F0
Fire Garden™
VF Chat Table
44" VF Chat Table
Omni-Test Laboratories, Inc.
Report # 0028GM127S
ANSI Z21.97-2017 /CSA 2.41-2017, CSA 2.17-2017
Outdoor Decorative Gas Appliances
DANGER
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill
you.
Never use this appliance in an
enclosed space such as a camper,
tent, car, or home.
French language manuals at outdoorfiregarden.com.
Travis Industries, Inc.
$10.00
By Travis Industries, Inc.
Manual
94900350
Listed by
CARBON MONOXIDE HAZARD
12521 Harbour Reach Dr., Mukilteo, WA 98275
Copyright 2022, T.I.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
•
Extinguish any open flame.
•
If odor continues, leave the area
•
immediately.
After leaving the area, call your gas
•
supplier or fire department.
Failure to follow these instructions
could result in fire or explosion, which
could cause property damage, personal
injury, or death.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
WARNING: For outdoor use only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Read the installation,
operating, and maintenance
instructions thoroughly before
installing or servicing this equipment.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for
future reference
Manuels de langue Française à outdoorfiregarden.com
www.travisproducts.com
Part # 100-01595
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries FIRE GARDEN VF Chat Table
Summary of Contents for Travis Industries FIRE GARDEN VF Chat Table
- Page 1 By Travis Industries, Inc. Fire Garden™ DANGER FIRE OR EXPLOSION HAZARD VF Chat Table If you smell gas: Shut off gas to the appliance. Manual • Extinguish any open flame. • If odor continues, leave the area • 44” VF Chat Table 94900350 immediately.
-
Page 3: Overview
WARNING: This product can expose you to chemicals including Carbon Monoxide and Benzene, which are known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.P65Warnings.ca.gov. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 4: Table Of Contents
Crushed Glass Installation ..........17 Assembling the Glass Wind Guard ........38 Tumbled Stone Installation ..........18 Index .................. 40 Before the First Fire ............19 Operating Instructions ............19 © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 5: Safety Precautions
Direct questions about the type of fuel used to your dealer. A label is placed on the control • Travis Industries, Inc. grants no warranty, implied or panel to show which fuel the appliance is designed for. stated, for the installation or maintenance of your appliance, and assumes no responsibility for any •... -
Page 6: Features
Max. Inlet 7" wc 11" wc Pressure Min. Inlet 6" wc 10" wc Pressure Input Rating Input Rating 65,000 65,000 (BTU/h) Orifice (1) - #30 (1) - #42 Size (DMS) © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 7: Installation Warnings
6. Leak test the gas lines. Verify the appliance works correctly and that there are no gas leaks. 7. Give the manual to the homeowner and explain the operation of the fire pit. Packing List • VF Chat Table • AAA battery. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 8: Additional Items Required
Travis Industries does not recommend or encourage the use of any media in this appliance except that which has been tested and is provided through an authorized Travis Industries dealer. -
Page 9: Installation Overview
Installation (qualified installers only) Installation Overview Below you will find a basic overview of the main components and how they are connected for a Voracious Fire - Chat Table. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 10: Appliance Placement Requirements
• In places where the controls beneath the appliance may be submerged underwater. Submerging any part of its controls may require the complete replacement of the controls. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 11: Clearances
Clearances Enclosure Ventilation Requirements WARNING Do not cover or block any opening in the table enclosure. These openings are required to vent propane in the event of a gas leak. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 12: Propane Cylinder Connection
• Unscrew the push button and remove it from the control panel. • Insert a AAA battery (negative end first) into the battery compartment. • Reinstall the push button knob © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 13: Enclosure Ventilation Requirements
Failure to maintain the gap will create a severe fire risk and will void the appliance warranty. • The height of the leveling legs can be adjusted by turning the leveling leg foot. The legs will adjust from 1/2" to 1". © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 14: Gas Line Requirements
The supply regulator (the regulator that attaches directly to the residence inlet or the propane tank) should supply gas • at the required input pressure detailed in the section “Gas Specifications” on page 6. Contact the local gas supplier if the regulator is at an improper pressure. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 15: Ng Conversion
2. Unscrew the appliance adapter from the air mixing tube as shown to the right 3. Remove the appliance adapter and the attached NG burner orifice from the mixing tube © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 16: Ng Conversion Steps - Cont
8. Reattach the gas flex to the appliance adapter. Make sure to check this connection to make sure there is no gas leak after installation. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 17: Steps For Finalizing The Installation
Crushed Glass Installation Crushed glass is placed over the burners and center media trays. Use only 1/4” crushed glass from Travis Industries and/or other media specifically approved by Travis Industries. Placing Crushed Glass on the Burner and Center Media Trays Without Optional Filler Kit 75 lbs. -
Page 18: Tumbled Stone Installation
