Page 1: Product Model
ProPlex CodeClock USER MANUAL... -
Page 2: Manual Edition Notice, Copyright, Disclaimer
TMB has confidence in the accuracy of the document information herein but assumes no responsibility or liability for any loss occurring as a direct or indirect result of errors or exclusions whether by accident or any other cause. ProPlex CodeClock User Manual v1 July 2024... -
Page 3: Table Of Contents
LTC OUT Mode Timecode Generator Screen Brightness Output Level Clock Color Auto Color Custom Color Pre-roll Frames Device Information Firmware Updater Menu Map Cleaning and Maintenance Technical Specifications Limited Warranty Information Return Procedure Contact information ProPlex CodeClock User Manual v1 July 2024... -
Page 4: Overview
Overview Safety Precautions The ProPlex CodeClock is a member of our LTC Device system which is designed to generate, distribute and monitor timecode. Our rugged, compact mini-enclosure design is perfect for desktop programmers to throw in bag while also being flexible enough to install in a rack with an optional RackMount Kit. With custom color selection on a clean dot-matrix display, the CodeClock is the ultimate tool to synchronize and monitor timecode streams. -
Page 5: Full Dimensional Wireframe Drawings
Full Dimensional Wireframe Drawings ProPlex CodeClock User Manual v1 July 2024... -
Page 6: Setup
• QR Code downloads card Power Requirements The ProPlex CodeClock is powered via USB-C cable connected to any standard 5 VDC wall charger or computer USB port. The included cable retainer is a threaded insert which attaches to the USB-C cable. It provides some... - Page 7 ProPlex CodeClock User Manual v1 July 2024...
-
Page 8: Installation
ProPlex RackMount Kits are available for both Single-Unit and Dual-Unit mounting configurations To fasten the rack ears or joiners to the ProPlex PortableMount chassis, you must remove the two chassis screws on each side at the front of the chassis. These same screws are used to securely fasten the RackMount ears and joiners to the chassis For dual-unit configurations, both sets of front and rear chassis screws will be used... - Page 9 The Dual-Unit Small RackMount Kit has TWO short rack ears plus TWO joiners. The diagram below depicts the completed installation of the RackMount Kit. This configuration requires the TWO center joiners attached at both front and rear ProPlex CodeClock User Manual v1 July 2024...
-
Page 10: Installing The Dual Joiners
These links are designed to nest into each other and are secured with the included screws and threaded holes. Each link piece is identical. Simply rotate the joining link and line up the installation holes to install on either the left or right side of the corresponding unit. ProPlex CodeClock User Manual v1 July 2024... -
Page 11: Operation
The ProPlex CodeClock can be easily configured with the onboard OLED Display and navigation buttons on the front of the unit Home Screens The CodeClock has 2 HOME SCREENS that display di erent parameters of incoming timecode streams. Cycle between these screens by pressing either the button... -
Page 12: Main Menu
The asterisk indicator will denote the currently selected output level Timecode Generator The CodeClock can generate clean, high output LTC out of the three isolated XLR3 ports (located on the rear of each unit) Use the button, then confirm selection with the... -
Page 13: Screen Brightness
The asterisk indicator will denote the currently selected output level Clock Color The CodeClock allows the user to customize the display color of the RGB segments or use our ‘auto’ display Use the button, then confirm with the button to choose between the two color modes. -
Page 14: Auto Color
RGB intensity values are represented by the format: 0x (r-value) (g-value) (b-value) Where 0xF00 is full red, 0x0F0 is full green and 0x00F is full blue When desired color is displayed, highlight the OK button on screen and press to save ProPlex CodeClock User Manual v1 July 2024... -
Page 15: Pre-Roll Frames
Use the button to highlight YES, then press button to enter Bootloader mode. The CodeClock screen should display a note to “Use USB to Update Firmware” to let you know it is ready Now the device should respond to updates sent from the Tiva Programmer software –... -
Page 16: Menu Map
Dust build-up in connector ports can cause performance issues and can potentially lead to further damage during normal wear and tear CodeClock devices need occasional cleaning to maintain best performance, especially units used in harsher environmental conditions The following are general cleaning guidelines: •... -
Page 17: Technical Specifications
4.5 W Max. Operating Temp. Dimensions (HxWxD) 1.72 x 7.22 x 4.42 in [43.7 x 183.5 x 112.3 mm] Unit Weight 1.2 lbs. [0.54 kg] Shipping Dimensions Shipping Weight 1.4 lbs. [0.64 kg] ProPlex CodeClock User Manual v1 July 2024... -
Page 18: Limited Warranty Information
Limited Warranty Information ProPlex Data Distribution Devices are warranted by TMB against defective materials or workmanship for a period of two (2) years from the date of original sale by TMB. TMB’s warranty shall be restricted to the repair or replacement of any part that proves to be defective and for which a claim is submitted to TMB before the expiration of the applicable warranty periods. -
Page 19: Return Procedure
TMB reserves the right to use its own discretion to repair or replace product(s) and determine the warranty status of any equipment. ProPlex CodeClock User Manual v1 July 2024... -
Page 20: Contact Information
Providing products and services for the industrial, entertainment, installation, defense, broadcast, research, telecommunications, and signage industries. Servicing the global market from o ces in Los Angeles, London, New York, Toronto, and Beijing. ProPlex CodeClock User Manual v1 July 2024...
