2. Placement on a Desktop
Place Tiny 2 Lite directly on your desktop.
3. Placement on a Tripod
OBSBOT Tiny 2 Lite is equipped with a standard UNC 1/4-20 nut connector on the
base for mounting the camera to a stand/tripod.

Connect to the Computer

OBSBOT Tiny 2 Lite is compatible with both Windows and Mac computers. To set up
your OBSBOT Tiny 2 Lite, use the standard data cable to connect it to the USB port
on your laptop or desktop computer. If necessary, use the provided USB-C to USB-A
adapter. The webcam will automatically install on your device. Please wait a few
seconds for the installation to finish before attempting to access the webcam. After
the installation is complete, you can use popular video call platforms such as Zoom,
Microsoft Teams, Skype, or Google Meet to start streaming with your Tiny 2 Lite.
⚠
① If the product is in working condition for a long time, the bottom of the product
will heat up, which is normal situation.
② To avoid compatibility problems, be sure to use the standard data cable to
connect the computer.
③To prevent the product from malfunctioning due to insu cient power supply,
please connect it directly to your computer or use an expansion dock with an
independent power supply.
④ 4K streaming requires compatible third-party software.
Gimbal
OBSBOT Tiny 2 Lite is equipped with a 2-axis brushless motor gimbal. The
controllable rotation range for the pan is ±140°, and for the tilt is 30° to -70°.
5

Sleep Mode

① Manual Sleep
Please adjust the lens to point straight down. If the indicator light is off, it means that
the sleep mode is activated.
② Device Auto Sleep
You can use OBSBOT Center software to set the sleep time so that it automatically
enters sleep mode as needed.
Gesture Control 2.0
Turn On/Off Human Tracking
To enter human tracking mode, perform the gesture as shown
in the figure. The current status light will flash twice in
succession and then turn to a steady blue state, indicating
that you have successfully entered human tracking mode.
To exit human tracking mode, perform the same gesture
again. The blue status light will flash twice continuously and
then turn to a steady green state, indicating that you have
successfully exited human tracking mode.
Zoom to 2x (default) / Cancel
Perform the gesture control as shown in the figure. The status
light will flash twice continuously to indicate that the zoom
in/out operation has been performed.
