5240 Willis Rd.
Theodore, AL 36582 USA
Toll Free: 1 (855) 223-2665
Tel: 1 (805) 933-9970
coolboss.com/coolee
3-in-1 Air Cooler, Ice Chest & Bluetooth Speaker
User Guide
Manual P/N 5900399 — Manual Revision A — May 2024
MODEL: CL-50R
⚠
Important
Read the entire contents of this manual before using this product. Make sure all other operators
also read this manual. Keep the manual near the product for future reference.
By proceeding with
setup and operation, you agree that you fully understand the contents of this manual and
assume full responsibility for product use.
Advertisement
Related Manuals for BendPak COOL BOSS coolee CL-50R
Summary of Contents for BendPak COOL BOSS coolee CL-50R
- Page 1 5240 Willis Rd. Theodore, AL 36582 USA Toll Free: 1 (855) 223-2665 Tel: 1 (805) 933-9970 coolboss.com/coolee 3-in-1 Air Cooler, Ice Chest & Bluetooth Speaker User Guide Manual P/N 5900399 — Manual Revision A — May 2024 MODEL: CL-50R ⚠ Important Read the entire contents of this manual before using this product.
- Page 2 Cool Boss. Trademarks. Coolee by Cool Boss, Coolee logo, and BendPak are trademarks of BendPak Inc. All other company, product, and service names are for identification only. All trademarks and registered trademarks in this manual are property of their respective owners.
- Page 3 Cool Boss at (855) 223-2665, or email Cool Boss at support@coolboss.com. Liability Information - BendPak Inc. assumes no liability for damages resulting from: • Use of the equipment for purposes other than those described in this manual.
-
Page 4: Specifications
Specifications Specifications Cooler Dimensions Exterior Length 25.25″(642.8 mm) Width 19.75″(501.75 mm) Height 21.5″(546.1 mm) Solar Panel Dimensions Exterior Length 12″(305 mm) Exterior Width 9.5″(241.5 mm) Approx. Total Interior Volume 50 quarts (47.3 liters) 12VDC (110VAC to 120 VAC, w/charging Nominal Input Charge Voltage adapter) Super Polymer Li-ion 10,400 mAh, 10.8V, Lithium Battery Packs (2) - Page 5 Components Adjustable Vents Swing operation allows • you to optimally direct a comfortable cool blast. • Internal Copper Finned Radiator High- quality radiator helps drop the temperature. • Two Solar Panels Simply place panels in direct sunlight to extend battery life. Extendable Handle Allows easy transport.
-
Page 6: Charging The Batteries
_________________________________________________________________________________________________ Charging the Batteries ⚠ WARNING Plug 110VAC charging cords into a properly grounded electrical receptacle only. For reliability, a durable injection molded battery case protects the lithium-ion battery cells and the electronics from moisture and harsh environments. The dual Coolee super-polymer rechargeable 10,000mAh lithium-ion battery lasts up to 5 hours (100 % Charge). - Page 7 Charging the Batteries in the Coolee 1. Raise the Rubber Cover (right side of Touch Control Panel) on the Coolee to access the 12VDC Input Port. 2. Choose to charge with either the 110VAC power adapter, or the 12VDC power cord. 3.
-
Page 8: Operation
Operation Operating the Coolee is easily accomplished from either the Touch Control Panel located at the top of the unit, or with the Hand-Held Remote Control; described later. The Touch Control Panel operates on-off functions, fan speeds, cooling pump, and Bluetooth. A built-in USB-A Output Port can deliver up to 10,000 mAh on a full charge for portable power and is compatible with any standard USB-A device. - Page 9 3. To operate Fan “A” and adjust the fan speed, press Fan “A” touch panel up to 2 short times to the desired fan setting (1 of 2 Fan levels will display). To turn off, press and hold Fan “A” touch panel. 4.
- Page 10 ____________________________________________________________________________ PARTS Ref. No. Description Qty. Coolee Cutting Board Wheel Directional Duct Axle Washer E-Clip Cap Nut Remote Batteries Battery Charger Car Charger 12V Pwr. Adap. 110V Typical Run Times w/Beginning Battery Charge at 100 percent Included Batteries RUN TIME (HOURS) Adding Optional RUN TIME (HOURS) PB960 Battery...
- Page 11 Storage During periods of non-use, it is best to store the Coolee away from harsh elements. Before storing, make sure to remove personal items and clean the Coolee as outlined in Easy Cleaning. It is also advisable to remove the battery packs and fully recharge them before storing. Keep the removed battery packs separate from the Coolee and placed where they are away from children.
- Page 12 5240 Willis Rd. Theodore, AL 36582 USA © 2024 BendPak Inc. All rights reserved. coolboss.com...
