MODEL 1036-13
STAINLESS STEEL FLUSH
EMBALMING STATION
CAUTION
Inspect unit and all components
for any loosening that may have
occurred during shipping
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
Technical Users' Manual
Installation and Operating Instructions
CAUTION
DO NOT USE CLEANERS
CONTAINING CHLORINE WHEN
CLEANING STAINLESS STEEL
ATTENTION
All images and Drawing in this manual
may not represent your model.
Refer to your particular project for
exact specifications
ISO Doc. #OM1036-13 (REV. D)
MARCH 2021
Advertisement
Table of Contents
Related Manuals for MORTECH 1036-13
Summary of Contents for MORTECH 1036-13
- Page 1 Technical Users’ Manual Installation and Operating Instructions MODEL 1036-13 STAINLESS STEEL FLUSH EMBALMING STATION CAUTION CAUTION DO NOT USE CLEANERS Inspect unit and all components CONTAINING CHLORINE WHEN for any loosening that may have CLEANING STAINLESS STEEL occurred during shipping...
-
Page 2: Safety Information
• Is unit draining properly? WARNING • Are all nuts, bolts, and pins secured in place? It is crucial that any work performed on Mortech If unit has an issue contact Mortech Manufacturing Inc. Manufacturing Inc. manufactured items are carried out... -
Page 3: Installation
WALL “Z” BAR MOUNTING proper location and per the project specifications. Drawings BRACKET (DRILL IN FIELD) from Mortech for utilities is provided with the submittal packet "Z" Mounting Bracket WALL “Z” BAR Holes need to be drilled in field MOUNTING... - Page 4 Installation 1036-13 Stainless Steel Flush Embalming Station Electrical Conduit BLUE TAPE (COLD WATER) RED TAPE (HOT WATER) BLUE TAPE (COLD WATER) RED TAPE (HOT WATER) CONNECT TO CONNECT TO Hot Water Figure-G1 CONNECT TO Cold Water Connect to building drain...
-
Page 5: Electrical Connection Instructions
Power Disconnect To Be GREEN L1 B ommended or Supplied: (GROUND) L2 W ELECTRICAL Figure-I To Be LINE 2 1036-13 Flush Embalming Station GREEN CTRICAL CONNECTION ~120VAC/60hz/1ph (NEUTRAL) 1036-13 Flush Embalming Station LINE 1 L1 BLACK (15A CIRCUIT) lied: (GROUND) -
Page 6: Parts Listing
Flush Embalming Station HOT/COLD MIXING FAUCET w/TOP DECK HIGH SPOUT T&S #B-0270 HOT/COLD MIXING VALVE T&S #B-0300 FLUSH BUTTON SLOAN WATER SAVER HYDRO ASPIRATOR MORTECH #LW480 / FISHER #3700 (2) HAND SPRAY ASSEMBLY w/FLEXIBLE HOSE SPRAY HOSE COUPLER MORTECH #SH10 (HOSE) - Page 7 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station Toto Wall Mounted Elongated Toilet Features: • Elongated bowl gives a modern and comfortable look and feel extending out an extra 1-1/2” compared to a round configuration • Made from vitreous china delivering strength and aesthetic appeal •...
-
Page 8: Troubleshooting Guide
Standard Design Components 1036-13 Stainless Steel Flush Embalming Station SLOAN VALVES Specifications +1036-13 • High chloramine resistant synthetic rubber WALL THICKNESS diaphragm with linear filtered bypass and vortex cleansing action • Metal non hold open push button • 1” I.P.S. wheel handle stop... - Page 9 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station Water Saver, 3.5 gpf (13.2 Lpf) IMPORTANT- Laws and Regulations requiring Low Consumption Fixtures (1.6gpf Water Closets and 1.0gpf Low Consumrtion, 1.6 gpf (6.0 Lpf) Urinals) prohibit the use of higher flushing volumes.
