- Page 1 INSTRUCTION MANUAL # 0901082 VERSION: MANUAL 2024-0710 DATE: Ultra Micro-Pro UMP-100L...
-
Page 2: Table Of Contents
Ultra Micro-Pro UMP-100L Instructions TABLE OF CONTENTS Declaration of Conformity ..................3 Introduction ......................4 Circuit Board Diagram ..................4 Installation ......................5 Plumbing ......................5 Probe Installation ....................6 Electrical ....................... 6 Probe Operation ....................7 Probeless Operation ..................... 8 Wiring Diagram ..................... -
Page 3: Declaration Of Conformity
Ultra Micro-Pro UMP-100L Instructions Kt-HGHT, LJLC A Unit Q:f Oo�p,oratlon 20531 Crescent IBa'i' ID r. Lake Forest, CA 92630R8825, U.S.A Phone: (949)595-4800 Fax: (!M9)695R4801 WiWt,kn"glntequip.com DEC1ll.ARATION OF CONFORMlifY il"yp8JMorl e l Number; l.ll'MP Clac & sh::: The slg !egar a ulhorilles slale that the above menlioii11ed... -
Page 4: Introduction
Ultra Micro-Pro UMP-100L Instructions INTRODUCTION Ultra Micro-Pro UMP-100 warewash system provides the versatility of probe or probeless detergent control through advanced microprocessor design while retaining overall operational simplicity. CONCENTRATION OR RECHARGE ALARM DELAY OR INITIAL CHARGE SLIDE SWITCH SETTINGS POTENTIOMETER SETTINGS •... -
Page 5: Installation
Ultra Micro-Pro UMP-100L Instructions PLUMBING INSTALLATION Mount the unit (using suitable hardware) with the LIQUID DETERGENT PLUMBING provided bracket in the accessory kit. Try to keep the unit within three feet from the final rinse line to avoid (1) Install the provided bulkhead fitting through a wall long tubing runs. -
Page 6: Probe Installation
Ultra Micro-Pro UMP-100L Instructions PROBE INSTALLATION (if required) REMOTE ALARM (1) Install the probe in the wash tank below the water A remote 3 - 28 VDC alarm may be wired to the “alarm” level. It should be away from incoming water terminals on the circuit board. -
Page 7: Probe Operation
Ultra Micro-Pro UMP-100L Instructions PROBE OPERATION • With the detergent power “on”, the conductivity probe senses detergent concentration. When concentration drops below the setpoint, the control automatically turns on detergent feed. • Low and high concentration ranges allow easy setting on all types of water conditions. -
Page 8: Probeless Operation
Ultra Micro-Pro UMP-100L Instructions PROBELESS OPERATION • Controls detergent concentration without a probe, based on timed detergent feed. • Initial charge time feeds detergent concentration setpoint when dishmachines are initially filled. • Recharge time feeds detergent to maintain detergent SLIDE RIGHT TO ACTIVATE setpoint as rinse water dilutes the dishmachine. -
Page 9: Wiring Diagram
Ultra Micro-Pro UMP-100L Instructions WIRING DIAGRAM SYSTEM WIRING DIAGRAM Version: F (Manual #0901082) 2024-0710... -
Page 10: Assembly Diagram
Ultra Micro-Pro UMP-100L Instructions ASSEMBLY DIAGRAM Version: F (Manual #0901082) 2024-0710... - Page 11 Ultra Micro-Pro UMP-100L Instructions NOTES: Version: F (Manual #0901082) 2024-0710...
-
Page 12: Warranty Information
Knight, LLC reserves the right, however, to discontinue or change specifications or design at any time without notice SCAN and without incurring any obligation whatsoever. KNIGHT LLC is part of the CFS Technologies family of brands. www.knightequip.com | cfstech.com 8504 MacArthur Dr., North Little Rock, AR 72118 USA • 501-895-2820 | 800-999-2820...
