Solar Technology International Hubi Retro 1 User Manual

SPECIAL NOTE Hubi Retro can deliver a maximum of 3.5A at any one time so if all
the power sockets are used and the combined current exceeds 3.5A, Hubi Retro
will close down to protect its circuits. To reset Hubi Retro, remove the solar panel
from the hub and use the reset tool provided in this kit (or a paperclip or similar
object) and insert it into the Reset socket (Fig 1, 9) on the front of Hubi. Press it
once to reset the system. Then connect Hubi back to the solar panel and once
daylight activates the solar panel the hub will be reset. Hubi is not designed to
work with an inverter. If an inverter is connected to Hubi Retro, the hub will close
down and will need to be re-set as above. Should the above occur, it will not have
damaged Hubi Retro.

9. Warning

Keep Hubi away from fire and don't allow it to get wet. Any severe shock or impact may
result in damage and will invalidate the warranty. It is strictly forbidden to dismantle
Hubi except by Solar Technology personnel or agents appointed by Solar Technology.
Any sign of tampering will result in the warranty being terminated.

10. Warranty

All items in this box including Hubi, LEDs and cables are supplied with a 24 month
global warranty* except the solar panel, which is supplied with a 10 year module
warranty and 20 year performance warranty.
Should a failure occur during this time Solar Technology International Ltd will repair or
replace any faulty part, at its discretion. Solar Technology International Ltd does not
accept liability for any 3rd party damage how so ever caused or any costs associated
with the return of faulty products.
*Global warranty means if a product is returned to the address overleaf at the sender's
expense and a warranty claim is found to be valid, Solar Technology International
Ltd will return the repaired or replaced product to the sender at Solar Technology
International Ltd's expense irrespective of where the sender is located in the world.

11. Optional accessories

Solar Technology supplies a comprehensive range of accessories for Hubi, which is
constantly being updated. Please visit www.solartechnology.co.uk
1. Lap top adaptor 7. Extension cables
2. Apple / HP version 8. 12v fan
3. Lumi light 9. Expansion kits (Hubi + panel)
4. Lumi splitter 10. Hubi boxes (without panel)
5. LED strip light 11. Mains adapter to charge Hubi
6. LED bulb and cable 12. Camcaddy2
We want your photos and videos!
Here is your chance for you and your Hubi power station to
be a star! Just send in pics or videos of you and your Hubi in a great location
and if selected we will not only give you ever lasting recognition on our
online favourite users wall of fame but we will send you a Freeloader Sixer,
6000mAH solar power bank worth £70 completely free!
Please send to hello@solartechnology.co.uk including your address details
and best of luck!
Note – we cannot guarantee to publish every entry and only those selected
by our marketing department for publication will be awarded a Sixer. By
providing your images you automatically grant us the right to use these
images or videos howsoever we see fit.

Frequently Asked Questions

1. The solar panel never seems to fully charge Hubi
• Check the panel is not shaded and that it is outdoors. If inside, even
if against a glass window, the charge capability of the panel reduces
significantly. Also bear in mind a solar panel looses approximately 8 times
its summer charging capability in the winter.
2. The power indicator on Hubi never shows 4 bars
• This does not necessarily signify that the Hubi is not full. LEDs are not a
totally accurate way to measure power and inaccuracies can sometimes
be experienced. So long as the Hubi after a full sunshine charge delivers
power as indicated in section 3 it is working well.
3. Is there any other way to charge up Hubi other than solar?
• There are two options; charge by mains wall plug or charge by 12v auto
plug – see www.solartechnology.co.uk
4. What happens if Hubi gets wet?
• Hubi is not water resistant although is very robust and designed for use
outdoor but should it get wet disconnect it from the solar panel and other
devices and let it dry naturally indoors for a period of one week. There is a
very good chance it will recover without future problems and can be used
as normal. However, if it will not work then it must be assumed the battery
has been damaged and can be returned to Solar Technology for battery
replacement – see section 8.
5. What about if I break something?
• All parts of the Hubi system are replaceable and we have spares
at Solar Technology in the UK. In this instance please call
+44 (0) 1684 774000 for a quotation.
6. I plugged a device into Hubi and it instantly stopped working
and would not work again.
to view.
• In this instance Hubi's sockets have been overloaded. Hubi can
only deliver a maximum of 3.5A and if more is demanded of it, it will
automatically shut down to protect its circuits from overload. To reset
Hubi disconnect the solar panel cable and follow the instructions in
the 'Special Note', top left next to this page.
Hubi
and look under Hubi Accessories.
User manual
Solar Power Station
Models:
Hubi Retro 1, 2, 3 and 4
Congratulations on purchasing the Hubi Power Station
and another step toward grid independence!
The instruction manual will help you understand how Hubi
works, how to get the best from it, and just as important,
its limitations.
IMPORTANT: PLEASE READ BEFORE FIRST USE
Important: please read before first use.
®
Retro