- Page 10 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station MIXING FAUCET with SPRAY HOSE ASSEMBLY Wall mount vertical mixing faucet with polished chrome plated brass body, swivel outlet (less nozzle), compression cartridges with spring checks, 4-arm handles and 1/2” NPT female inlets. Certified to ASME A112.18.1/CSAB125.1, NSF 61-Section 9 and NSF 372.
- Page 11 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station SPRAY HOSE ASSEMBLY SPRAY HEAD: Model #10820 SPRAY HANDLE: Model #2913 SPRAY HOSE: Model #SH10 Features • 1/4” ID X 10 ft. MPT swivel and rigid • Outstanding coil memory • Oil and fuel resistant Wash hands after handling.
-
Page 12: Backflow Preventer
Standard Design Components 1036-13 Stainless Steel Flush Embalming Station BACKFLOW PREVENTERS Temperature and Pressure Maximum Pressure 150psi (10.3 bar). ATTENTION INSTALLER Maximum Temperature 140°F (60°C). Before installing, flush out pipe lines to remove scale and Annual inspection of all water system safety and control other foreign matter. - Page 13 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station DOUBLE PANTRY MIXING FAUCET with 18 INCH SWING NOZZLE T&S MODEL #B-0270 T&S MODEL #B-0270 MARCH 2021 MFGISO DOC. #OM1036-13 (REV. D)
- Page 14 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station HYDRO-ASPIRATOR A - VACUUM 3/4-11.5 FAUCET THREAD Mandatory operation requirements: B - 1.500-28 THREAD C - 1/8-27 NPS PIPE THREAD • Minimum 1/2” supply line D - 3/4-32 THREAD • Minimum 60 lbs of water pressure •...
-
Page 15: Vacuum Breaker
Standard Design Components 1036-13 Stainless Steel Flush Embalming Station VACUUM BREAKER Size: 3⁄4” (20mm) thread Installation Thread Vacuum Breaker onto Aspirator, tighten. Vacuum Vacuum Breaker is a line of unique vacuum breakers Breaker is secured by tightening the set screw. specially made to permit the attachment of portable hoses to hose thread faucets. -
Page 16: Technical Specifications
Standard Design Components 1036-13 Stainless Steel Flush Embalming Station LIQUID-TUFF ™ (Type LFNC-B) Technical Specifications UL Liquidtight Flexible Non-Metallic Conduit Scope This specification covers AFC Cable Systems, Inc. UL LIQUID-TUFF™ Integral Liquidtight Flexible Non-Metallic Conduit, Type LFNC-B designed for use in wet, dry or oily... - Page 17 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station GFCI Features and Benefits: Lockout Action • Automatically tests every time the RESET button is pushed. • Expanded wiring options with nine back-wire holes (two for each line and load connection plus one for ground with an •...
- Page 18 Standard Design Components 1036-13 Stainless Steel Flush Embalming Station RECEPTACLE COVER Type: Vertical Color: Gray • Heavy Duty Die Cast Metal Construction • Patented Quick-Fit™ Key Hole Mount for Easy Installation • Patented Universal-Fit™ Adapter Technology • Lockable Tab • Premium Powdercoat Finish •...
-
Page 19: Maintenance Instructions
Stainless Steel Equipment Maintenance MAINTENANCE INSTRUCTIONS had time to oxidize or decompose. The preferred solvent is one that does not contain chlorine, such as acetone, methyl The unit requires regular maintenance and follow the alcohol, and mineral spirits. manufactures directions. EFFECTIVE CLEANING METHODS DISINFECTING AND CLEANING Commercial Cleaners - Many commercial cleaners... -
Page 20: Maintenance Record
Maintenance Record MAINTENANCE RECORD Date... -
Page 21: Training Record
Training Record TRAINING RECORD Date... -
Page 22: Warranty
PARTS AND SERVICE Information in this Manual is subject to change without notice Customer relations and product support are important and does not represent a commitment on the part of Mortech aspects of Mortech Manufacturing. Inc. Manufacturing. Inc. Mortech Manufacturing. Inc. assumes...
