SUPERTOOTH ROAMEE Quick Manual

Bluetooth compliance: Bluetooth® version 5.1
Multipairing:
Maximum 8 phones paired /
1 phone connected at a time
Operating range: up to 300 meters (line of sight)
Frequency range: 2.402 - 2.480 GHz
Power:
7.09 dBm EIRP
Battery type: 200 mAh Li-Po
Charging time: 3 hours (depending on charger)
Compatible with any standard USB charger
The power delivered by the charger must be between min 0.5 Watt required by the radio equipment,
and max 0.5 Watts in order to achieve the maximum charging speed.
WARNING:
To prevent possible hearing damage,
do not listen at high volume levels for long periods.
CAUTION:
– The disposal of a battery into re or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion.
– Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of
ammable liquid or gas.
– A battery subjected to extremely low air pressure that may result in an explosion or the leakage of ammable liquid or gas.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems).
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its
working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other
types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the
retailer where they purchased this product, or their local government o ce, for details of where and how they can take this item for
environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
This product has an embedded, non-replaceable battery, do not attempt to open the product or remove the battery as this may cause injury and
damage the product. Please contact the local recycling facility for removal of the battery. The embedded, non-replaceable battery is designed to last
the life time of the product.
Federal Communications Commission (FCC) Statement
Industry Canada (IC) Statement
15.21
You are cautioned that changes or modi cations not expressly approved by the part responsible for compliance could void the user's authority to
operate the equipment.
15.105(b)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC/IC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s) Operation is subject to the following two
conditions :
1) This device may not cause interference and
2) This device must accept any interference, including interference that may cause undesired operation of the device.
FCC/IC RF Radiation Exposure Statement :
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. End users must follow the speci c operating
instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Hereby, EURO COMMUNICATION EQUIPEMENTS declares that the radio equipment type
BTBIKE is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
http://www.SuperTooth.net/download
Euro Communication Equipements sas
Route de Foix D117
11 500 NEBIAS
FRANCE
Operating temperature: 0 to 45°C
Charging temperature:
10 to 40°C
DC input: 5VDC 0.1A
Storage temperature: -10 to 60°C
Accessories: 1 USB cable
2 small holders
2 big holders
Optional large foam
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Euro-CB is under license.
Other trademarks and trade names are those of their
respective owners.
ROAMEE -
Quick Guide
Roamee is a Bluetooth® hands-free kit for bicycle helmets. With its two small adhesive holders
provided, the Roamee can be positioned on any bicycle helmet in a matter of seconds.
Roamee is held securely on its holders by a powerful magnet, making it easy to remove from
the helmet if necessary. With its Open Ear Design technology you can communicate safely with
your caller. Thanks to the speaker placement above your ears, you experience absolute comfort
and remain aware of the surroundings for enhanced safety.
The built-in microphone of the Roamee allows phone conversations or intercom
communication between two Roamee devices (second Roamee available as an option).
With its two speakers, you can also listen to your music in stereo, podcasts, and
navigation instructions from your smartphone.
The ergonomics and simplicity of the three buttons on the Roamee allow you to keep
your phone in your pocket.
INSTALLATION ON HELMET
1. Select the appropriate ROAMEE holders based on the shape of your helmet :
if the surface of the helmet in contact with the holder is too small or
not at enough, choose the large holders.
2. Attach the ROAMEE holder to your helmet, positioning it near your ear in a way
that the directive beam-forming microphone points toward your mouth.
Left ear side
Secure the wire under the helmet foam
OPTIONAL FOAM INCLUDED
• For better wind noise reduction
Right ear side
at high speeds or in strong wind
conditions, insert the optional foam
over the standard foam cover.
