- Page 1 EN Dishwasher / User Manual TDV-FN158COX/TDV-FN158CDX...
- Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................2 1.3. During Use........................3 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Electrical Connection ....................7 2.5. Fitting the Machine Undercounter .................7 3.TECHNICAL SPECIFICATIONS .................. - Page 4 8.CLEANING AND MAINTENANCE ................. 20 8.1. Filters ...........................20 8.2. Spray Arms ........................20 8.3. Drain Pump ........................21 9.TROUBLESHOOTING ....................22...
-
Page 5: Safety Instructions
1. SAFETY INSTRUCTIONS 1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 6: Installation Warnings
2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void. -
Page 7: During Use
pressure exceeds 1 MPa, a pressure relief valve must be fitted between the connection. 3. During Usage • This machine is for domestic use only; do not use • it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door of the dishwasher. - Page 8 the door for one minute after it has opened. For effective drying, keep the door open for 30 minutes after a programme has ended. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by an authorised service company, otherwise the warranty will be void.
- Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
-
Page 10: Installation
2. INSTALLATION WARNING: Use the new water inlet hose supplied with your machine, do not 2.1. Machine positioning use an old machine’s hose. When positioning the machine, place it in WARNING: Run water through the an area where dishes can be easily loaded and unloaded. -
Page 11: Electrical Connection
2.5. Electrical connection WARNING: After removing the top panel of your dishwasher, the machine should be placed in a space of the dimensions shown in WARNING: Your machine is set to the figure below. operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. -
Page 12: Technical Specifications
3. TECHNICAL SPECIFICATIONS 3.2. Technical specifications 15 place Capacity settings Dimensions Height 850(mm) Width 598(mm) Depth 598(mm) Net weight 53,600 (kg) Operating 220- 220-240 voltage / 50 (Hz) frequency Total current 10(A) Total power 1900(W) Maximum: Water supply 1 (Mpa) 3.1. -
Page 13: Before Using The Appliance
4. BEFORE USING THE APPLIANCE 4.1. Preparing your dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •... -
Page 14: Test Strip
4.4 Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices. -
Page 15: Filling The Detergent
Add the proper detergent for the selected 4.11 Rinse-aid usage program to ensure the best performance. The rinse aid helps to dry the dishes without The amount of detergent needed depends streaks and stains. Rinse-aid is required for on the cycle, load size, and soil level of stain-free utensils and clear glasses. - Page 16 Level Brightener Dose Indicator Rinse-aid not r1 is shown on the dispensed display. 1 dose is r2 is shown on the dispensed display. 2 doses are r3 is shown on the dispensed display. 3 doses are r4 is shown on the dispensed display.
-
Page 17: Loading Your Dishwasher
5. LOADING YOUR WARNING: To avoid any possible DISHWASHER injuries, place long-handle and sharp- pointed knives with their sharp points facing down or horizontally on the baskets. For best results, follow these loading guidelines. Loading the household dishwasher up to Upper Basket the capacity indicated by the manufacturer Height adjustment... - Page 18 Height Adjustable Rack (peg type) The foldable racks in the upper basket enable the placement of large items such as pots and pans. Each section can be folded separately. The foldable racks can be either raised up or folded down. Upper Cutlery Basket The upper cutlery basket is designed for the placement of large and small cutlery and...
-
Page 19: Alternative Basket Loads
5.2. Alternative basket UnsUitable items for dishw ashing loads Lower basket • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron- alloy materials. • Forks, spoons and knives with wooden, bone, ivory or nacrecoated handles; glued items, items soiled with abrasive, acidic or base chemicals. -
Page 20: Programme Table
6. PROGRAMME TABLE Duration Programme Description (min) Prewash Suitable to rinse dishes that you plan to wash later Mini 14’ Fastest program for lightly soiled and recently used dishes and suitable for 4 place settings. (Jet Wash) Suitable for lightly soiled dishes and quick wash. Quick 30’... -
Page 21: The Control Panel
7. CONTROL PANEL 4. Remaining Time Display Program flow can be tracked with Washing, Rinsing, Drying, End lights and the (9) (8) (a) (b) (c) (d) (10) (11) Remaining Time Display. 5. Start/Pause Key Start the program by pressing the Start/ Pause key. -
Page 22: Changing A Programme
13. Extra Rinse Option Display Once the program has stopped, use the program selection key If you select the rinsing option, washing- to select the desired program. rinsing steps will be added to this program to ensure that your dishes are extra dry and shiny. -
Page 23: Switching The Machine Off
3. “IL1” will be displayed when the Power 7.3. Switching off the Machine Saving Mode is enabled. In this mode, the inner light will turn off 4 minutes after the door is opened and the machine will turn off Once the program end and the End light turns on, press the On/Off Key to switch off in 15 minutes if no key is pressed to save the machine. -
Page 24: Cleaning And Maintenance
8. CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter out of the micro filter (2).Then pull and remove Cleaning your dishwasher is important to the metal filter (3).Rinse the filter with lots of maintain the machine’s service life water until it is free of residue. -
Page 25: Drain Pump
8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on pieces of broken glass or pointed implements. -
Page 26: Troubleshooting
9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 27 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
- Page 28 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
- Page 29 PRACTICAL INFORMATION 1. When the machine isn’t in operation: • Disconnect the plug and close the tap. • Leave the door slightly open to prevent odour formation. 2. Select the dry option to remove water droplets. 3. Place dishes in the machine properly to achieve the best energy consumption, washing and drying performance.
- Page 30 THE PRODUCT FICHE Supplier's trade mark TORNADO Supplier's model TDV-FN158COX / TDV-FN158CDX Capacity of dishwasher The energy efficiency class A++++ Annual energy consumption in kWh per year (AEc) ( 280 Cycle )* Energy consumption (Et) (kWh per cycle) 0,949 Off-mode power consumption (W) (Po) 0,50 Left-on mode power consumption (W) (Pı)
- Page 31 52336829 R60...
