All Traffic Solutions StatTrak-E Quick Start Manual

S T -E Q
TAT RAK
T C S
RAFFI LOUD
The StatTrak-E by All Traffic Solutions is a discreet, wireless traffic data collection device that provides
law enforcement authorities and traffic engineers with detailed statistics and reports on vehicle counts and
speeds by class of vehicle, and sends alerts for issues such as low battery, tampering, and high speed.
For roadside installations, StatTrak-E captures traffic data simultaneously for up to two lanes of traffic,
moving in the same or opposite directions. For median installations, StatTrak-E captures up to four lanes of traffic data,
bidirectionally. For TraffiCloud subscribers, data uploads automatically to the cloud for reporting purposes.
Initial StatTrak-E setup
Once you receive your StatTrak-E, you'll need to perform the following initial setup:
Step 1: Charging the StatTrak-E on the next page
Step 2: Signing in to TraffiCloud for the first time on the next page
Step 3: Choosing a Site for your StatTrak-E on page 3
Step 4: Mounting a solar panel on page 5
Step 5: Installing the mounting brackets on page 6
Step 6: Mounting and aiming the StatTrak-E on page 7
Step 7: Connecting a solar panel to the StatTrak-E on page 9
Step 8: Powering on the StatTrak-E on page 9
Step 9: Setting up the StatTrak-E mobile app on page 10
Step 10: Confirming your installation on page 13
After deployment, please see:
Replacing StatTrak-E batteries on page 15
Check the package contents
Upon receiving your new StatTrak-E, check to ensure that you have all of the items ordered. If you
notice any damaged or missing items, contact All Traffic Solutions Technical Customer Support immediately. Below is a summary
of what's typically included with your StatTrak-E. Also check your packing slip for precise details of your order.
The StatTrak-E can accommodate up to two 12.8V, 11.5Ah rechargeable lithium batteries and
includes a smart battery charger, two adapters, two keys for the ON/OFF switch, and two keys for the
enclosure. If you purchased a solar panel, only one battery is included.
A main pole bracket, three stainless steel banding straps, and a custom security bit. See
5: Installing the mounting brackets on
Six 3/4-in. long x 1/4-in. -20 bolts, with 1/4-in -20 nuts and washers.
An angle bracket, two bolts with washers, a Torx T-30 security bit with 1/4-in. shank, and two pole
adapters for roadside use with Telespar-type poles.
ATS | Chantilly, VA | USA | Tel: 1-866-366-6602 | Email:
Copyright © 2024 | StatTrak-E Quick Start Guide, TraffiCloud Subscriber Edition , ver. 1.02 | 4800268 | All rights reserved. | Page 1
S G
UICK TART UIDE
E
UBSCRIBER DITION
What's included
page 6.
,
sales@alltrafficsolutions.com
What you'll need
A clean workspace and
AC power outlet.
Step
A nut driver and power
screwdriver.
Two wrenches or nut
drivers with 7/16-in.
sockets.
An Android mobile
device with the
StatTrak-E mobile app
installed.
