Summary of Contents for Alukov CORONA
- Page 1 USER’S MANUAL WARRANTY CARD COMPLETE YOUR HOME...
- Page 2 POOL PROGRAM / SWIMMING POOL ENCLOSURES LOW LINE CORONA™ VIVA™ VIVA PRIME TERRA TERRA PRIME IMPERIA NEO™ LIGHT ELEGANT NEO™ RIVIERA OCEANIC LOW IMPERIA PROGRES ELEGANT MEDIUM-HEIGHT LINE UNIVERSE NEO™ TROPEA NEO™ UNIVERSE TROPEA HIGH LINE LAGUNA NEO™ OCEANIC HIGH VISION™...
-
Page 3: Key To Symbols
User’s Manual is required. Keep the User’s Manual / Warranty Card in a safe place. ALUKOV a.s. keeps upgrading its products by using new materials and applying the latest developments trends within the field. The quality of our products are checked and certified by professionals in the area of quality control ISO 9001, environment ISO 14001 and the French research institute LABORATOIRE NATIONAL D‘... - Page 4 Used Materials: PROFILES Aluminium alloy: AlMgSi 0.5 F 22 Standard: EN-AW-6063 T6, EN-AW-6060 T6 section strength within the range 180 - 250 N/MPa Surface finish: white powder color RAL 9010, beige powder color RAL 1015, anthracite charcoal powder color - special finish DB 703, silver powder color RAL 9006, antique brown, powder color surface finish - wood imitation, natural anodizing C-0 layer 15 -20 μm and brown anodizing C-33 layer 15 - 20 μm (applicable just for guide leading lines) Thickness of walls sections:...
- Page 5 (to see the procedure for removing snow, please visit http://www.alukov.cz/lang-cs/videa-realizace-zastreseni-bazenu). When the construction is loaded with snow or other things, it is strictly forbidden to enter the swimming pool, spa or patio enclosure.
-
Page 6: Declaration Of Conformity
WARRANTY TERMS 1. ALUKOV a.s. / IPC TEAM provides 3-year warranty for product functionality, starting on the date when the enclosure is handed over to the customer. The ma- nufacturer writes the date of handover in the warranty card. The warranty covers faults which may occur during the warranty period as a result of material defects or an error in the manufacturing process. -
Page 7: Certificate Of Warranty
CERTIFICATE OF WARRANTY Type and size of enclosure: Production No.: Stamp, signature and telephone number of supplier: Handover/Receipt: COMPLAINT SHEET Complaint: Date of receipt: Date of delivery:... - Page 8 Spare parts / In case of damage or loss, these spare parts can be ordered: STANDARD latch sliding latch (92.003) (31.534 right, 31.536 le ) Insert into pavement (31.512) KOMFORT latch narrow blind flange of the corner section (92.001 right, 92.002 le ) - progres 110°...
- Page 9 blind flange of the bottom travel SPA blind flange KOMFORT (31.923 le , 31.922 right) (31.543 right, 31.542 le ) door handle blind flange of the corner section (31.537 black) (31.509) cam lock blind flange of the corner section (21.425 + 21.426) small (31.572) door fastener blind flange of the door rail...
- Page 10 catch blind stop for NEO™ line - non-locking catch blind stop for NEO™ line - locking (31.357 right, 31.356 le ) (31.359 right, 31.358 le ) blind stop for NEO™ line - full side entrance blind stop for NEO™ line (31.348 right, 31.347 le ) (31.278 right, 31.277 le ) EASY UP blind stop for NEO™...
- Page 11 Possible means of securing the roofing structure against the weather Automatic latching of segments STANDARD KOMFORT PROGRES EASY-UP 1 / Secured 1 / Secured 2 / Released 2 / Released Securing the front wall 3 / Securing pin - Bent pin 4 / Adjustment pins...
- Page 12 Appendix 1A Unlocking the front walls 1B Locking the front walls 2A Manually unlocking segment latches 2B Manually locking segment latches 2C Automatically latching segments...
- Page 13 3A Unlocking the door 3B Locking the door Easy Up Plus - unlock Easy Up Plus - lock Easy Up - unlock Easy Up - lock 1 Climate latch - use only if the weather is getting worse (e.g. strong or gusty wind, massive rainfall) 2 Automatic latch - used for standard daily locking of segments Notes...
- Page 14 ALUKOV a.s. Orel 18, Slatiňany 538 21, Czech Republic Tel.: +420 469 681 488 Fax: +420 469 681 321 E-mail: info@alukov.cz www.alukov.cz COMPLETE YOUR HOME...
