The Purchaser

    Make sure the equipment is operated only by trained individuals that have read and understood this manual . If there is any portion of this manual or function you do not understand, contact your local authorized Digga dealer or the manufacturer to obtain further assistance . Keep this manual available for reference . Provide the manual to any new owners and/or operators .

  • Page 6: Product Identification

    PF-001130-1500 PF-001130-1800 PF-001130-4000 Your Digga Multifit Pallet Fork model provides important information about the product. Compare the model engraved on the serial plate to the list above . • This manual does not cover non-multifit Pallet Forks/Bale Spears. See manual PM-000021.
  • Page 7 Digga replacement parts . Substitute parts may not meet the standards required for safe and dependable operation . Use of non genuine Digga parts will void warranty and Digga accept no liability what so ever for consequential or special damages. All service must be performed by qualified professionals. Contact your local Digga dealer for details .

  • Page 8: Preparation For Use

    Preparation for use To avoid any inconvenience before operation, please check that you have received the following items which you may have ordered. Items may differ depending on type of machine the Pallet Fork is to be fitted to. DESCRIPTION Pallet Fork Frame Pallet Fork Tynes Tyne Bars...

  • Page 9: Safety Precautions - General Information

    Safety Precautions - General Information You must understand all safety statements shown on your attachment and in this manual . Especially note the information called out by the designations shown below . Follow these safety precautions, when operating or ⚠ maintaining the attachment .
  • Page 10 Safety Precautions - General Information Know where utilities are • Observe overhead electrical and other utility lines . Be sure the equipment will clear them . • Before starting any digging project, lodge an enquiry with BYDA (Before you Dig Australia) or your local utilities location service for the identification of buried electrical, telephone, cable wires, gas, water and sewer lines are likely to be present .
  • Page 11 Safety Precautions - General Information Remove paint before welding or heating. • When sanding or grinding paint, avoid breathing the dust . Wear an approved respirator . If you use solvent or paint stripper, remove stripper with soap and water before welding . Remove solvent or paint stripper containers and other flammable material from area.
  • Page 12 Safety Precautions - General Information • Always carry loads close to the ground and do not exit the machine with the loader arms raised . • Do not exceed rated operating capacity (ROC) of the host machine, as machine may become unstable resulting in loss of control.
  • Page 13 Safety Precautions - General Information • All operations must be stopped in the event of local thunderstorm or lightning activity . During operation, weather conditions shall be monitored, operations shall cease during electrical storms or when electrical storms are imminent . Ground personnel and bystanders . •...
  • Page 14 Use extra care when loading or unloading the attachment on to a trailer or truck . No responsibility for loss or damage to persons or property in any regard can be attributed to Digga . PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...

  • Page 15: Safety - Working With The Attachment

    Complete a Risk Assessment Your Digga Multifit Pallet Fork is a versatile machinery attachment, capable of performing its tasks in a safe and effective manner. To ensure the safety of operators and others, it is important to document the work at hand for hazard and risk .
  • Page 16 . NOTE For any additional safety information please see “Risk Management Booklet”. To obtain a copy of this document please contact Digga Head Office. PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...
  • Page 17 • Do not make any modifications to your Digga attachment. • When making repairs use only competent and experienced service agents and use only genuine Digga parts . For fasteners, use only properly rated parts . • Replacement parts must also have safety signs attached .

  • Page 18: Safety - Decal Labels

    Safety - Decal Labels This section provides a glossary of safety labels found on your Digga Multifit Pallet Fork. These labels are important! Become familiar with both their meaning and location prior to operating the Pallet Fork . Ensure that each label is clean, visible, and legible at all times .
  • Page 19 Safety - Decal Labels FALL HAZARD SAFE WORKING LOAD SWL DIAGRAM ⚠ ⚠ ⚠ D A N G E R C A U T I O N C A U T I O N Do not allow persons over the forks. Do not exceed the attachment Safe Do not exceed the attachment Safe Do not ride on the attachment.
  • Page 20 SERIAL TAG DE-000256 (Australia & New Zealand) ⚠ NOTE WA R N I N G Scan the QR-code to access my.digga. This product contains chemicals com and find manuals, safety known to the State of California to information, guides and more.

  • Page 21: Safety Decals - Location

    DESCRIPTION DE-002064-1 Read Operator's Manual DE-000650 Crush Hazard DE-000651 Fall Hazard DE-000652 Safe Working Load DE-000471 SWL 1500kg DE-000850 QR-Code my .digga .com DE-000256 Serial Tag DE-000646 Pinch/Crush Point DE-000049 Digga Logo PF-001130-1800 (DKIT1020) ITEM ORDER CODE DESCRIPTION DE-002064-1 Read Operator's Manual...
  • Page 22 DE-000650 Crush Hazard DE-000651 Fall Hazard DE-000652 Safe Working Load DE-000543 SWL 4000lbs DE-000850 QR-Code my .digga .com DE-000542 Serial Tag DE-000646 Pinch/Crush Point DE-000049 Digga Logo DE-000538 Proposition 65 PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...

  • Page 23: Before Use

    Digga replacement parts . Use of non-genuine Digga parts ⚠ will void warranty and Digga will accept no liability what so ever for consequential damages as a result thereof . D A N G E R Safety first!! Read and understand the safety instructions before beginning any maintenance.
  • Page 24 Before Use ⚠ WA R N I N G Escaping fluid under pressure as low as 100 PSI can have sufficient force to penetrate the skin up to 4" (100mm) away causing serious personal injury. Fluid escaping from a very Cardboard small hole can be almost invisible.

