- Page 1 User Guide SeaWire Pro UserGuide_SeaWirePro_Rev.2.01 Developed and produced by MiWire Group ApS, Denmark Diplomvej 381, DK-2800 Kongens Lyngby Phone: +45 82 820 820, E-mail: info@miwire.net...
-
Page 3: Table Of Contents
STEP 5 – Powering the RouDems ....................11 STEP 6 – Configuration of internet via SeaWire RouDem ............12 STEP 7 – Registration ........................12 MiWire user interface ........................13 Specifications ............................19 FAQ/Troubleshoot ..........................20 Service & Repair ........................... 22... -
Page 4: Introduction
Required information for the reader IMPORTANT: Text marked ‘Important’ provides essential information to the reader and is key information to the user for the equipment to work properly. Damage to the equipment can occur if instructions are not followed. MiWire Group ApS... -
Page 5: Package Content
Picture Quantity SeaWire RouDem 1x IP 192.168.2.1 1x IP 192.168.3.1 Mounting Bracket 19’’ BDU Pro including rack assembly items BDU Power Cable 100-240V Screws M4x16mm Unbraco 4 Key Torx 10 Key Privacy Policy User Guide Registration Information MiWire Group ApS... -
Page 6: Requirements
360° view with the longest possible distance to other radiocommunication systems. The Mounting Bracket interfaces to a pole of Ø38mm/1.5” (outer diameter). Read more about the mounting in Installation of the SeaWire RouDem section, step 3. System Configuration MiWire Group ApS... -
Page 7: Hardware Overview
SeaWire RouDem’s comes with IP address 192.168.2.1 and 192.168.3.1. If you connect more than two SeaWire RouDems to the BDU please change the IP address to 192.168.4.1 and 192.168.5.1. See how to change the IP address in the section ‘MiWire User Interface’. Console port RJ45 serial console port for Command Line Interface (CLI) management. -
Page 8: Ports (Bdu) Below Deck Unit - Back Panel
User Guide SeaWire Pro PORTS (BDU) BELOW DECK UNIT - BACK PANEL Note: there are additional ventilation holes in the bottom. MiWire Group ApS... -
Page 9: Led's
Green: When the device is ready for use the LED will light green. It indicates the direction of the operator tower it is connected to. It is possible to turn off the LED. See how in the section MiWire user interface > SIM > LED Settings BELOW DECK UNIT (BDU) Power... -
Page 10: Installation Of The Seawire Pro
3. Check if the device is working with the purchased SIM card. Turn on the RouDem by pressing the on/off button and wait for the LED to light green. It takes a few minutes. If the LED remain red, please read the troubleshoot section. MiWire Group ApS... -
Page 11: Step 2 - Preparing Mounting Bracket And Connecting The Ethernet Cable
Unbraco 4 Key. It is not possible to state which torque the pinole screws should be tightened with, as it depends on the material. ❶ a ❶ b ❶ c ❷ ❸ ❹ MiWire Group ApS... -
Page 12: Step 3 - Installing The Seawire Pro
VHF’s and GPS antennas to prevent electrical noise and interference. Install one RouDem in the port side and the other RouDem in the starboard side • on the vessel to make up for blind spots. MiWire Group ApS... -
Page 13: Step 4 - Cable Wiring
In case of power outage, RouDem is battery powered. Full charging takes 4h 30min after which it can operate for at least 8 hours on battery power. Note: the device will not charge at temperatures below 10°C and above 45°C. MiWire Group ApS... -
Page 14: Step 6 - Configuration Of Internet Via Seawire Roudem
The device will automatically search for available WiFi networks (make sure WiFi is on). 2. Choose the WiFi network with the name containing MiWire. The SSID (network name) and WiFi key. Find the information on the unit label, which is found under the RouDem, on the box or on the registration flyer. -
Page 15: Miwire User Interface
In this section there will be a description of system settings which are configurable from the Web Server/MiWire user interface. MiWire user interface presents an overall status of the RouDem and allow the user to configure WiFi and network related settings, get an overview SIM card information and perform device commands. - Page 16 The information can usually be found by looking up the MCC and MNC at the internet. Read more about setting the APN in the Network tab, ‘MyDefinedAPN’. WiFi WLAN basic Turn WiFi ON (default)/OFF WiFi Radio SSID Change SSID/WiFi name Encryption WPA2 (default) None Password/repeat password Change WiFi password MiWire Group ApS...
- Page 17 Result of values in Start IP Address and Address Limit DHCP Client List List of registered clients. It is possible to block clients from the list WLAN Advanced Change of WiFi channel. Select Auto Channel (default) or between 1-11. Network MiWire Group ApS...
- Page 18 If you change the setting in the APN List to MyDefinedAPN you can change the APN Authentication to: None CHAP Both Force APN Turn Force APN ON/OFF (default) Serving Cell Showing serving cell information Data Traffic Showing data consumption for specific periods MiWire Group ApS...
- Page 19 Select a value between 0 (off) and 255 (max) to define the brightness of the external LED Compass & Map Shows the GPS position of the SeaWire RouDem Compass Shows the direction the antenna is pointing. Calibrate the antenna if needed MiWire Group ApS...
- Page 20 *Not recommended for SeaWire. Admin Change Password New Password/Repeat Password Change password for MiWire user interface. Upgrade System Upload new SW directly. Device commands Reboot You will lose connection to the device during reboot.
-
Page 21: Specifications
100-240VAC, 47-63Hz, 50W IEC 60320 C14 Inlet Environmental conditions Temperature operational 0°C ~ +50°C Relative humidity Max. 90% Interfaces 2/4 x WAN interface RJ45 1 x LAN interface RJ45 1 x Console (support) Features Load balancing, monitoring MiWire Group ApS... -
Page 22: Faq/Troubleshoot
The LED light on the RouDem is Red • Check whether you must enter the PIN code. Go to MiWire user interface and see if the message on the status page in front of SIM says to enter the pin code. If so, go to the SIM page and enable the PIN code. - Page 23 Contact your provider if the problem persists. Check whether the SIM card indicator is green. • If not, this may be because the SIM card is not seated correctly. Try removing the SIM card and putting it back again. GENTLY! MiWire Group ApS...
-
Page 24: Service & Repair
Before contacting your dealer/distributor, please identify the product. Find the serial number and IMEI number on the unit label, which is found under the RouDem, on the box or on the registration flyer. Alternatively log on MiWire user interface and read out the serial number or IMEI number.
