Summary of Contents for ProLights ControlGo
- Page 1 ControlGo Versatile 1-Universe DMX Controller with Touchscreen, RDM, CRMX and Multiple Power Options QUICK GUIDE English version Rev.01 - Preliminary...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
-
Page 3: Table Of Contents
CREATING CUSTOM PERSONALITIES ................10 UPDATING THE LIBRARY:....................10 8 - ACCESSORIES INSTALLATION QUICK MOUNT PLATE FOR CONTROLGO..............11 V-MOUNT BATTERY ADAPTER FOR CONTROLGO ............12 9 - FIRMWARE UPDATE FLASH DRIVE PREPARATION: ..................13 RUNNING THE UPDATE: ....................13 ADDITIONAL NOTES: .................... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. - Page 5 AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 • This device complies with Part 15 of the FCC Rules. Operation is subject to the fol- lowing two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Other approvals PROLIGHTS - ControlGo...
-
Page 7: Packaging
• 1 x CONTROLGO • 1 x Eva Case for CONTROLGO (CTRGEVACASE) • 2 x Soft handle for CONTROLGO (CTRGHANDLE) • 1 x Neck lanyard with double balancing and adjustable side strips for CONTROLGO (CTRGNL) • 1 x User manual OPTIONAL ACCESSORIES •... -
Page 8: Product Overview
5. USB-C Port for 5-9-12-20V PD3.0 Power Input & data transfer; 6. Power Button; 7. HOOK for Soft Handle; 8. Quick function keys; 9. RGB Push Encoders; 10. 5'' Touchscreen Display; 11. Physical Buttons 12. NPF Batteries Slots Fig 02 PROLIGHTS - ControlGo... -
Page 9: Connection To The Power Supply
4 - CONNECTION TO THE POWER SUPPLY ControlGo is equipped with an NP-F battery slot and optional accessory to fit V-Mount batteries. If you want to keep it lighter, you can still source power from the USB C, the Weipu 2 Pin DC input, or from the remote port on board of PROLIGHTS fixtures. -
Page 10: Construction Of The Dmx Termination
CONSTRUCTION OF THE DMX TERMINATION The termination is prepared by soldering a 120Ω 1/4 W resistor between pins 2 and 3 of the male XLR connector, as shown in figure. Example: 5 pin XLR connector Fig. 04 PROLIGHTS - ControlGo... -
Page 11: Control Panel
Fig. 05 BUTTONS FUNCTIONS AND NAMING CONVENTIONS The ControlGo device features a display and several buttons that provide access to various control panel functions. Each button’s functionality can vary depending on the context of the screen currently in use. Below is a guide to understanding the common names and roles of these buttons as referenced... -
Page 12: Personality Library Update
• PUSH ENCODER • GROUP buttons (Buttons Above the Touchscreen) 7 - PERSONALITY LIBRARY UPDATE ControlGo allows you to update and customize fixture personalities, which are profiles that define how the device interacts with various lighting fixtures. CREATING CUSTOM PERSONALITIES... -
Page 13: Accessories Installation
8 - ACCESSORIES INSTALLATION QUICK MOUNT PLATE FOR CONTROLGO (CODE CTRGQMP - OPTIONAL) Place fixture on a stable surface. 1. Insert the CTRGQMP from the bottom part. 2. Screw the supplied screw to fix the accessory to the CONTROLGO. PROLIGHTS - ControlGo... -
Page 14: V-Mount Battery Adapter For Controlgo
V-MOUNT BATTERY ADAPTER FOR CONTROLGO (CODE CTRGVMADP - OPTIONAL) Place fixture on a stable surface. 1. Insert first the pins of the accessory on the bottom part. 2. Fix the accessory as shown in the figure. PROLIGHTS - ControlGo... -
Page 15: Firmware Update
• Insert the USB flash drive into the ControlGo's USB port without powering off the device • If you are inside the ControlGo software, press and hold the Back/Esc button for 5 seconds to return to the main screen. -
Page 16: Maintenance
• It is recommended to check at least annually if new firmware is available and a visual check of the status of the device and mechanical parts. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. - Page 17 Re-link them if necessary by following the CRMX linking procedure in the ControlGo manual. • Ensure Output • The ControlGo might not be outputting a DMX signal: from ControlGo Confirm that the ControlGo is configured to output DMX. Navigate to the DMX output settings and verify that the signal is active and being transmitted.
- Page 18 Note...
- Page 20 PROLIGHTS is a trademark of prolights.it Via A.Olivetti snc MUSIC & LIGHTS S.r.l. support@prolights.it 04026 - Minturno (LT) ITALY musiclights.it Tel: +39 0771 72190...
