Dish Playmaker Manual

DISH
Playmaker
®
Winegard is excited to announce the launch of the
newest DISH Playmaker
®
Portable Automatic Antennas that work exclusively
with DISH SD/HD programming.
High-Strength, Military Grade Aluminum Reflector
Durable design to handle portable and mobile use
Hybrid Stepper Motors
that are fast and precise.
Lightweight, Robust Design
for optimal performance
Ideal with Pay-As-You-Go programming
through Winegard.
Features and Benefits
The DISH Playmaker and DISH Playmaker Dual antennas work exclusively
with DISH HD Solo receiver technology and programming. Powered through
the receiver, the DISH Playmaker is optimized for single receiver use, requiring a
single coax connection. The DISH Playmaker Dual is built with two coax ports
to accomodate two receivers for two channel viewing.
Please note: While all non-local programming is accessible with a DISH
Playmaker and DISH Playmaker Dual, only locals that are broadcast from a
western arc satellite will be available.
With a USB Digital OTA Tuner, an over-the-air antenna may be integrated
with the Wally receiver. The USB Digital OTA is available from DISH on
®
dishformyrv.com and is required to connect an over-the-air antenna and
receive local programming that originates in the user's location.
Winegard offers optional mount options for the DISH Playmaker and DISH
Playmaker Dual automatic portable satellite TV antennas that raise the
antenna off of the ground for better reception and security. These mounts are
built to withstand the harsh outdoor environment.
DISH Playmaker and DISH Playmaker Dual have a two year parts,
one year labor warranty.
Robust Design
Re-engineered high-strength, military-grade aluminum alloy reflector for
n
maximum durability resulting in increased signal strength performance
of at least 20%
Reliable, high-performance stepper motors provide speed and precision
n
Lightweight, low profile antenna made from robust materials for optimal
n
performance
Easy-grip handle included for effortless carrying
n
Powered via coaxial cable from the primary receiver (120 volts AC)
n
DISH Playmaker / DISH Playmaker Dual
DISH
Playmaker
/
® ®
and DISH Playmaker
® ®
-
Reliable, high-performance motors
-
High-grade materials and low-profile
-
Activation available
Dual
®
Portable Automatic Satellite TV Antennas
Dual
®
-
ACCESSORIES
IMPROVE RECEPTION AND SECURITY
Mounts create additional locations
for better satellite visibility
(sold separately)
• TR-1518
Temporary ground mount with
adjustable height and leveling
settings of 14.5" – 22".
Quickly disassembles for
compact storage.
RK-4000
•
Permanently mount the DISH
Playmaker to the vehicle roof.
Includes feet, cable entry plate
and mounting hardware.
PL-7000
DISH Playmaker antenna, white
PL7000R DISH Playmaker antenna with
Wally receiver
™
PL-8000 DISH Playmaker Dual antenna, white
PL-8035 DISH Playmaker Dual antenna, black
Tripod Mount
Roof Mount
Dimensions: 16" diameter
13" height, 7 pounds
