protech prox SA-N718 Quick Reference Manual

Advertisement

Quick Links

SA-N718
Quick
Reference
Guide
Specifications
System
CPU Support
LGA1200 socket for Intel
i5 / i3 / Pentium
®
CPU List
Xeon
: W-1290TE, W-1270TE, W-1250TE
10th Core™: i9-10900E(TE), i7-10700E(TE), i5-10500E(TE),
i3-10100E(TE)
®
Pentium
: G6400E, G6400TE / Celeron
®
Chipset
Intel
H420E / Q470E / W480E
Memory Support
2 x SO-DIMM sockets, support 2933MHz DDR4 up to 64GB
(W1-1290TE, W-1270TE, i9, i7 CPU)
2 x SO-DIMM sockets, support 2666MHz DDR4 (up to 64GB)
(W-1250TE, i5, i3 CPU)
2 x SO-DIMM sockets, support 2400MHz DDR4 (up to 64GB)
®
(Pentium
/ Celeron
Power Supply
ATX 250W
Dimensions (WxHxD)
300.2 x 94.5 x 272.79 mm
Expansion Slots
1 x PCIeX16 slot, supports PCIe Gen3.
1 x M.2 slot, M-Key, supports NVMe PCIeX4/X2 and SATA,
for storage only without USB signal, supports 2242 only
Drive Bay
2 x 2.5" SATAIII HDD / SSD drive space
Operating System
Windows 10 IoT Enterprise LTSC 2019, 2021/ Ubuntu 20.04 LTS
System Weight
5 kg
Certification
FCC / CE
I/O Ports
Display
2 x DVI-D / 1 x DP (optional)
USB
4 x USB 3.0 (rear)/2 x USB 2.0 (Rear)/ 2 x USB 3.0(option, front)
Audio
1 x Line In, 1 x Line Out, 1 x Mic In
LAN
2 x GbE LANs support Wake-On-LAN, PXE
®
LAN1: Intel
Serial Ports
COM1 for RS-232/422/485, COM2 for RS-232
(COM 1/2 support +5V/+12V/RI by setting jumper)
COM3~COM6 for RS-232 only (option)
Parallel Port
1 x parallel port (optional)
PS/2
1 x PS/2 Combo connector for keyboard & mouse (rear I/O)
LED & Button
1 x Power LED, 1 x HDD LED, 1x Power Button
Environment
Operating Temp.
HDD: 0°C ~40°C (32°F~104°F)
Storage Temp.
-20°C ~60°C (-4°F~140°F)
Humidity
20% ~ 90%
All Rights Reserved. Copyright 2022
SA-N718
®
®
10th Gen. Xeon
/ Core™ i9 / i7 /
®
®
/ Celeron
desktop CPU / Target TDP 65W
CPU Support
Chipset
DRAM
OS Support
Power Supply
Drive Bays
®
: G5900E, G5900TE
SATA
System Dimension
Watchdog
RAID function
Speaker
Fan
PXE
POWER BUTTON
LED Indicator
USB
USB
Keyboard / Mouse
®
CPU)
Serial Port
Display
LAN
Audio
DC out
USB
PCIe/PCI slot
(Riser card)
Operation Temp.
Storage Temp.
Humidity
RoHS
DVI to VGA adapter DVI to VGA adapter P/N: 10-625-04410123
®
219LM / LAN2: Intel
LAN 210AT
Packing Checklist
If you discover any item below damaged or lost,
please contact your vendor immediately.
SA-N718
Driver/Manual DVD
This Quick Reference Guide
Mini Jumper (2 mm)
Ver. Q1
System View
Front View
System
Intel
®
Core 4
th
Gen. i3 / i5 / i7 processors (LGA1150, max 65W TDP)
i7-4770S, i3-4340TE, i3-4330TE, Celeron G1820TE
Intel Q87
2 x 204p DDR3 SO-DIMM socket up to 16GB
Win 7 / Win 8
FSP Flex ATX 220W
2 x 2.5" SATA HDD & 1 x slim DVD-ROM
SATAIII x 4 for Q87
(W)300 x (H)94 x (D)270 mm
1~255 sec
RAID 0/1/5/10 for Q87
Top View
Internal buzzer
1 CPU Fan (4 pin header) + 1 system Fan (3 pin header) + twin Front System
Fans (4 pin header)
300.20
With PXE (disable in BIOS as default)
I/O port (front)
1 x (option)
2x (Power LED + HDD LED)
2 x USB 2.0 cable by pin header
4x USB3.0 + 2x USB2.0 (Q87);
2 x PS/2 port (wake up system from S1 to S4)
4 x COM port, COM 2 for RS232/422/485 (COM1/2 support +5/+12V/RI
selectable)
1 x DVI-I / 1x DVI-D / 1 DP , Support 3 independent diaply for Q87
2 x Giga LAN (RJ45) , support Wake-on-LAN
LAN1: Intel I217LM/V (Clarksville) / LAN2: Intel I210-AT (Springville)
Realtek ALC888S-VD2-GR HD Audio codec, Mic x 1, R channel x 1 + L
channel x 1, Volume controller x 1
1x 8p(Molex micro-Fit 3.0) housing DC 5V&12V
Additional 2 x USB 2.0 cable by pin header (Q87) (option)
Expansion Slot
1 x PCIe 16x + 1 x PCI (SR-5076RA-R2N) or 2 x PCI slot (SR-5076RA-R3N)
Environment
0°~ 40°C (with customer graphic card GT 630)
-20 to 60°C
20~90%
RoHS Version
Accessary
I/O View
COM5
COM6
COM4
COM3
COM2
Rear View
Audio
Volume
R
Controler
COM3
COM3
COM5
COM4
COM4
COM6
COM2
DVI-D
COM1
COM2
DVI-I
DVI-D
COM1
DVI-D
Quarter View
Side View
PS/2 Combo
Connector for
Line In
KB & MS
Line Out
LAN2 LAN1
COM3
COM5
COM4
COM6
COM2
DVI-D
COM1
DVI-D
DVI-D
Mic In
AC In
COM1
USB 2.0
USB 3.0
SA-N718
x 1
x 1
x 1
x 6
SA-N718
Unit: mm
L
272.79
1.75
