IRIS
VOXORT Sink mixer IRIS 56461B /VOXORT Spültischbatterie IRIS 56461B /
VOXORT Armatura za kuhinjo IRIS 56461B / VOXORT miješalica za sudoper IRIS 56461B / N14933
Accessories checking:
Please double-check the
accessories list and contact
the distributor for any
unconformity
Remakrs:
-without affecting their
performancing, accessories
may be changed without
further notice
-drawings for reference only,
product size & shape do not
refer to actual faucet.
EN: Installation Instructions:
-
Do not disassamble the main body, as it has been installed & commissioned correctly & precisely before
leaving the factory
-
To avoid the faucet from jamming, do flush the water pipe before installation
-
After installation, make sure every joint safely sealed & no leaking
Fero-Term d.o.o.
Gospodarska 17,
10255 D.Stupnik, HR
Tel.+385 1 434 3116
info@fero-term.hr
Installation instruction / Montageanleitung
Upute za montažu / Navodila za montažo
Überprüfung des Zubehörs:
Bitte überprüfen Sie die Zubehörliste
und wenden Sie sich an den Händler
bei Abweichungen
Anmerkung:
- ohne die Leistung zu
beeinträchtigen, kann das Zubehör
ohne weitere Benachrichtigung
geändert werden
-Zeichnungen dienen nur als
Referenz. Produktgröße & Form
entsprechen nicht den tatsächlichen
Mischer.
No.
1
2
3
4
5
Anschlussschlauch / inlet pipe / spojne cijevi /
6
Fero-Term - Slovenia
Kajuhova 32T
10000 Ljubljana, SLO
info@fero-term.si
Provjera pribora:
Molimo prije postavljanja
provjerite popis pribora i
kontaktirate distributera u
slučaju odstupanja.
Napomena:
-Bez utjecaja na performanse
proizvoda, pribor može biti
promijenjen bez najave.
-Tehnički crteži služe samo za
referencu. Veličina proizvoda i
oblik ne odgovara stvarnoj
miješalici.
Beschreiung / Description / Opis / Opis
Körper / body / tijelo /telo
Gewindehülse / threaded sleeve / vijak za
pričvršćivanje / vijak za pritrjevanje
O-Ring / O-Ring / O-Ring / O-Prstan
Dichtung / wacher / brtva / Tesnilo
Gegenverschraubung / fixed nut / matica za
fiksiranje / matica za fiksiranje
spojne cevi
Kontrola orodja:
Prosimo, da pred
postavljanjem preverite
seznam orodja in v primeru
odstopanj kontaktirate
distributerja.
Opomba:
-Brez vpliva na performanse
izdelka, orodje je lahko
spremenjeno brez napovedi.
Tehnične risbe služijo samo
za referenco. Velikost izdelka
in oblika ne ustrezata
dejanskemu mešalniku.
STK / QTY
/ KOL / KOL
Servis:
Fero-Term d.o.o.
Gospodarska 17,
10255 D. Stupnik, HR
01/ 434-3116
servis@fero-term.hr
1
1
1
1
1
2
