Index Important Safety Information..............3 Identification of Key Parts..............4 Electric Diagram..................4 Specification...................5 Installation Of Your Warming Cabinet..........5 Using Your Warming Cabinet..............6 Food Setting Guide................7 Cleaning & Maintaining Your Warming Cabinet........8 Troubleshooting..................8 Exploded View..................8-9...
IMPORTANT SAFETY INFORMATION When using electrical appliances basic safety precautions should always be followed, including the following: 1. Read all instructions carefully and completely. 2. For commercial use only. 3. Do not touch hot surfaces. 4. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids.
Identification of Key Parts 1. Main body 2. Door 3. Power switch 4. Temperature display 5. Temperature regulator 6. Heat & Proof switch 7. Humidity regulator 8. Water pan 9. Caster wheel 10. Corner guard 11. Power cord Electric Diagram...
Specification Installation Of Your Warming Cabinet All electrical connections must comply with the voltage, hertz and wattage shown in the chart above. The installation must be done by qualified personnel. It is highly recommended that you ONLY use the power cord supplied with the cabinet. All models are free-standing, place the cabinet in a stable, level surface, and leave enough space (suggested 4”...
Proofing instructions 1. Set module switch to “Proof”. 2. Set “Power” switch to “ ▌” position, power indicator light turn on. 3. Set “Temperature” control to “2”. 4. Set “Humidity” control to “9”. 5. Pre-heat cabinet until desired temperature and humidity is reached (usually heat-up time from 77°F(25°C) ambient to 95°F(35°C) and 95% relative humidity is approximately 30 minutes).
NOTE: 1. Water pan must be in place during operation. 2. Unplug cabinet from wall and allow cabinet (and water) to cool before cleaning or servicing. 3. Do not spray or pour water on the module when cleaning and do not immerse the module in water.
Exploded View Part Name Quantity Main body Door assembly Water Pan Caster wheel Corner Guard Power cord...
Page 9
Part Name Quantity Heating element-2-120V/900W Heating element-3-120V/600W Power switch Temperature display Temperature control knob Heat & Proof switch Thermostat Fan motor Ceramic terminal Power cord clip Power cord SUS GN pan Heating element-1 120V/600W NOTE: A. heating element-3 plus heating element-1 is for proofing B.
