DOT – V454939
Intimate care shower set Voxort DOT Black , with valve for cold
Intimpflege-Duschset Voxort DOT Black, mit Kaltwasserventil
Tuš set za intimno nego Voxort DOT Black z ventilom za hladno vodo
Tuš set za intimnu njegu Voxort DOT Black, sa ventilom za hladnu vodu
Accessories checking:
Please double-check the
accessories list and contact
the distributor for any
unconformity
Remakrs:
-without affecting their
performancing, accessories
may be changed without
further notice
-drawings for reference only,
product size & shape do not
refer to actual faucet.
Fero-Term d.o.o.
Gospodarska 17,
10255 D.Stupnik, HR
Tel.+385 1 434 3116
info@fero-term.hr
Installation instruction / Montageanleitung
Upute za montažu / Navodila za montažo
Überprüfung des Zubehörs:
Bitte überprüfen Sie die Zubehörliste
und wenden Sie sich an den Händler
bei Abweichungen
Anmerkung:
- ohne die Leistung zu
beeinträchtigen, kann das Zubehör
ohne weitere Benachrichtigung
geändert werden
-Zeichnungen dienen nur als
Referenz. Produktgröße & Form
entsprechen nicht den tatsächlichen
Mischer.
No.
1
2
3
4
5
6
Fero-Term - Slovenia
Kajuhova 32T
10000 Ljubljana, SLO
info@fero-term.si
Provjera pribora:
Molimo prije postavljanja
provjerite popis pribora i
kontaktirate distributera u
slučaju odstupanja.
Napomena:
-Bez utjecaja na performanse
proizvoda, pribor može biti
promijenjen bez najave.
-Tehnički crteži služe samo za
referencu. Veličina proizvoda i
oblik ne odgovara stvarnoj
miješalici.
Beschreiung / Description / Opis /Opis
Kaltwasserventil / cold water valve / ventil za
hladnu vodu /ventil za hladno vodo
Siegel /Seal /Brtva /Pečat
Handbrausehalter/ Shower handset holder/
Držač za tuš slušalicu/ Držalo za tuš slušalko
Brauseschlauch / shower hose / tuš crijevo / cev
za tuš
Rozette / flange / rozeta /rozeta
Handbrause / hand shower / tuš slušalica / tuš
ročka
Kontrola orodja:
Prosimo, da pred
postavljanjem preverite
seznam orodja in v primeru
odstopanj kontaktirate
distributerja. Opomba:
-Brez vpliva na performanse
izdelka, orodje je lahko
spremenjeno brez napovedi.
Tehnične risbe služijo samo
za referenco. Velikost izdelka
in oblika ne ustrezata
dejanskemu mešalniku.
Servis:
Fero-Term d.o.o.
Gospodarska 17,
10255 D. Stupnik, HR
01/ 434-3116
servis@fero-term.hr
STK /
QTY /
KOL
1
1
1
1