Tumbled Stone may be placed over the burners and media trays. Only use the Tumbled Stone media kit from Travis Industries. The amount of stone indicated on the chart below refers to the small stones used to cover the burner and media tray. Large stones may be placed anywhere over the media tray but should not be installed over the burner and are not included in the recommended weights in the chart below. -
Page 19: Before The First Fire
Inspect the appliance, burner, and supply lines for any damage prior to operation. The burner must be replaced prior to the appliance being put into operation if it is evident that the burner is damaged. Use only Travis Industries replacement burners. It may be difficult to see the burner operating in direct sunlight. -
Page 20: Lighting The Fire Pit
4. After the burner lights, continue to push the valve control in for 30 seconds. 5. Release the valve control knob. Turn the knob until you have the desired flame height. 6. Close the door and enjoy the fire. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 21: Turning The Fire Pit Off
The LP gas cylinder must be disconnected from the appliance when the appliance is not in use. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 22: Maintaining Your Appliance
You may use a damp cloth and mild soapy water to clean the surface of the table enclosure. NOTE: Take care not to get soapy water on any of the media or in the burner tray • Rinse with clean water to ensure no soapy film remains. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 23: Leak Testing
If a leak is found in a gas line or if you are unable to stop a leak at a connection, turn the gas off, remove the propane cylinder and call your dealer for service. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 24: Accessing Components
Disconnect the igniter wire from the back of the pulse igniter module. NOTE: The thermocouple is delicate. Take care not to damage the thermocouple when disconnecting it from the valve. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 25: Removing The Burner Assembly
Once maintenance or testing of components is complete, follow the above steps in reverse to return the appliance to its proper configuration. NOTE: Make sure to leak test the gas line connections after reassembling the appliance. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 26: Winterizing The Appliance
Start the main burner. After 15 minutes, the flames should be orange/yellow. If the appliance is not burning correctly, contact your dealer for service. If the igniter is not sparking or lighting the appliance properly contact your dealer for service. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 27: Replacement Parts List
Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate the appliance with the optional glass wind guard cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 28: Troubleshooting Table
Burner or burner orifice may be debris (spider webs, etc.) from the burner and dirty or blocked orifice area. Remove or reposition the media • Media is too thick over the burner © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 29: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your... -
Page 30: Optional - Glass Media Filler Kit
When forming the shapes as shown below, we recommend using gloves to protect your hands from any sharp metal edges. • The filler piece shapes have perforated tabs along its perimeter. Use pliers to gently bend the tabs of each filler piece down 90 degrees. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 31: Glass Media Weights When Using Filler Kit
When using the glass filler kits as described above disregard the weights listed in the appliance manual. The amount of glass media needed for the installation will decrease to the weights below Chat Table Amount of glass needed with Filler Kit 25 lbs. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 32: Optional - Hard Pipe Kit - Sku 94601184
The installation of this kit should only be undertaken by qualified installers. Check with the local authority having jurisdiction to determine if any special licenses, certifications, and/or permits are required. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 33: Installation
• Pull the door away from the enclosure until the slide rails on the door are free from the slide rails on the enclosure. Set the door aside for reinstallation. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... - Page 34 There are (2) notches in the metal support just under the knock-out hole. Slide the (2) pem studs into the (2) slots. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table...
- Page 35 NOTE: make sure the rubber washer is sandwiched between the decorative flange and the enclosure to avoid damaging the finish on the appliance. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table...
- Page 36 Slide the door inward until it is flush with the enclosure. You should hear a soft click as the locking levers lock the slide rails back together. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table...
-
Page 37: Operation
Turn the key clockwise to open the valve and counterclockwise to close it. • Once the key valve is open, follow the instructions included with the Chat Table for lighting the appliance. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... -
Page 38: Optional - Glass Wind Guard - Sku 94601180
Chat Table Burner. Measure the distance from the edges of the pit to the edges of the glass to ensure that it is centered. © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table... - Page 39 Notes © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table...
-
Page 40: Index
Turning the Fire Pit Off ........21 Igniter Battery Installation ......... 12 Winterizing the Appliance ........ 26 Installation Warnings .......... 7 Yearly Service Procedure ........ 26 Leak Testing ............. 23 Index © Travis Industries, Inc. 4/29/24 - 1595 VF Chat Table...
