1200 PRO
STUDENT DESK
Parts List (11 parts)
1. Side Left
x 1
2. Side Right
x 1
3. Top Panel
x 1
4. Box Side
x 1
5. Box Bottom
x 1
6. Cleat (front of unit)
x 1
Make sure you have all the parts listed and organize them by
type and size. You will also need a Phillips or star screwdriver.
6
1
mecofurniture.co.za
7. Drawer Front
x 1
8. Drawer Side
x 2
9. Drawer Rear
x 1
10. Drawer Bottom 3mm
x 1
3
4
4
5
ASSEMBLY
INSTRUCTIONS
Hardware
Confirmat Screws (use
A
the supplied Allen Key)
B
Allen Key
Cams
C
D
Cam Pins
Set of Drawer Runner 350mm
E
with Runner screw
F
Slimline Handle
Cable Outlet
G
Glides
H
Attached to parts no action needed
8
7
9
2
CLEANING INSTRUCTIONS
NB: Clean with a damp cloth only.
Excessive water will cause damage, voiding the warranty.
x 8
x 1
x 9
x 9
x 1
x 6
x 1
x 1
x 4
9
