SWEDEN TV STAND
Parts List (18 parts)
1.
Left Side
2.
Right Side
3.
Divider
4.
Bottom Panel
5.
Top Panel
6.
Large Shelf
PIVOT HINGE
1
mecofurniture.co.za
7.
x 1
Door
x 1
8.
Drawer Backing 3mm
9.
x 1
Unit Backing 3mm
10.
x 1
Drawer Front
x 1
11.
Drawer Sides
12.
x 1
Drawer Rear
9
7
INSTRUCTIONS
Hardware
Confirmat Screws (use
A
the supplied Allen Key)
x 1
B
Allen Key
x 2
x 1
C
Sofa Legs
x 2
D
G-Screws
x 4
x 2
E
Cams
F
Cam Pins
G
Drawer Runners
H
Flat Runner Screws
I
4x16 Screws
Magnetic Catch & Plate
J
(3 x small brass screws)
Pivot Hinge with Spacers
K
(4 x screws)
5
3
6
4
CLEANING INSTRUCTIONS
NB: Clean with a damp cloth only.
Excessive water will cause damage, voiding the warranty.
ASSEMBLY
x 10
x 1
x 4
x 16
x 14
x 14
2
sets
x 12
x 18
x 3
2
sets
8
10
11
2
12
