    1 PURPOSE OF THIS MANUAL The purpose of this Service Manual is to provide Service Engineers who are already familiar with repair procedures with information regarding the PCB. The manual deals with the following topics: o PCB general characteristics o Disassembly Document Revisions Rev.
  • Page 4: Erf2600 Overview

    3. Mark and disconnect all wires and release snaps to detach the boards. 4. Do not replace the ERF2600 and the NIUx board at the same time. Replace first one and start the appliance before replacing the other. This is due to that the boards are serialized.
  • Page 5 Q&CI - Technical Support 599 83 20-19 Rev. 02...
  • Page 6 3.1 ERF2600 Loads layout AC In/Output ERF Nomenclature DC In/Output J1:1 Neutral NEUTRAL VCZ Fan (OR FZ J8:1 Light) J1:2 Line In IN_LIVE 4 Pin DC_PWM_LO EPII 7.92 J1:3 Line Out LIVE J8:2 AD_OUT_4 J1:4 STD Compressor COMP_LIVE VCC (Inverter...
  • Page 7 DC In/Output J14:J15:J16:1 MACS J10:1 J14:J15:J16:2 RX/TX 4 Pin J10:2 IN_5 JST PA J14:J15:J16:3 J10:3 J14:J15:J16:4 J10:4 FZ NTC J10:5 NTC_3 J10:6 FZ EVAP NTC J10:7 NTC_4 14 Pin EP2.5 = J10:8 VCZ NTC J10:9 NTC_5 J10:10 FZ Door SW J10:11 DOOR_SW_2 J10:12...
  • Page 8: Niux Board

    ESD damage. NIUx Note: Do not replace the ERF2600 and the NIUx board at the same time. Replace first one and start the appliance before replacing the other. This is due to that the boards are serialized. Q&CI - Technical Support...
  • Page 9: User Interface On Door

    5 USER INTERFACE ON DOOR 5.1 Modes Mode: Press and hold to activate/deactivate Service + (freezer) and – (freezer) for 10 Demo + (freezer) and – (refrigerator) for 10 sec. mode: mode: sec. Water “Ice Cubes” and “Crushed ice” for Reset Warns automatically after 6 months since the pressure...
  • Page 10 5.2 Disassembly user interface on door 1. Insert thin plastic tool to clip out the electronic board or use a suction cup. 2. Disconnect the wire connector. 5.3 Connectors user interface on door PCB J1 (NIUx INTERFACE) J2 (MACS) J3 (I2C) 1- WiFi RX 1- GND 1-SCL...
  • Page 11 Q&CI - Technical Support 599 83 20-19 Rev. 02...
  • Page 12: User Interface On Vcz Drawer

    6 USER INTERFACE ON VCZ DRAWER 6.1 Disassembly user interface VCZ drawer Cover is glued and cannot be reused. 1. Use a suction cup to clip out the control panel. 2. Disconnect the wire connector. 6.2 Connectors VCZ PCB JFlash DAAS FUNCTION FUNCTION...
  • Page 13: Wi-Fi Connectivity Setup

    7.1 Install the application “My Electrolux Kitchen” Go to the app store on the mobile device Download and install the app “My Electrolux Kitchen” Start the application. Select country and language and login or create a new account. 7.2 Configure the wireless connection Stand near the appliance with the mobile device (Android or iOS).
  • Page 14: Connectivity States

    8 CONNECTIVITY STATES The table shows the different connectivity readiness state of the appliance based on various conditions. Blinking frequency is 480 ms on and 240 ms off. Home Network Wi-Fi Credentials Home Network Cloud UI feedback for Wi-Fi State function Registration status Connection...
  • Page 15: Service Mode

    9 SERVICE MODE 9.1 Enter and exit service mode Activate/deactivate service mode Change status Progress through the different functions Activate service mode: Press and hold All LEDs of the UI illuminates and a beep confirms that service mode is + (freezer) and activated.
  • Page 16 9.2 Display character representation 9.3 List of functions in service mode Number Function test UI action to change the Expected behaviour status First screen LED lights up to display UI. LED turns off. Second screen a. The freezer evaporator defrost sensor Freezer defrost Press “Ice Cubes”...
  • Page 17 a. Solenoid is activated when “on”, deactivated Cube/crush Press “Ice Cubes”. when “off”. solenoid b. Do not leave solenoid activated for more than 1 minute; it turns off automatically after 1 minute. b. Be prepared to collect water at dispenser. Water valve Press “Ice Cubes”.
  • Page 18 a. The freezer evaporator fan runs at three Freezer Press “Ice Cubes”. speeds: • evaporator fan “On”: Fan runs at maximum speed • “Mi”: Medium speed • “Off”: Stopped b. “Lc”: Rotor condition locked. c. “Ns”: PWM signal that provides duty cycle is absent and the fan is ““off”.
  • Page 19 a. Freezer evaporator fan is automatically at VCZ damper Press “Ice Cubes”. maximum speed. a. “Op”: VCZ damper is open. b. “Cl”: VCZ damper is closed. c. “Off”: Stopped b. Check for airflow when the damper is fully open and that there are no air leaks when fully closed.
  • Page 20 a. “Op”: Door is open. Freezer drawer Open/Close FZ Reed Switch b. “Cl”: Door is closed. a. “Op”: Door is open. VCZ drawer Open/Close VCZ Reed b. “Cl”: Door is closed. Switch a. “On”: Paddle is pressed. Dispenser paddle Press the Dispenser Paddle b.
  • Page 21 Displays digits sequence related to the set of parameters that is Runs flashed inside ERF2600 power board; Automatically, b. It is built of 8 digits. The same digit is displayed simultaneously on scrolling all the 2 displays (Freezer and Refrigerator).
  • Page 22: Demo Mode

    10 DEMO MODE When demo mode is activated, the UI and internal light will work normally, but the cooling system is turned off. Activating / Deactivating Demo Mode Press and hold + (freezer) and – (refrigerator) for 10 seconds, reverse to deactivate. 11 RESET TO FACTORY DEFAULT Press and hold - (freezer) and - (fridge) keys for 5 seconds to reset the following functions to its factory settings: •...
