protech Prox SG-S152 Quick Reference Manual

SG-S152/
SG-S162/
SG-S172
Quick
Reference
Guide
Jumper Setting
1
NC
(default)
1
1 1
5V 12V
5V
(default)
1
CAUTION!
Danger of explosion may occur if the battery is replaced incorrectly. Replace batteries only with the same or equivalent type recommended by the manufacturer. Dispose the
used batteries according to the manufacturer's instructions.
The waterproof capability of the device may be incapable when the screws are loosened.
The O-ring to seal the device may be damaged during the maintenance process. Qualified engineer is recommended to make the O-ring replacement to keep the waterproof
capability of the device.
All Rights Reserved. Copyright 2023
1
JBTN1
1 1
PWR2
1 2
JDIO2
1 2
1
JP_COM1
JDIO1
M_PCIE1
1 6
JCOM2
1 6
JCOM1
1 2
JUSB1
1 2
JAUDIO1
M.2 Wi-Fi
JP7
1
M2_E1
1
JINV1

Specifications

System
CPU Support
Memory Support
Operating System
Enclosure
IP Rating
Power Input
Watchdog
Mounting Support
System Weight

Dimensions (WxHxD)

(w/o Stand)
Dimensions (WxHxD)
(with Stand)
Certifications

I/O Ports

Power Input
USB
Serial Ports
LAN
Storage
Expansion Bus

Display

LCD
Touchscreen

Environment

Operating Temperature 0°C~50°C (32°F~122°F)
(with airflow)
Storage Temperature
Ver. Q1
Humidity
JDP_HDMI1
LAN2 LAN1
(DP & HDMI)
M2
M1
1
10
1
JLPC1
JP_LPC1
9
1
M.2 SSD
2 4
1
JP1
1
JP_VDD1
1
1
1
1
29
2
74 68 58
6
1
30
2 75 67 57
LVDS1 JUSB2
SG-S152 / SG-S162 / SG-S172
Intel Celeron J6412 processor
® ®
Intel Atom x6425RE processor (option)
® ®
1 x DDR4 3200MHz SO-DIMM socket (up to 32GB) (non-ECC)
Windows 11 / Windows 10 IoT LTSC 64bit
® ®
Ubuntu 20.04 (Kernel 5.4)
Stainless SUS304
IP66 / IP69K
DC In 12V/24V
1~255 second Watchdog timer selectable
VESA 100 / Stand
SG-S152:13kg / SG-S162: 12.7kg / SG-S172: 14.4kg
SG-S152:420 x 335 x 92.1mm/ SG-S162:450 x 305 x 92.5mm
SG-S172: 450 x 381 x 96.1mm
SG-S152:420 x 387.5 x 160mm/SG-S162:450 x 372.5 x 160mm
SG-S172:450 x 433.5 x 160mm
FCC / CE
1 x M12 waterproof connector, supporting 12V/24V DC
2 x USB 2.0 M12 waterproof connectors (4 x USB ports)
2 x COM M12 waterproof connectors, with RS-232/422/485
2 x 1GbE LANs with M12 waterproof connectors
Supports Wake-On-LAN
1 x 2.5" SATA III SSD
1 x full-sized Mini PCIe slot (Mini PCIe and USB signal)
SG-S152: 15" TFT LCD (LED) resolution 1024 x 768
SG-S162: 15.6" TFT LCD (LED) resolution 1366 x 768
SG-S172: 17" TFT LCD (LED) resolution 1280 x 1024
Projected capacitive touchscreen (USB interface)
or 5-wire resistive touchscreen (option)
-20°C~50°C (-4°F~122°F)
(Wide-ranged temp. sku and components)
-20°C~80°C (-4°F~176°F)
20% ~ 90%
SG-S152/SG-S162/SG-S172
USB2
USB1
1
JCOMS1
7
2 1
JSPI
JP_USB1
SO-DIMM1
M2_M1
SATA1 JHD_PWR1
2
1 7
1
1
Clear CMOS Data
Selection
1 1
Normal Clear CMOS
(default)
Low Pin Count
Selection
1 1
80 Port LPC Device
(default)
1
1
S5,
S5,USB Power=0V
USB Power=5V
(default)
5V
(default)
1
LVDS Sequence Control
Selection
5 1 5 1
6 2 6 2
BKLTEN
BKLTCTL
from CPU
from CPU
(default) (default)
