- Page 1 Premium Power Station 250 / 500 / 750 DESCRIPTION HSPS250W / HSPS500W / HSPS750W PRODUCTS USER INSTRUCTIONS Page | 1...
- Page 2 This page has been intentionally left blank Page | 2...
-
Page 3: Table Of Contents
Contents What’s included? ..........................4 Leisure battery ..........................4 Charge controller ..........................5 Solar panel............................6 Top panel and connections ......................7 System operation ..........................8 System operation (cont.) ......................... 9 Basic fault finding .......................... 10 Accessories ..........................11 Specifications for Hubi Power Station Premium 250 ..............12 Specifications for Hubi Power Station Premium 500 .............. -
Page 4: What's Included
What’s included? In the standard power station kit are the following parts – • Power station premium • 12V AGM leisure battery • Solar panel • Solar panel mounting brackets • Instructions bag containing – o Power station instructions (this document) o Inverter instructions o Charge controller instructions o Solar panel information... -
Page 5: Charge Controller
Charge controller Built into the power station is a 20A PWM charge controller capable of handling up to a maximum of 300W of solar power. This device converts the incoming solar power from the panel to the required power for the battery. There are no adjustments required for this device, as it is already connected to the power station wiring. -
Page 6: Solar Panel
Solar panel The size of the solar panel supplied with the power station will depend on which model was purchased, but they range from 60-150W and come with 4m of cable pre-attached. 150W 100W Also provided as part of the kit is a universal solar panel stand consisting of a fully adjustable pair of stand legs which can be either wall, roof or ground mounted. -
Page 7: Top Panel And Connections
Top panel and connections 1. DIN Socket This socket allows you to connect peripheral devices that require a 12V supply. 2. Voltage indicator This display indicates the voltage of the battery inside the power station when the unit has been switched on. 3. -
Page 8: System Operation
System operation To turn the system on, click the system on/off switch into the forward position. The panel voltage display will come on and indicate the current battery voltage. These indicative voltages show how much charge is left within the battery. Ideally, these readings should be taken after dark when the solar panel is not producing any power –... -
Page 9: System Operation (Cont.)
System operation (cont.) When a mains supply is required, click the inverter switch to the “1” position. Please allow 5 seconds from when the inverter switch is turned on, for the mains supply to be available and ready for use from the mains socket (9). The modified sine wave inverter can operate light loads of up to 300W but it is not recommended for powering voltage-sensitive or inductive equipment. -
Page 10: Basic Fault Finding
Basic fault finding Check the 30A system fuse and replace it as necessary. No power when the power station is switched on. Is the battery charged? Double-check using a multimeter that it reads over 12V DC. No output from the DIN socket, Check the 10A lighting fuse and replace it as necessary. -
Page 11: Accessories
Accessories Here is a list of accessories that are available for the power station premium – • Lighting Pack 1 is ideal for a single office or hobby room and the perfect choice with Solar Power Station Premium 250. • Lighting Pack 2 is perfect as a lighting solution for workshops, garages and large stable blocks, and the perfect choice with Solar Power Station Premium 500. -
Page 12: Specifications For Hubi Power Station Premium 250
Specifications for Hubi Power Station Premium 250 Model Number HSPS250W 12V DC System voltage 230V AC Battery AGM solar battery 42Ah Useable watts at 12V 252Wh Useable watts at 5V 200Wh 12V auto socket Power output sockets 3-pin UK/2-pin euro AC socket (on the inverter) Power input MC4 connectors (for solar panel) Switch settings... -
Page 13: Specifications For Hubi Power Station Premium 500
Specifications for Hubi Power Station Premium 500 Model Number HSPS500W 12V DC System voltage 230V AC Battery AGM solar battery 85Ah Useable watts at 12V 500Wh Useable watts at 5V 1220Wh 12V auto socket Power output sockets 3-pin UK/2-pin euro AC socket (on the inverter) Power input MC4 connectors (for solar panel) Switch settings... -
Page 14: Specifications For Hubi Power Station Premium 750
Specifications for Hubi Power Station Premium 750 Model Number HSPS750W 12V DC System voltage 230V AC Battery AGM solar battery 125Ah Useable watts at 12V 750Wh Useable watts at 5V 1800Wh 12V auto socket Power output sockets 3-pin UK/2-pin euro AC socket (on the inverter) Power input MC4 connectors (for solar panel) Switch settings...
