Model 682B01
DIN rail mount 24 VDC power supply, 120-230 VAC input
Installation and Operating Manual
For assistance with the operation of this product,
contact the PCB Piezotronics, Inc.
Toll-free: 800-959-4464
24-hour SensorLine: 716-684-0001
Fax: 716-684-3823
E-mail: imi@pcb.com
Web: www.imi-sensors.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMI SENSORS 682B01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PCB Piezotronics IMI SENSORS 682B01

Summary of Contents for PCB Piezotronics IMI SENSORS 682B01

  • Page 1 Model 682B01 DIN rail mount 24 VDC power supply, 120-230 VAC input Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 800-959-4464 24-hour SensorLine: 716-684-0001 Fax: 716-684-3823 E-mail: imi@pcb.com Web: www.imi-sensors.com...
  • Page 2  Assistance is needed to safely operate equipment  PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected  calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
  • Page 3 CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
  • Page 4 PCB工业监视和测量设备 - 中国RoHS2公布表 PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table 有害物质 镉 汞 铅 (Pb) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 部件名称 (Hg) (Cd) 住房 PCB板 电气连接器 压电晶体 环氧 铁氟龙 电子 厚膜基板 电线 电缆 塑料 焊接...
  • Page 5 Component Name Hazardous Substances Lead (Pb) Mercury (Hg) Cadmium (Cd) Chromium VI Polybrominated Polybrominated Compounds Biphenyls (PBB) Diphenyl Ethers (Cr(VI)) (PBDE) Housing PCB Board Electrical Connectors Piezoelectric Crystals Epoxy Teflon Electronics Thick Film Substrate Wires Cables Plastic Solder Copper Alloy/Brass This table is prepared in accordance with the provisions of SJ/T 11364.
  • Page 6 The following manual for the QUINT4-PS/1AC/24DC/1.3/PT power supply unit has been provided by Phoenix Contact GmbH & Co. KG. This manual was last downloaded from the https://www.phoenixcontact.com/en-us/ website on 08/01/2023. QUINT POWER and the PHOENIX CONTACT design trademark are registered trademarks of Phoenix Contact GmbH &...

  • Page 7: Description

    QUINT4-PS/1AC/24DC/1.3/PT Power supply unit Data sheet 108338_en_00 © PHOENIX CONTACT 2017-12-20 Description QUINT POWER power supplies are exceptionally small yet offer superior system availability in the sub 100 W power Technical data (short form) range. Input voltage range 100 V AC ... 240 V AC -15 % ... +10 % Powerful Mains buffering...

  • Page 8: Table Of Contents

    QUINT4-PS/1AC/24DC/1.3/PT Table of contents Description ..........................1 Table of contents ........................2 Ordering data .......................... 3 Technical data ......................... 4 Safety and installation notes ....................12 High-voltage test (HIPOT) ..................... 13 ..............13 High-voltage dielectric test (dielectric strength test) ............13 High-voltage dielectric test during the manufacturing process ...............

  • Page 9: Ordering Data

    QUINT4-PS/1AC/24DC/1.3/PT Ordering data Description Type Order No. Pcs./Pkt. Primary-switched QUINT POWER power supply with QUINT4-PS/1AC/24DC/1.3/ 2909575 Push-in connection for DIN rail mounting, input: single- phase, output: 24 V DC / 1.3 A Accessories Type Order No. Pcs./Pkt. Pluggable device protection, according to type 3/class III, PLT-SEC-T3-230-FM 2905229 for 1-phase power supply networks with separate N and...

