MAYA UPHOLSTERED BED
FULL/QUEEN ASSEMBLY
BOX#1
A. HEADBOARD
A
BOX#2
B.
SIDE RAIL
C. FOOTBOARD
D. SLAT
E.
CENTER SLAT SUPPORT
F. SIDE RAIL SLAT CLIP
G. CENTER SUPPORT SLAT CLIP
H. SLAT SUPPORT LEG
B
D
F
H
INSTRUCTIONS
1 PC
2 PCS
1
PC
39
PCS
2
PCS
26
PCS
26
PCS
4
PCS
C
E
G
HARDWARE KIT PACKED IN BOX #2
1
ALLEN
BOLT(5/16"x1-1/4")
2
ALLEN
BOLT(5/16"x2-1/2")
3
FLAT WASHER(5/16")
LOCK WASHER(5/16")
4
5
ALLEN KEY 5/16")
(
FULLY ASSEMBLED
8 PCS
4 PCS
12 PCS
12 PCS
1 PC
x2
00:30
Advertisement
Related Manuals for Modus Furniture MAYA
Summary of Contents for Modus Furniture MAYA
- Page 1 MAYA UPHOLSTERED BED FULL/QUEEN ASSEMBLY INSTRUCTIONS BOX#1 HARDWARE KIT PACKED IN BOX #2 A. HEADBOARD 1 PC ALLEN BOLT(5/16"x1-1/4") 8 PCS ALLEN BOLT(5/16"x2-1/2") 4 PCS FLAT WASHER(5/16") 12 PCS LOCK WASHER(5/16") 12 PCS ALLEN KEY 5/16") 1 PC FULLY ASSEMBLED...
- Page 2 MAYA UPHOLSTERED BED C.KING/E.KING ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 STOP IF USING BED WITH AN ADJUSTABLE MATTRESS BASE, SKIP STEPS3,4,5,& 6 AND REFERENCE APPENDIX A: ADJUSTABLE MATTRESS BASE ASSEMBLY SUPPLEMENT. IF USING BED FRAME WITH STANDARD BOX SPRING OR FOUNDATION, CONTINUE TO STEP 3.
- Page 3 MAYA UPHOLSTERED BED C.KING/E.KING ASSEMBLY INSTRUCTIONS STEP 4 5: STARTING FROM HEADBOARD STEP STEP UPDATED:FEBRUARY 22ND,2024...
-
Page 4: Maintenance Instructions
MAYA UPHOLSTERED BED C.KING/E.KING ASSEMBLY INSTRUCTIONS ASSEMBLY COMPLETE. MAINTENANCE INSTRUCTIONS: INSTRUCTIONS FOR ADJUSTING LEVELERS: POSITION THE BED IN YOUR ROOM. LOCATE LEVELERS UNDER EACH SUPPORT LEG ( H ). TURN COUNTER-CLOCKWISE TO EXTEND, CLOCKWISE TO RETRACT . ADJUST LEVELERS UNTIL EACH LEG SUPPORT IS APPLYING EQUAL UPWARD PRESSURE ON THE CENTER SLAT. -
Page 5: Appendix A:adjustable Mattress Base Assembly Supplement
MAYA UPHOLSTERED BED C.KING/E.KING ASSEMBLY INSTRUCTIONS APPENDIX A:ADJUSTABLE MATTRESS BASE ASSEMBLY SUPPLEMENT AN ADJUSTABLE MATTRESS BASE IS A FREESTANDING MATTRESS SUPPORT THAT SITS WITHIN THE PERIMETER OF THE BED FRAME. IF USING THIS BED FRAME WITH A STANDARD BOX SPRING OR FOUNDATION THESE INSTRUCTIONS DO NOT APPLY.
