Quoizel DAY8407EK Installation Manual

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, install or
operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the
circuit breaker box or the main fuse box.
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
TOOLS REQUIRED
CARE AND MAINTENANCE
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
PACKAGE CONTENTS
Fixture Body
A
x 1
INSTALLATION
Install lnner Backplate
1
INSTALLATION GUIDE FOR DAY840 EK
Glass Shade
B B x 1
Lock Screw
(preassembled
C
on Fixture Body)
x 2
Rubber Washer
(preassembled
D
on Fixture Body)
x 2
MOUNTING HARDWARE
Inner Backplate
AA
x 1
Mounting Screw
BB
x 4
Wiring
2
White wire from supply
Black (or red) wire from supply
Ground wire from supply
Green ground screw
- 1 of 2 -
7
Released Date: 202 - 4 04-30
120Vac, 60Hz
Model No.
Rating
DAY840 EK 7
Wire Connector
CC
x 3
Outlet Box Screw
DD
x 2
White from fixture
Black from fixture
Ground wire
from fixture
Wattage
15W
