GAMMA2 Nano Click User Manual

user manual
READ ALL INSTRUCTIONS BEFORE OPERATING UNIT. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
components
1) Lid
2) Food Hopper
3) Wheel
4) Base
5) Bowl
6) Hopper Slide Lock
7) Wheel Slide Lock
LID
FOOD HOPPER
section 1: product assembl y
sTEP 1: wheel assembl y
Ensure WHEEL SLIDE LOCK
is in the unlocked position.
Insert WHEEL into BASE, aligning
end of shaft with opening of base.
Rotate shaft clockwise into position.
Slide WHEEL SLIDE LOCK
to locked position.
manual PET FEEDER
WHEEL
SLIDE LOCK
BASE
BOWL
sTEP 2: FOOD hopper assembl y
WHEEL
Ensure HOPPER SLIDE LOCK is in the
unlocked position.
Insert front tab of FOOD HOPPER into
the slot on the BASE. Rotate hopper
to insert the rear tab into the base.
Note: Make sure wheel cut-out on
the FOOD HOPPER is on the same
side as the WHEEL.
Slide HOPPER SLIDE LOCK
to locked position.
HOPPER
SLIDE LOCK
