Refrigerator-Freezer
OPERATING INSTRUCTIONS
Non-Freon Refrigerators
This refrigerator uses non-Freon refrigerant (isobutane) and non-Freon foam insulation (cyclopentane).
These materials are harmless to the environment and do not affect the ozone layer and global warming.
.
Maintenance work shall only be carried out at workshop by well-trained maintenance worker.
.
Please read this manual carefully and follow the information contained within. In particular, be sure to read the safety precautions before using this refrigerator.
.
Be sure to receive your copy of the warranty from the retailer and confirm that the purchase date and retailer name are written on the warranty.
.
Store this operating instructions manual and the warranty in a safe place.
.
This refrigerator was manufactured for refrigerating and freezing of foods in general households. For commercial use, please use a commercial refrigerator-freezer.
.
The principal plastic components indicate the material name to facilitate recycling.
.
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
.
This appliance is intended to be used in household application only.
.
WARNING - When positioning the appliance, ensure the supply cord is not trapped or damaged.
.
WARNING - Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
.
WARNING - Just in case of having damaged the refrigerant circuit, do not use electric items or fire equipments near by, and open the window to ventilate the room.
And contact the retail store at which you purchased it or the following MITSUBISHI SERVICE CENTRE.
.
WARNING - Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
.
WARNING - Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
.
The user manual should be handed over to any person who would use or handle the refrigerator whenever the refrigerator would be transferred to another location and
delivered to a recycling plant.
.
This refrigerator uses flammable foaming gas for insulation. Please deliver the unit to specialized industrial waste dealer when you do away it. Please follow the rules in your country.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
SERIES MODEL
MR-CX56ET
MR-CGX56ET
Contents
目錄
Refrigerator / Sliding case / Vegetable and Freezer Compartments
Page
2 - 3
4 - 5
6 - 8
9
1 0 - 1 1
1 2 - 1 3
1 4
1 5 - 1 6
1 6 - 1 8
1 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MR-CX56ET Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric MR-CX56ET Series

Summary of Contents for Mitsubishi Electric MR-CX56ET Series

  • Page 1: Table Of Contents

    SERIES MODEL MR-CX56ET MR-CGX56ET Refrigerator-Freezer Contents 目錄 Page OPERATING INSTRUCTIONS For your safety, please be sure to follow these instructions 2 - 3 From installing to running your refrigerator 4 - 5 Using each compartment 6 - 8 Refrigerator / Sliding case / Vegetable and Freezer Compartments How to adjust the temperature Automatic Ice-Maker 1 0 - 1 1...

  • Page 2: For Your Safety, Please Be Sure To Follow These Instructions

    If the power cord is damaged call Mitsubishi Electric a person responsible for their safety. Children should be Service Centre for a technician to replace power cord.
  • Page 3 When something abnormal or unusual occurs, turn off immediately and consult with “the store where you purchased the unit” or with a “Mitsubishi Electric repair centre.” CAUTION WARNING About using your refrigerator Installing and Transporting Do not use in a shed or a garage.

  • Page 4: From Installing To Running Your Refrigerator

    From installing to running your refrigerator From installing to running your refrigerator Installation Turning on the power / installing an earth wire 5 cm. or more Lower back section To get the refrigerator 10 cm. or more cooled down faster, plug it in right after installing.
  • Page 5 Start using (to provide half-opened Adjustment and affixing door/noise/move/vibrate) ● It takes time to cool down. Put in warm food items or ice Turn the adjustable legs to get Turn in the direction of cream after the refrigerator has them to touch the floor, then affix. the arrows and lower been adequately cooled down.

  • Page 6: Using Each Compartment

    Using each compartment Refrigerator / Sliding case Refrigerator / Sliding case Insert drinks or immediately used foods in refrigerator compartment. Sliding case can store meats, fish, dairy products, processed foods, etc. at a lower temperature than the refrigerator compartment. How to remove shelf, pocket, case Page 13 ➡...
  • Page 7 At the time of purchase, the lower case is not set Sliding Cases to Supercool Chilling. When setting Supercool Chilling, use the following settings. :KHQ ORZHU FDVH VHW LV VXSHUFRRO FKLOOLQJ Lower Case 2QO\ ZLWK 05&*;(7 Sliding Case(Lower) Supercool chilling stocker 2QO\ ZLWK 05&*;(7 The freshness of meat and fish can be Upper Case...