  • Page 10: Technical Data

    QUINT4-PS/1AC/24DC/1.3/PT Technical data Input data Unless otherwise stated, all data applies for 25°C ambient temperature, 230 V AC input voltage, and nominal output current (I Input voltage range 100 V AC ... 240 V AC -15 % ... +10 % 110 V DC ... 250 V DC -20 % ... +40 % Electric strength, max.
  • Page 11 QUINT4-PS/1AC/24DC/1.3/PT Electric strength of the insulation Housing Input Signaling Output Type test (IEC/EN 60950-1) 4 kV AC Production test 3 kV AC Field test 2 kV AC POWER factor = U : 120V AC/U : 24 V DC = U : 230V AC/U : 24 V DC Crest factor 120 V AC 230 V AC...
  • Page 12 QUINT4-PS/1AC/24DC/1.3/PT Input connection data Connection method Push-in technology Conductor cross section, solid 0.2 mm² ... 2.5 mm² Conductor cross section, flexible 0.2 mm² ... 2.5 mm² Stranded conductor cross section with ferrule 0.25 mm² ... 2.5 mm² Conductor cross section AWG 24 ...
  • Page 13 QUINT4-PS/1AC/24DC/1.3/PT Signal contact (adjustable) Digital 0 / 24 V DC , 30 mA Default 24 V DC , 30 mA ( 24 V DC for U > 0.9 x U Signal connection data Connection method Push-in technology Conductor cross section, solid 0.2 mm² ... 2.5 mm² Conductor cross section, flexible 0.2 mm²...
  • Page 14 QUINT4-PS/1AC/24DC/1.3/PT Efficiency 120 V AC 230 V AC typ. 89.2 % typ. 90.7 % = U : 120V AC/U : 24 V DC = U : 230V AC/U : 24 V DC Ambient conditions Ambient temperature (operation) -25 °C ... 70 °C (> 60 °C Derating: 2.5 %/K) The ambient temperature (operation) refers to IEC 61010 surrounding air temperature.
  • Page 15 QUINT4-PS/1AC/24DC/1.3/PT Electromagnetic compatibility CE basic standard Minimum normative Higher requirements in requirements practice (covered) Conducted noise emission EN 55016 EN 61000-6-4 (Class A) EN 61000-6-3 (Class B) Noise emission EN 55016 EN 61000-6-4 (Class A) EN 61000-6-3 (Class B) Harmonic currents EN 61000-3-2 not required 0 kHz ...
  • Page 16 QUINT4-PS/1AC/24DC/1.3/PT CE basic standard Minimum normative Higher requirements in requirements of EN 61000- practice (covered) 6-2 (CE) (immunity for industrial environments) Signal 0.5 kV (Test Level 2 - 0.5 kV (Test Level 2 - symmetrical) symmetrical) 0.5 kV (Test Level 1 - 1 kV (Test Level 2 - asymmetrical) asymmetrical)
  • Page 17 QUINT4-PS/1AC/24DC/1.3/PT Basic standard Minimum normative Higher requirements in requirements of EN 61000- practice (covered) 6-5 (power station equipment, zone 1, 2) Comments Criterion B Criterion A Asymmetrical conducted disturbance variables EN 61000-4-16 Input, Output, Signals 50 Hz , 60 Hz , 10 V 16.67 Hz , 50 Hz , 60 Hz , 30 V (Permanent) ( Test Level 3 ) (10 s) ( Test Level 2 )

  • Page 18: Safety And Installation Notes

    QUINT4-PS/1AC/24DC/1.3/PT Safety and installation notes Safety notes and warning instructions Symbols used WARNING: Danger to life by electric shock! Instructions and possible hazards are indicated by corresponding symbols in this document. – Only skilled persons may install, start up, and operate This is the safety alert symbol.

  • Page 19: High-Voltage Test (Hipot)

    QUINT4-PS/1AC/24DC/1.3/PT High-voltage test (HIPOT) High-voltage dielectric test performed by the customer This protection class II power supply is subject to the Low Apart from routine and type tests to guarantee electrical Voltage Directive and is factory tested. During the HIPOT safety, the end user does not have to perform another high- test (high-voltage test), the insulation between the input voltage test on the power supply as an individual...
  • Page 20 QUINT4-PS/1AC/24DC/1.3/PT 6.3.1 Performing high-voltage testing If high-voltage testing of the control cabinet or the power supply as a stand-alone component is planned during final inspection and testing, the following features must be observed. – The power supply wiring must be implemented as shown in the wiring diagram.

  • Page 21: Structure Of The Power Supply

    QUINT4-PS/1AC/24DC/1.3/PT Structure of the power supply Device dimensions The fanless convection-cooled power supply can be 22,5 snapped onto all DIN rails according to EN 60715. Function elements 3.1 2.1 2.2 − Output DC 24V 1.3A 24-28V 3.1 2.1 2.2 Signal (SIG) + −...

  • Page 22: Keep-Out Areas

    QUINT4-PS/1AC/24DC/1.3/PT Keep-out areas 22,5 − Output DC 24V 1.3A 24-28V Signal (SIG) P >P Boost > 100% > 75% > 50% DC OK Input AC 100-240V − + 1.1 1.2 Figure 5 Device dimensions and minimum keep-out areas (in mm) The minimum clearance to other devices to the left and right is 0 mm.