  • Page 25: Commissioning Procedure

    For fitment of the Pallet Fork to other machines you must first contact your DIGGA dealer and receive written confirmation to ensure you do not incorrectly fit the attachment to a machine with lower rated load capacities than what the product was designed for .
  • Page 26 Commissioning Procedure NOTE It is important to make sure the locking mechanism on your quick attach is engaged, therefore locking the attachment onto the machine. 5 . Lower the unit to the ground and remove the key from the parent machine . 6 .
  • Page 27 Commissioning Procedure Unpacking 1 . Slide cardboard packaging upwards and remove it (Figure 1) . Ensure packaging is disposed of in accordance with federal, state and local regulations . 2 . Ensure pallet fork frame is sitting stable on timber frame and then cut the straps (Figure 2) . ⚠...
  • Page 28 Commissioning Procedure Mounting the safety guard 1 . Remove the front nuts and bolts from both sides of the frame (Figure 4) . ⚠ 2 . Swing the safety guard upright (Figure 5) . WA R N I N G Ensure hands are well clear from the pinch points (Figure 5).
  • Page 29 Commissioning Procedure Mounting tynes 1 . Unscrew the bolts holding the two tyne rods in place (Figure 7) . 2 . Slide the tyne rods outwards just enough so that the tynes can be fitted (Figure 8). 3 . Move the first tyne in place and insert the rod through the tyne hole. (Figure 9). Figure 7 Figure 8 Figure 9...
  • Page 30 Commissioning Procedure 4 . Align the tyne rod hole and the hole located on the frame (Figure 10) . 5 . Tighten the bolt (Figure 11) . Ensure the bolt head is facing upwards (Figure 12) .Align the tyne rod hole and the hole located on the frame (Figure 10) .
  • Page 31 Commissioning Procedure 7 . Move the second tyne into place and insert the rod through the tyne hole (Figure 13) . 8 . Align the tyne rod hole with the hole located on the frame and tighten bolt (Figure 14) . Ensure the bolt head is facing upwards (Figure 12) .

  • Page 32: Operating Instructions

    Operating Instructions ⚠ D A N G E R Safety first!! Read and understand the safety instructions before operating the attachment and moving any loads. Failure to obey the following procedures could result in death or serious injury. 1 . Remove bucket as per Machine Operators Manual . 2 .
  • Page 33 Operating Instructions NOTE Tynes are matched and serial coded as a pair, any damage to an individual tyne will require a new pair to be purchased. Tynes are not sold separately. ⚠ D A N G E R Do not exceed the lifting capacity of machine. The Pallet Fork is part of the machine's Safe Working Load (SWL). Refer to the host machine operator's manual.
  • Page 34 Operating Instructions How to adjust tyne width Ensure the equipment is safely immobilised before making any adjustment or maintenance to the attachment . When adjusting tynes, please place hands in correct position to avoid potential pinching . Figure 2 Figure 1 Method 1: Pull locking pin and Method 2: Lower the pallet fork twist to lock open.

  • Page 35: Maintenance

    Maintenance Greasing The Pallet Fork has no grease nipples . Lubricate the tyne bar with multipurpose grease frequently to allow tynes to slide easily when adjusting width . Lubricate the locking pins with lubricant spray frequently . Visual Inspection Inspect the attachment every day for wear, cracks and damage . Check if all fasteners are present and tighten . Do not use the Pallet Fork if there are any issues with the frame or missing/defective parts .

  • Page 36: Technical Specifications

    Technical Specifications MODEL CAPACITY LENGTH HEIGHT WIDTH WEIGHT PF-001130-1500 1500 kg 1314mm (51 .7") 964mm (38") 1170mm (46") 138 kg (304 lbs) PF-001130-1800 1800 kg 1464mm (57 .6") 964mm (38") 1170mm (46") 157 kg (346 lbs) PF-001130-4000 4000 lbs 1464mm (57 .6") 964mm (38")
  • Page 37 Tynes are not sold separately. Only replace tynes with the type specified for ⚠ your attachment . D A N G E R Do not exceed the Safe Working Load stated in the attachment serial tag. PF-001130-1500 PF-001130-1800 or PF-001130-4000 1800 kg 1500 kg 3965 lbs...

  • Page 38: Spare Parts

    For spare parts of your Pallet Fork, obtain the serial number from the aluminium serial tag located on the frame of the Pallet Fork . The serial number allows Digga to trace all production and service records . Ensure all service and maintenance is performed by an authorized Digga service agent and all service records are kept .
  • Page 39 Spare Parts For further information on spare parts, please contact one of the Digga sales offi ces shown below, or contact your local authorised Digga dealer . DIGGA INTERNATIONAL SALES OFFICES ASIA PACIFIC NORTH AMERICA EUROPE DIGGA HEAD OFFICE - BRISBANE...

  • Page 40: Troubleshooting

    Troubleshooting Pallet Fork TROUBLE POSSIBLE CAUSE REMEDY Lack of grease Grease Pivot pins bent or damaged Replace Pivot Pins Fork tynes do not slide Locking bolts tighten Loosen locking bolts Attachment falls off Locking mechanism on the loader not engaged Ensure that the attachment is locked on before use PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...

  • Page 41: Warranty Statement

    This warranty is in lieu of all other warranties expressed or implied and there are no warranties of merchantability or of fitness for a particular purpose . In no event shall Digga be liable for consequential or special damage . Digga’s liability for any and all losses and damages to buyer, resulting from any cause whatsoever, including Digga’s negligence, irrespective of whether...
  • Page 42 Notes PM-000135-F Operator's Manual - Multifit Pallet Fork - Nov 2023...
  • Page 43 Notes...
  • Page 44 PM-000135-F...
