- Page 1 EN Dishwasher / User Manual TDV-FN107DDS...
- Page 2 Thank you for choosing this product. This User Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................1 1.1. General Safety Warnings ....................1 1.2. Installation Warnings .....................2 1.3. During Use........................3 2.INSTALLATION ......................... 6 2.1. Machine Positioning .....................6 2.2. Water Connection ......................6 2.3. Water Inlet Hose ......................6 2.4. Electrical Connection ....................7 2.5. Fitting the Machine Undercounter .................7 3.TECHNICAL SPECIFICATIONS .................. - Page 4 8.CLEANING AND MAINTENANCE ................. 20 8.1. Filters ...........................20 8.2. Spray Arms ........................20 8.3. Drain Pump ........................21 9.TROUBLESHOOTING ....................22...
-
Page 5: Safety Instructions
1. SAFETY INSTRUCTIONS 1. General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. -
Page 6: Installation Warnings
2. Installation Warnings • Choose a suitable and safe place to install your machine. • Only original spare parts should be used with the machine. Unplug the machine before installation. Your machine must only be installed by an authorised service agent. Installation by anyone other than an authorised agent may cause your warranty to be void. -
Page 7: During Use
pressure exceeds 1 MPa, a pressure relief valve must be fitted between the connection. 3. During Usage • This machine is for domestic use only; do not use • it for other purposes. Commercial use will void the guarantee. Do not stand, sit or place loads on the open door of the dishwasher. - Page 8 the door for one minute after it has opened. For effective drying, keep the door open for 30 minutes after a programme has ended. Do not stand in front of the door after the auto-open signal sounds. In the case of a malfunction, repair should only be performed by an authorised service company, otherwise the warranty will be void.
- Page 9 CE Declaration of Conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. Disposal of your old machine The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
-
Page 10: Installation
2. INSTALLATION WARNING: Use the new water inlet 2.1. Machine positioning hose supplied with your machine, do not use an old machine’s hose. When positioning the machine, place it in an area where dishes can be easily loaded WARNING: Run water through the and unloaded. -
Page 11: Electrical Connection
2.4. Electrical connection WARNING: After removing the top panel of your dishwasher, the machine should be placed in a space of the dimensions shown in WARNING: Your machine is set to the figure below. operate at 220-240 V. If the mains voltage supply to your machine is 110 V, connect a transformer of 110/220 V and 3000 W between the electrical connection. -
Page 12: Technical Specifications
3. TECHNICAL SPECIFICATIONS 3.2 Technical specifications 10 place Capacity settings Dimensions Height 850(mm) Width 450(mm) Depth 598(mm) Net weight 40 kg Operating 220-240V voltage / 50 Hz, frequency Total current 10(A) 3.1. General appearance 1. Worktop Total power 2. Upper basket with racks 1900(W) 3. -
Page 13: Before Using The Appliance
4. BEFORE USING THE APPLIANCE 4.1. Preparing your dishwasher for first use • Make sure the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging material inside the machine. •... -
Page 14: Test Strip
4.4. Test Strip Run water Keep the Shake the Wait Set the hardness level of through the strip in the strip. (1min.) your machine. tap (1min.) water (1sec) second munite munite NOTE: The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend that you use filter and refinement devices. -
Page 15: Filling The Detergent
amount of detergent needed depends on 4.11 Rinse-aid usage the cycle, load size, and soil level of dishes. The rinse aid helps to dry the dishes without Do not fill detergent into the detergent streaks and stains. Rinse-aid is required for compartment more than required;... - Page 16 Level Brightener Dose Indicator Rinse-aid not r1 is shown on the dispensed display. 1 dose is r2 is shown on the dispensed display. 2 doses are r3 is shown on the dispensed display. 3 doses are r4 is shown on the dispensed display.
-
Page 17: Loading Your Dishwasher
5. LOADING YOUR WARNING: To avoid any possible DISHWASHER injuries, place long-handle and sharp- pointed knives with their sharp points facing down or horizontally on the baskets. For best results, follow these loading guidelines. Loading the household dishwasher up to the capacity indicated by the manufacturer will contribute to energy and water savings. - Page 18 Dish rack The upper basket racks can either be open, a, or closed, b. Place cups and large utensils (horizontally) on the racks to be washed. Two Folding Racks The folding racks allow large items, such as pots and pans, to be placed more easily. Each part can be folded separately.
-
Page 19: Alternative Basket Loads
5.2.Alternative Basket Loads Important Note for Test Laboratories Lower Basket For detailed information required for tests according to EN normatives and a softcopy of the manual, please send the model name and serial number to the following address: dishwasher@standardtest.info Top Basket Incorrect Loads Un chargement incorrect peut entraîner de mauvaises performances de lavage et... -
Page 20: Programme Table
6. PROGRAMME TABLE Duration Programme Description (min) Prewash Suitable to rinse dishes that you plan to wash later Quick 30’ 40°C Suitable for lightly soiled dishes and quick wash. Delicate Suitable for lightly soiled delicate dishes. 30°C - 50°C Standard program for normally soiled daily using dishes with reduced energy and water consumptions. -
Page 21: The Control Panel
7. THE CONTROL PANEL switch to 0 hour by using the delay when the machine is paused. 4. Remaining Time Indicator Programme flow can be monitored via the Wash,Rinse, Dry, End indicators and Remaining Time Indicator. 5. Start/Pause Button Press the Start/Pause button to start the programme. -
Page 22: Changing A Programme
7.1. Changing a programme illuminate while this function is in operation. Dishes placed in other areas will not be If you would like to change the programme washed. when the machine is already running. Press the Start/ 12. Extra Hygiene Indicator Pause button. -
Page 23: Switching The Machine Off
Save Power Mode 7.3. Switching the Machine Off To activate or deactivate save power mode, follow the below steps: Pull the plug out of the outlet. Turn off the 1. Open the door and press Program (2) water tap. and Option (6) buttons at the same time for 3 seconds. -
Page 24: Cleaning And Maintenance
8. CLEANING AND To remove and clean the filter combination, turn it counter clockwise and remove it by MAINTENANCE lifting it upwards (1).Pull the coarse filter out of the micro filter (2).Then pull and remove Cleaning your dishwasher is important to the metal filter (3).Rinse the filter with lots of maintain the machine’s service life water until it is free of residue. -
Page 25: Drain Pump
8.3 Drain Pump Large food residues or foreign objects which were not captured by the filters may block the waste water pump. The rinsing water will then be above the filter. Warning Risk of cuts! When cleaning the waste water pump, ensure that you do not injure yourself on pieces of broken glass or pointed implements. -
Page 26: Troubleshooting
9. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Switch your Dishwasher on by pressing the Your Dishwasher is not switched on. On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 27 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as Not enough detergent used. instructed in the programme table. Rinse aid dosage and/or water Increase rinse aid and/or water softener softener setting set too low. level. Whitish stains remains on dishes.
- Page 28 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of Water inlet system failure the hose.
- Page 29 PRACTICAL INFORMATION 1. When the machine isn’t in operation: • Disconnect the plug and close the tap. • Leave the door slightly open to prevent odour formation. 2. Select the dry option to remove water droplets. 3. Place dishes in the machine properly to achieve the best energy consumption, washing and drying performance.
- Page 30 THE PRODUCT FICHE Supplier's trade mark TORNADO TDV-FN107DDS Supplier's model Capacity of dishwasher The energy efficiency class Annual energy consumption in kWh per year (AEc) ( 280 Cycle )* Energy consumption (Et) (kWh per cycle) 0,739 Off-mode power consumption (W) (Po)
- Page 31 52347214 R45...
