- Page 1 2.0 Software OperOper Addendum E-MU PN FI 10383...
- Page 2 Audity 2000 2.0 Software Addendum Page New Features 3. 64 voice Polyphony! in Version 2.0 3. Additional user presets! 4 banks of 128 user presets. 3. New main display screen shows preset and ROM group. 3. New Sound Navigator feature allows you to browse sounds by ROM Group, Preset Number, Bank, Preset Category or Preset Name.
-
Page 3: Main Screen
When the cursor is on the Preset Category field, turning the Data Entry Control selects different preset categories. The Name Field will change to show the first preset in each category. V127 A:off USER bas: Interference Preset Category Preset Name Audity 2000 - 2.0 Software Addendum 3... -
Page 4: Instrument Category
Audity 2000 2.0 Software Addendum Instrument Category To Change the Preset Category Press either cursor key repeatedly until the cursor is underneath the preset category field. Rotate the Data Entry Control to select one of the preset categories. Preset Categories are displayed in alphabetical order. - Page 5 USER Bank 0 AUDTY Bank 0 XTREM Bank 0 USER Bank 1 AUDTY Bank 1 XTREM Bank 1 USER Bank 2 AUDTY Bank 2 USER Bank 3 AUDTY Bank 3 AUDTY Bank 4 Audity 2000 - 2.0 Software Addendum 5...
- Page 6 Audity 2000 2.0 Software Addendum Multisetups Multisetups A Multisetup is a group of parameters that you might associate with a particular sequence or song. It is like a “snapshot” of the current MIDI channel configuration of the module. There are 16 setups numbered 0-15.
-
Page 7: Restoring Multisetups
Audity 2000 2.0 Software Addendum Multisetups Restoring Audity 2000 contains 16 Multisetup locations. 15 of these (0-14) are user locations which you can use to store your own Multisetups. Multisetups Multisetups can also be restored using a MIDI Bank Select followed by a Program Change command (0-15). - Page 8 Audity 2000 2.0 Software Addendum Restoring Multisetups Press either cursor button to move the cursor to the bottom line of the screen. Scroll to the “Save Multisetup” screen (shown below) using the Data Entry Control. SAVE MULTISETUP to 020 Destination Multisetup Press either cursor button to move the cursor to the bottom line of the screen.
-
Page 9: Mix Output
The Mix Output function is also useful when sequencing since it lets you route specific MIDI channels (and thus sequencer tracks) to specific Sub outputs (on the back panel) where there they can be processed with EQ or other outboard effects. Audity 2000 - 2.0 Software Addendum 9... -
Page 10: Preset Edit Menu
Audity 2000 2.0 Software Addendum Changes to the Mix Output Screen OUTPUT SECTION & EFFECTS PROCESSORS FX Sends Hall 1 Send 1 15% PRESET Effect Send 2 10% EDIT MENU Send 3 0% Send 4 0% Output Send 1 FX Sends... -
Page 11: Fxa Send Amounts
The PatchCord routing and amount in the Edit menu be transmitted. determine what effect the controller has on each preset. Real-time controllers are shown in the PatchCord menu as MIDI A through MIDI L. Audity 2000 - 2.0 Software Addendum 11... - Page 12 Audity 2000 2.0 Software Addendum Arpeggiator Controller Assign O O O O Audity 2000 factory presets have certain synth parameters assigned to each REALTIME CONTROLLER # controller letter and so these are A: 21 B: 22 C: 23 D: 24 “Global”...
- Page 13 Any layers set to On will play and any layers set to Off will be muted. If all layers are set to Off, then Solo mode ends and all layers play normally. When you exit the Edit menu, all layers play normally. Audity 2000 - 2.0 Software Addendum 13...
-
Page 14: Play Solo Layers
Audity 2000 2.0 Software Addendum New LFO Waveforms PLAY SOLO LAYERS 1: off 2: off 3: off 4: off New LFO Waveforms Audity now contains 17 LFO waves as shown in the diagram below. The new pattern shapes can be combined (Hint: Send both LFOs to the same destination and adjust the amounts) for even more variation. -
Page 15: Envelope Repeat
Key: C1 Crs: 036 Fine: 00 Audity 2000 now contains twelve factory programmed tunings. The Keyboard Tuning parameter in the Edit Menu selects which tuning is used by the current preset. The factory tuning tables are described on the following page. - Page 16 However, in Just tunings you are limited to playing certain chords and if you play the wrong chord it may sound… BAD! Audity 2000 allows you to modulate between keys by providing you 12 user tuning tables. Tuning tables can be changed as you play using a program...
- Page 17 C3 Tuning Tables These new tuning tables take the concept of just intonation a step beyond previous E-mu products. Fully explaining the mysteries of just intonation is beyond the scope of this manual, but the subject is covered exhaustively in Hermann Helmholtz’s On the Sensations of Tone, available at most libraries...
-
Page 18: Playing Demo Sequences
Audity 2000 2.0 Software Addendum Playing Demo Sequences Playing Demo The Demo Screen has been updated to allow more sequences. The actual number of demo sequences depends on which ROM sounds sets are Sequences installed. You can play these demo sequences by accessing the Demo Sequence page. -
Page 19: Create Random Preset
Press Enter. A new random preset will be created. You need to save this preset if you want to keep it. Don’t like the sound? Press Enter again and a new random sound will be generated. Audity 2000 - 2.0 Software Addendum 19... -
Page 20: Multitimbral Sequencing
Audity 2000 2.0 Software Addendum Create Random Preset Multitimbral “Multitimbral” means that Audity 2000 can play multiple sounds at the same time. For a multitimbral sequence to play back correctly, the proper Sequencing preset must be selected for each MIDI channel. This could be done by inserting preset changes into each track of your sequence before the sequence starts. -
Page 21: Base Tempo
Audity 2000 2.0 Software Addendum Multitimbral Sequencing Base Tempo Audity 2000 contains an internal Master Clock. The Master Clock controls all the arpeggiators, synchronizes the LFOs when in Tempo-based mode, controls the times of Tempo-based envelopes, and can be used as a modulation source in the PatchCords section. - Page 22 World Headquarters E-mu Systems, Inc. USA PO Box 660015 Scotts Valley, CA USA 95067-0015 Tel: (831) 438-1921 Fax (831) 438-6812 www.emu.com Europe, Africa, Middle East E-mu Systems, Ltd. Suite 6 Adam Ferguson House Eskmills Industrial Park Musselburgh, East Lothian Scotland, EH21 7PQ...