  • Page 8: Freezing Case (Upper)

    Vegetable compartment Vegetable compartment Approx. 3℃〜9℃ Please insert fruit, vegetables and drinks. If you wrap fruit and vegetables, they will stay fresh longer. Sliding Case For smaller items that get damaged easily such as tomatoes and fruit. Vegetables Case LED light in the vegetable case The LED light with specially selected light spectrum installed in the Vegetable compartment can increase the Vitamin C and preserve freshness in green vegetables...

  • Page 9: How To Adjust The Temperature

    How to adjust the temperature How to adjust the temperature You can stop ice-making, adjust the temperature in refrigerator/freezing compartment by using the operation unit in the back of the refrigerator compartment. Supercool chilling setting (Only with MR-CGX56ET) Status of supercool chilling light (green) Green light off…Supercool chilling is unset.

  • Page 10: Automatic Ice-Maker

    Automatic Ice-Maker Automatic Ice-Maker You can make ice cubes by puting water in the water supply tank of the refrigerator compartment. Please do periodically maintain to make a good ice cube by cleaning. Please drain the water in the water supply tank when you do not make ice. About the first batches of ice.
  • Page 11 Press button Press button Red light To stop To restart when the ice-making when the ice-making Press stop light (red) is off. stop light (red) is on. ice-making ice-making The ice-making stop The ice-making stop light (red) will turn on. light (red) will turn off.

  • Page 12: How To Remove And Clean Accessories

    Soot and dust Remove the toe grille. purchased or contact MITSUBISHI ELECTRIC SERVICE CENTER or its service agent. Turn the adjustable supports to raise them from the floor,and pull out the refrigerator.

  • Page 13: Toe Grille

    Use reverse procedures to put accessories back in place. Glass shelf / One-two shelf Lift up the front side with both hands. Pull forward and take out. ※ If forcefully pulled outward damage may occur to door side. Please slowly pull and take out. To ensure that glass side is attached or removed.

  • Page 14: How To Maintain Your Automatic Ice-Maker

    How to maintain your automatic ice-maker How to maintain your automatic ice-maker Please do periodic care to prevent the occurrence of water Do not use a dishwasher or dryer ※ scale, mold, etc. Please remove water when not making ice. because it may cause deformation.

  • Page 15: What To Do In These Situations

    What to do in these situations What to do in these situations When there’s a power failure ・ Minimize opening/closing of doors and avoid putting in more food. When not in use for a long time (Remove the power plug) Clean the auto ice-maker.

  • Page 16: Troubleshooting 1 6 - 1

    What to do in these situations What to do in these situations (continue) (continue) When alarm rings continuously Make sure that each door closes without any gaps. Inspection is required due to a possibility that an abnormality has occurred. Please contact the store where you purchased the unit. How to stop alarm (PiPi continuous sound) You can stop alarm sound temporarily.
  • Page 17 Troubleshooting Troubleshooting (continue) (continue) If this happens… Please check this out. Please do this. This is the reason. Is the temperature in lower case Please adjust the temperature to Food in the lower set to [Supercool chilling] ? [Supercool chilling]. Page 7 ➡...
  • Page 18 Troubleshooting Troubleshooting (continue) (continue) If this happens… Please check this out. Please do this. This is the reason. Sometimes there are sounds like “shuu” This is the sound of refrigerant (gas) flowing It’s got a loud sound or “plub-plub” (boiling water sound) through.

  • Page 19: Accessories

    Accessories Accessories Model name MR-CX56ET MR-CGX56ET Accessories Quantity Quantity Adjustable shelf One-two shelf Sliding case (upper) Sliding case (lower) Water supply tank (including purification filter) Free pocket (large) Free pocket (small) Small-Item pocket Free egg tray Bottle pocket Bottle stopper Vegetable case Sliding case Freezing case (upper)
  • Page 20 MEMO MEMO...
  • Page 21 MITSUBISHI ELECTRIC BUILDING SINGAPORE 159943 Head Office: Tel. (65) 6473-2308 SOLE AGENT in Malaysia MITSUBISHI ELECTRIC SALES MALAYSIA SDN. BHD. (CO.NO.:11098W) LOT 11, JALAN 219, PO BOX 1036, 46860, PETALING JAYA, SELANGOR DARUL EHSAN, MALAYSIA. Head Office: Tel. (603) 7955-2088 (10 lines)