  • Page 23: Block Diagram

    QUINT4-PS/1AC/24DC/1.3/PT Block diagram active DC OK Figure 6 Block diagram Symbol Designation Symbol Designation Filter Optocoupler (electrically isolating) Current limitation Additional regulatory protection against surge voltage Rectification Microcontroller Inrush current limitation PNP transistor switch output Power factor correction (PFC) Rotary selector switch active Switching transistor and main transmitter Signal/display LEDs (P...

  • Page 24: Mounting/Removing The Power Supply

    QUINT4-PS/1AC/24DC/1.3/PT Mounting/removing the power supply Mounting the power supply unit Proceed as follows to mount the power supply: The power supply is mounted in the normal mounting position from above onto the 35 mm DIN rail (DIN EN 60715). Make sure that the integrated snap-on foot is in the correction position behind the DIN rail (A).

  • Page 25: Fix Connection Wiring To The Power Supply

    QUINT4-PS/1AC/24DC/1.3/PT Fix connection wiring to the power supply – Shorten the excess length of the cable binder ends. – Then check again that the connection wiring is properly Two receptacles for the bundled attachment of the secured. connection wiring are integrated in the left and right housing panel.

  • Page 26: Device Connection Terminal Blocks

    QUINT4-PS/1AC/24DC/1.3/PT Device connection terminal blocks Protection of the primary side Installation of the device must correspond to EN 61010 The AC input and DC output terminal blocks on the front of regulations. It must be possible to switch off the device using the power supply feature Push-in connection technology.

  • Page 27: Output

    QUINT4-PS/1AC/24DC/1.3/PT Output By default, the power supply is pre-set to a nominal output voltage of 24 V DC. The output voltage is adjusted using the potentiometer. Protection of the secondary side The power supply is electronically short-circuit-proof and no-load-proof. In the event of an error, the output voltage is limited If sufficiently long connecting cables are used, fuse protection does not have to be provided...

  • Page 28: Output Characteristic Curves

    QUINT4-PS/1AC/24DC/1.3/PT Output characteristic curves The U/I output characteristic curve is optimized for the following applications: – When supplying loads with high switch-on currents, such as motors. The dynamic boost of the power supply supplies up to 200% of the nominal power for 5 s. This ensures that sufficient reserve energy is available;...

  • Page 29: Boost Currents

    QUINT4-PS/1AC/24DC/1.3/PT Boost currents The power supply provides the static boost (I ) for a Stat.Boost sustained load supply or the time-limited dynamic boost Dyn.Boost 11.1 Static Boost For system expansion purposes, the sustained static boost ) supports the load supply with up to 125% of the Stat.Boost nominal current of the power supply.

  • Page 30: Signaling

    QUINT4-PS/1AC/24DC/1.3/PT Signaling 12.3 Location and function of the signaling elements For signaling and the functional monitoring of the power supply two LEDs and an active signal output are available. Using the rotary selector select the required functional monitoring. The monitoring of the output voltage (DC OK) or −...

  • Page 31: Active Signal Outputs, Digital

    QUINT4-PS/1AC/24DC/1.3/PT 12.4 Active signal outputs, digital Signals are routed to a superordinate controller via the digital signal output "3.1 SIG". The 24 V DC signal is applied between the connection − terminal blocks "3.1 SIG" and "2.2 -". The maximum load is Output DC 30 mA. Signal (SIG) Digital Input P >P...

  • Page 32: Operating Modes

    QUINT4-PS/1AC/24DC/1.3/PT Operating modes 13.2 Parallel operation You can connect several power supplies in parallel in order Depending on the intended use, the power supply can be to increase the power or to supply the loads redundantly. run in series or parallel operation. 13.1 Series operation −...
  • Page 33 QUINT4-PS/1AC/24DC/1.3/PT 13.2.1 Redundancy operation 13.2.2 Increased power Redundant circuits are suitable for supplying systems and When n power supplies are connected in parallel, the output system parts which place particularly high demands on current is increased to n x I .

  • Page 34: Derating

    QUINT4-PS/1AC/24DC/1.3/PT Derating 14.2 Installation height The power supply can be operated at an installation height The QUINT POWER power supply runs in nominal of up to 2000 m without any limitations. Different data operation without any limitations. For operation outside the applies for installation locations above 2000 m due to the nominal range, the following points should be observed differing air pressure and the reduced convection cooling depending on the type of use.
