- Page 1 Qube X Unpressurized hot water storage tank and drain back reservoir Solartechnik Prüfung Forschung Installation and Operation Manual Ƚ SQ-WDHSU ( 3 heat exchangers ) Ƚ SQ-WDHS ( 2 heat exchangers ) Ƚ SQ-WD ( 1 heat exchanger )
-
Page 2: Table Of Contents
CONTENTS Introduction General Informations Installation and assembly Drawings and dimensions Accessories Warranty... -
Page 3: Introduction
Dear customer, have been provided in this guide We strongly believe that the products bought and on the Qube X water heater to warn any from us will contribute the comfort at your person(s) of potential hazards. homes and increase it’s energy efficiency. -
Page 4: General Informations
GENERAL INFORMATION Models and Usage QubeX water heaters are available as: 1. SQ-WDHSU - Hygienic Hot Water + Solar Drain Back + Heat Pump + space heating 2. SQ-WDHSU - Hygienic Hot Water + Solar Pressurized + Heat Pump 3. SQ-WDHS - Hygienic Hot Water + Solar Drain Back + Heat Pump 4. - Page 5 Depending on the materials used in the heating system, Solarico recommends that pH value should lie between 8,2 and 10. Disclaimer Solarico is not liable for damage resulting from any but the device’s intended use. Solarico is not liable in case of: •...
- Page 6 GENERAL INFORMATION Safety instructions WARNING: When using electrical appliances, basic safety precautions to reduce the risk of fire, electric shock, or injury to persons should be followed, including: • This water heater must be grounded. Connect only to properly grounded outlet. •...
- Page 7 GENERAL INFORMATION NOTE: Mixing valves are available for reducing point of use water temperature by mixing hot and cold water in branch water lines. Contact a licensed plumber or the local plumbing authority for further information. DANGER: Hotter water increases the potential for Hot Water SCALDS.
- Page 8 GENERAL INFORMATION Maintenance The functionality of pressure safety valves, that Solarico recommends to be installed , must be periodically tested. The water may drip from the discharge pipe of the pressure-relief device and that this pipe must be left open to the atmosphere.
-
Page 9: Installation And Assembly
INSTALLATION AND ASSEMBLY Instructions to installer During installation and operation, the country specific requirements and regulations must be observed: • Regulations and norms concerning the fitting of the installation with safety devices. • Safety during installation - personal protective equipment. WARNING: The preperation, installation and commissioning must be performed by an authorized professional installer / service. - Page 10 INSTALLATION AND ASSEMBLY Shipping and packaging We recommend delivering your storage tank directly to the installation site on the pallet and in the original packaging. During transport and installation, depending on the weight, appropriate safety equipment must be used in accordance with Directive 2006/42/EC.
- Page 11 INSTALLATION AND ASSEMBLY Assembly NOTE: Compliance with local accident prevention guidelines,legal requirements, directives and guidelines is mandatory. WARNING: The preperation, installation and commissioning must be performed by an autho- rized professional installer / service. NOTE: It is our recommendation an expansion vessel to be installed on the domestic cold water supply line, between the tank connector “A”...
- Page 12 INSTALLATION AND ASSEMBLY Sensors assembly and wiring Sensors for automation of the heating system are not part of Solarico storage tanks. Depending on the type, Solarico storage tanks are provided by maximum 3 sensor sleeves. All sensors can be installed from the top side of the tank, under plastic cap of the heater.
- Page 13 INSTALLATION AND ASSEMBLY Liquid Level Control ( optional ) The QubeX tank could have special level control window, for better visibility of the liquid level. Filling of the tank QubeX should be filled on the Drain Back top connector I. The filling is finished when the liquid appear in the top side connector D - over flow.
-
Page 14: Drawings And Dimensions
DRAWINGS AND DIMENSIONS S2,S3,S5,Sth S2,S4,S5,Sth Qube X D (diameter) (mm) H1 (height) (mm) H (height) (mm) 1100 1100 a (width) (mm) Pivot measurement (mm) 1320 1460 Gross tank capacity Weight (with exchangers) (kg) Connections I,J 5/4” S2 Solar sensor position... - Page 15 DRAWINGS AND DIMENSIONS CAUTION: The following schemes are purely illustrative and does not replace technical planning. SQ-WDHSU SQ-WDHS SQ-WD...
- Page 16 - Heating valve - External temperature sensor - Solar system station - DHW sensor - Floor temperature limiter QUBE X & PRIMARY CIRCUIT CONTROL Heat Pump heating - ON S4 < 40°C S4 > 55°C WINTER Solar heating - ON...
- Page 17 - Solar panels sensor 4. Solar system pump station S2, S3, S4 - Storage tank sensors 5. Solar thermal panels QUBE X & PRIMARY CIRCUIT CONTROL (S4 + 10°C) < S1 and S4 < Tset WINTER / SUMMER Solar heating - ON heating and shower regime * Heat Pump high pressure protection if Solar DHW heating is set above 55°C...
-
Page 18: Accessories
ACCESSORIES Stainless steel electric heating elements with integrated thermostat Qube X tank is equipped with 3kw top electrical heater. On demand of the customer it is possible to insert plus one. Outlet connection of electric heating element is 6/4” Storage Tank... - Page 19 ACCESSORIES Connection scheme for stainless steel electric heating elements with integrated thermostat WARNING All installation operations, including manual adjustments, must be fulfilled by a qualified specialist following all safety conditions.
-
Page 20: Warranty
WARRANTY Manufacturing defects and materials guarantee Manufacturer expressly guarantees that the products it manufactures shall be free from defects in materials and workmanship which can prevent from normal operation under proper and normal use, installation and maintenance for the intended functions of the products, for a period set out in the warranty certificate of the respective water heater model you have bought. - Page 21 Technical Department. Euroterm d.o.o. , Lece Koteski 50, Industrial area Biljana, 7500 Prilep, R. North Macedonia, phone +389 48 419 415; fax +389 48 422 981 , e-mail: info@solarico.eu, web: www.solarico.eu...
- Page 22 WARRANTY Limitation of liability • Manufacturer is not liable before the customer, neither directly nor indirectly, for any non-fulfillment or delay at applying the warranty obligations which might originate from external pressure of other circumstances outside Manufacturer. • The liability of Manufacturer under this Warranty Certificate is limited to the abovementioned obligations and up to the sum in accordance with the purchase receipt of the product to be claimed;...
- Page 23 NOTES...
- Page 24 Type Serial number Tank: 30 years Guarantee Heat Exchangers: 10 years Manufacturing date Signature Euroterm d.o.o. Lece Koteski 50 Industrial area - Biljana, Prilep Republic of North Macedonia tel. +389 48 419 415 fax +389 48 422 981 e-mail: info@solarico.eu...
