DVB Hardware | IPTV System | Video IP Encoder/Transcoder
TBS6916 Signal Connection Mode and Usage Instruction
The TBS6916 uses two chips, each has 8 demodulators and integrated with tuners,
and the chips adopted of the multiplexing technology, which provides more
diverse signal connection methods. Now, let's introduce three typical modes:
Setting the mode in the driver:
Create a configuration file:
touch /etc/modprobe.d/stid135.conf
1.# Mode 0, Multswitch mode
It is the default mode set by the driver. So, there is no need to configure the driver
settings file.
Or if you want to set the configuration file, please enter:
Vim /etc/modprobe.d/stid135.conf
Options stid135 mode= 0
After the setup complete, please reboot the system to apply the configuration file.
Any RX terminal such as Quad-LNB or Multiswitch can be connected arbitrarily.
Quattro-LNB/Multiswitch ：
In this mode, the four signal input ports of the 6916 output four signal
polarizations respectively: VL（LNB0） 、VH（LNB1） 、HL（LNB2） 、HH（LNB3） ，
When use Quattro-LNB , the corresponding polarization signal lines must be
correctly connected.
www.tbstdv.com | www.tbsiptv.com
Advertisement
Related Manuals for tbs electronics TBS6916
Summary of Contents for tbs electronics TBS6916
- Page 1 DVB Hardware | IPTV System | Video IP Encoder/Transcoder TBS6916 Signal Connection Mode and Usage Instruction The TBS6916 uses two chips, each has 8 demodulators and integrated with tuners, and the chips adopted of the multiplexing technology, which provides more diverse signal connection methods.
- Page 2 DVB Hardware | IPTV System | Video IP Encoder/Transcoder Quad-LNB ： Connect the 4 cables to the 4 ports of TBS6916 directly Single C or Ku Band： Two inputs are enough, you just need to connect the cables to input 0 and input 2 to provide V and H signal.
- Page 3 DVB Hardware | IPTV System | Video IP Encoder/Transcoder In some case multiswitch have more than one satellite input, need to choose the satellite first. 2.# Mode 1, direct connection mode Create configuration file: Vim /etc/modprobe.d/stid135.conf Options stid135 mode=1 After the setup complete, please reboot the system to apply the configuration file. In this mode, LNBs provide signals for adapters in this way: "LNB0"...
- Page 4 DVB Hardware | IPTV System | Video IP Encoder/Transcoder 3#. Model 2， Unicable Mode Create configuration file: Vim /etc/modprobe.d/stid135.conf Options stid135 mode=2 Reboot the system to apply the configuration file. In this mode, using Unicable function, the signal line from Unicable is directly connected to "LNB3"，...
